Product Overview
SD16/F/R/W
* Power System
● The installed WP10 electronically controlled engine conforms to the China-III non-road machinery emission regulation,
featuring strong power, high efficiency and energy-saving, and low maintenance cost.
● The rated power reaches 131kW, featuring high torque reserve coefficient.
● The radially sealed intake system is applied to effectively prolong the engine life.
* Drive system
● The curves of drive system and engine are perfectly matched to achieve more extensive high-efficiency zone and higher transmission efficiency.
● Shantui’s self-made drive system features stable performance and reliable quality and has been long proved by the market.
* Driving/Riding Environment
● The hexahedral cab provides super-large interior space and broad vision and the ROPS/FOPS can be installed depending on
specific needs to ensure high safety and reliability.
● The electronic control hand and foot accelerators guarantee more accurate and comfortable operations.
● The intelligent display and control terminal and the A/C and heating system are installed to provide more abundant
personalized driving/riding experience and enable you to understand system status at any time, featuring high intelligence and convenience.
* Working adaptability
● Shantui’s stable and reliable chassis system is applicable to diversified severe working conditions.
● The product features long ground length, high ground clearance, stable driving, and good trafficability.
● The straight tilting blade, U-blade, angle blade, coal blade, rock blade, environmental sanitation blade, ripper, and
traction frame can be installed depending on specific working condition to achieve higher working adaptability. The optional LED working lamps improve the illumination capability during nighttime operations to achieve higher safety and reliability.
* Easy maintenances
● The structural parts inherit the excellent quality of Shantui’s mature products;
● The electric harnesses adopt corrugated pipes for protection and deconcentrators for branching, featuring high protection grade.
● The openable large-space side hoods make the repairs and maintenance easier.
● The fuel filter element and the air filter are designed on one same side to achieve one-stop；
● The installed WP10 electronically controlled engine conforms to the China-III non-road machinery emission regulation,
featuring strong power, high efficiency and energy-saving, and low maintenance cost.
● The rated power reaches 131kW, featuring high torque reserve coefficient.
● The radially sealed intake system is applied to effectively prolong the engine life.
* Drive system
● The curves of drive system and engine are perfectly matched to achieve more extensive high-efficiency zone and higher transmission efficiency.
● Shantui’s self-made drive system features stable performance and reliable quality and has been long proved by the market.
* Driving/Riding Environment
● The hexahedral cab provides super-large interior space and broad vision and the ROPS/FOPS can be installed depending on
specific needs to ensure high safety and reliability.
● The electronic control hand and foot accelerators guarantee more accurate and comfortable operations.
● The intelligent display and control terminal and the A/C and heating system are installed to provide more abundant
personalized driving/riding experience and enable you to understand system status at any time, featuring high intelligence and convenience.
* Working adaptability
● Shantui’s stable and reliable chassis system is applicable to diversified severe working conditions.
● The product features long ground length, high ground clearance, stable driving, and good trafficability.
● The straight tilting blade, U-blade, angle blade, coal blade, rock blade, environmental sanitation blade, ripper, and
traction frame can be installed depending on specific working condition to achieve higher working adaptability. The optional LED working lamps improve the illumination capability during nighttime operations to achieve higher safety and reliability.
* Easy maintenances
● The structural parts inherit the excellent quality of Shantui’s mature products;
● The electric harnesses adopt corrugated pipes for protection and deconcentrators for branching, featuring high protection grade.
● The openable large-space side hoods make the repairs and maintenance easier.
● The fuel filter element and the air filter are designed on one same side to achieve one-stop；
FEATURES AT A GLANCE
Operating weight: 17000kg
ENGINE POWER
131kW/1850rpm
OVERALL WEIGHT
17,000kg (Standard)
ENGINE MODEL
WD10/WP10
131kW/1850rpm
OVERALL WEIGHT
17,000kg (Standard)
ENGINE MODEL
WD10/WP10
Right elevation
Left elevation
Front elevation
PRODUCT SPECIFICATIONS
Parameter name | SD16 (Standard version) | SD16C (Coal version) | SD16E (Extended version) | SD16L（Super-wetland version） | SD16R (Environmental sanitation version) | SD16D (Desert version) |
Performance parameters | ||||||
Operating weight (Kg) | 17000 | 17500 | 17346 | 18400 | 18400 | 18200 |
Ground pressure (kPa) | 58 | 50 | 55 | 25 | 25 | 33.2 |
Engine | ||||||
Engine model | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) |
Rated power/rated speed (kW/rpm) | 131/1850 | 131/1850 | 131/1850 | 131/1850 | 131/1850 | 131/1850 |
Overall dimensions | ||||||
Overall dimensions of machine (mm) | 5140*3388*3032 | 5427*3900*3032 | 5345*3388*3032 | 5262*4150*3074 | 5262*4150*3074 | 5262*4150*3074 |
Driving performance | ||||||
Forward speed (km/h) | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 |
Reversing speed (km/h) | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 |
Chassis System | ||||||
Center distance of track (mm) | 1880 | 1880 | 1880 | 2300 | 2300 | 2300 |
Width of track shoes (mm) | 510/560/610 | 610 | 560/510/610 | 1100/950 | 1100/660 | 810 |
Ground length（mm） | 2430 | 2430 | 2635 | 2935 | 2935 | 2935 |
Tank capacity | ||||||
Fuel tank (L) | 315 | 315 | 315 | 315 | 315 | 315 |
Working device | ||||||
Blade type | Angle Blade, Straight tilting blade and U-shaped Blade | Coal blade | Angle Blade, Straight tilting blade and U-shaped Blade | Straight tilting blade | Sanitation blade | Straight tilting blade |
Digging depth (mm) | 540 | 540 | 540 | 485 | 485 | 485 |
Ripper type | Three-tooth ripper | —— | Three-tooth ripper | —— | —— | —— |
Ripping depth (mm) | 570 | —— | 570 | —— | —— | —— |
PRODUCT CONFIGURATION
Imported High Power Engine
Imported Control Valve
Imported hydraulic motor
Successful Project
Project in Africa
Project in Central Asia
Project in South America
