3D динамическая фокусировка RF Co2 лазерная маркировка гравировальные станки для кожаной обуви футболки логотип
832 132,80-866 805,00 ₽
Легко транспортировать ручной лазерный гравировальный станок
- Категория: >>>
- Поставщик: TopChoice World trade LLCTopChoice LLC
Сохранить в закладки 1601286857604:
Описание и отзывы
Характеристики
Products Description
Easy to transport hand hell laser engraving machine second-hand-laser-engraving-machine handheld shoe laser engraver
Handheld Fiber Laser Marking Machine
Fiber Handheld 20/30W/50w Series Specification Table/Laser Marking Machine. Provide high-quality, reliable laser systems trusted by customers in many countries.
Handheld laser markers are portable, battery powered and fully autonomous marking machines! Thanks to its powerful 24V rechargeable lithium battery power supply system, under normal usage.
Handheld laser markers are portable, battery powered and fully autonomous marking machines! Thanks to its powerful 24V rechargeable lithium battery power supply system, under normal usage.
Product Paramenters
project | Parameter table | 20w | 30w | 50w | ||
Overall characteristics | Material of complete machine | Sand blasting oxidation all aluminum structure | ||||
Laser | The service life of fiber laser generator is more than 100000 hours | |||||
Actual output power | ≥20W | ≥30W | ≥50W | |||
master control | 8 inch touch controller | |||||
Cooling system | air cooling | |||||
Lens | 100*100mm/ 140*140mm/ 165mm*165mm（option ） | |||||
Positioning mode | Red light indication | |||||
Production line speed | 0 ~ 130m / min (depending on the material) | |||||
Repetition Frequency | 27-60Khz | 30-60Khz | 45-170Khz | |||
parameter | Power Supply | Standard configuration: external power supply 100-240VAC 50/60HZ | ||||
operating system | Linux system | |||||
hand-held head | 273*130*283.5mm; 1.4kg | |||||
Overall dimensions | 315*170*264mm | |||||
Net machine weight | 10.1kg | 11.3kg | ||||
Battery endurance | 160 minutes | 80minutes | ||||
Software introduction | Multilingualism | English, French, Spanish, German, etc 16 languages | ||||
Inkjet mode | Static, analog and encoder. Three printing modes | |||||
data protection | With power-off data protection function | |||||
file format | With power-off data protection function | |||||
bar code | Code39, code128, code126, QR, (optional) | |||||
Details Images
Handheld laser marking machine Features:
1.Built in battery design :
24V lithium battery (optional) 12Ah
hiah capacitv batterv
Charging time: 4 hours
Continuous run time
20W/30W: 160 minutes; SOW: 80 minutes
2.Portable design, multiple :
Portable + flight design (optional) suitable for a variety of occasions
3.Configure Linux system :
8-core processor with high configuration
security Stable performance, fast response, not easy to be poisoned and down
4.All aluminum body precise and compac :
The weight of the whole machine is 11.3kg. and the marking head is only 1. 4Kg.
Ergonomic design, comfortable to hold and easy to operate
hiah capacitv batterv
Charging time: 4 hours
Continuous run time
20W/30W: 160 minutes; SOW: 80 minutes
2.Portable design, multiple :
Portable + flight design (optional) suitable for a variety of occasions
3.Configure Linux system :
8-core processor with high configuration
security Stable performance, fast response, not easy to be poisoned and down
4.All aluminum body precise and compac :
The weight of the whole machine is 11.3kg. and the marking head is only 1. 4Kg.
Ergonomic design, comfortable to hold and easy to operate
Customer Photos
Participation in exhibitions
Application：
Fiber laser marking machines are widely used in many industries, including but not limited to:
1.Electronic and communication products: used to mark serial numbers and barcodes on components.
2.Machinery: Marking unique identifiers or brand logos on parts.
3.Jewelry: Carving fine patterns and text on metal or gemstone surfaces. 4.Packaging industry: Printing information such as
production date, shelf life and anti-counterfeiting code on packaging materials.
1.Electronic and communication products: used to mark serial numbers and barcodes on components.
2.Machinery: Marking unique identifiers or brand logos on parts.
3.Jewelry: Carving fine patterns and text on metal or gemstone surfaces. 4.Packaging industry: Printing information such as
production date, shelf life and anti-counterfeiting code on packaging materials.
Product packaging
Company Profile
FAQ
1.Q:Are you a manufacturer or a trading company?
A：We have our own factory and we are committed to creating high quality products, If you have the opportunity, welcome to visit our factory. We are a company with 13 years of experience in manufacturing and sales. if you are interested in our products, please contact us!!!!
2.Q:How long does it take to learn how to use a machine?
A：The software has instructional videos that are easy to learn, and we can also help you learn the laser online. However, when working with different materials, it takes some trial and error to master the speed and power settings. Therefore, we include a comprehensive guide with recommended speed and power settings for various materials. If you have any questions during use, we will always send someone to answer your questions for you.
3.Q:What is the packaging of the product? Is it safe in transportation?
A：(1) Inner: plastic stretch film and white foam.
(2)Middle: small pieces of wood and screws.
(3)outside: standard export wooden case. So,the laser machine will send to you safely. In case the machine was damaged , please contact us ,We will process the replacement as soon as possible to ensure that it arrives in time .
(3)outside: standard export wooden case. So,the laser machine will send to you safely. In case the machine was damaged , please contact us ,We will process the replacement as soon as possible to ensure that it arrives in time .
4.Q:If there is a problem with the machine what will you guys do to fix it?
A：We provide two years warranty. During the warranty period, we will provide the damaged products for free. After the warranty period, we still provide repair service.
5.Q:Quality control:
A: The entire production process will be subject to regular inspection and strict quality control. The whole set of machines will be tested before they leave the factory to make sure they work well. Our machines have passed CE certification, meet European and American standards, and are exported to more than 100 countries.
