Солнечный погружной насос с электродвигателем переменного и постоянного тока
29 412,66-34 050,81 ₽
Китай лидер продаж заводская цена сельскохозяйственное оборудование серии Qb бесщеточный двигатель постоянного тока водяной насос на солнечной батарее Солнечный
- Категория: >>>
- Поставщик: Xrise International Trading Co. LtdXrise Ltd
Сохранить в закладки 1601287291013:
Описание и отзывы
Характеристики
Solar Pump System Introduction
hybrid solar pump system consists of four parts: solar panels, solar pumping inverter, three-phase AC pump and water storage device. The solar pump inverter converts DC power produced by solar panels to AC power, which drives the AC pump to extract water from boreholes, rivers, lakes, etc. to the storage device. The inverter applies the high-efficiency MPPT algorithm to maximize power harvested from the solar panels, producing water as energy-efficiently as possible. The solar pump system meets low carbon, energy conservation, and environmental protection demands while improving the standard of living in water-deficient areas.
Solar system Parameters
Solar paenls
Type:182mm Half Cell High Effiency
PV Module
Max. Power 550WMax. Efficiency: 21.29%
Size: 2278×1134×35mm
Weight: 29kg
monocrystalline solar module with PERC technology 550Wp (144 cells)
Solar panel with 550Wp power output and high efficiency 21.29%. With positive power tolerance 0/+5W allows to reach maximum power of 555Wp. Warranty of 12 years of product and 25 years of production of linear type.
Anti-PID design with split cells at one third (144 in total) smaller than traditional split-cell solar panels allows for high solar performance.
Solar panel with 550Wp power output and high efficiency 21.29%. With positive power tolerance 0/+5W allows to reach maximum power of 555Wp. Warranty of 12 years of product and 25 years of production of linear type.
Anti-PID design with split cells at one third (144 in total) smaller than traditional split-cell solar panels allows for high solar performance.
Solar pump inverter
* Drives power-matched three-phase AC pump
with 380-460Vac 50/60Hz.
* Hybrid with Unility grid/DG or solar input, automatic switching with solar priority,
complementary energy usage to keep the pump running and achieving 24-hour water supply.
* Advanced IGBT power module
* High conversion efficiency, low temperature rise, low noise, long lifespan
* Advanced MPPT technology, 99%+ efficiency
* Fully automatic operation; operational data can be stored for 10 years
* Robust system protection, high reliability
* Newly redesigned anodized aluminum case
LCD display
* RS485/GPRS interface
* Modular design; easy to install, operate and maintain
complementary energy usage to keep the pump running and achieving 24-hour water supply.
* Advanced IGBT power module
* High conversion efficiency, low temperature rise, low noise, long lifespan
* Advanced MPPT technology, 99%+ efficiency
* Fully automatic operation; operational data can be stored for 10 years
* Robust system protection, high reliability
* Newly redesigned anodized aluminum case
LCD display
* RS485/GPRS interface
* Modular design; easy to install, operate and maintain
Model | JNP22KH-V5 | JNP45KH-V5 | JNP55KH-V5 | ||
PV Input | |||||
D.C. Max. Input Voltage | 880V | ||||
Recommended MPPT Voltage | 460~850V | ||||
D.C. Max. Input Current | 49A | 100A | 122A | ||
Max. MPPT Efficiency | >99% | ||||
Number of String | 1 | ||||
A.C. Input | |||||
Voltage | 330~460Vac (3PH) | ||||
Frequency | 50Hz/60Hz(±3%) | ||||
50Hz/60Hz(±3%) | |||||
Max. Motor Output Power | 22kW | 45kW | 55kW | ||
Rated Output Voltage | 380~460Vac (3PH) | ||||
Output Frequency Range | 0~50/60Hz | ||||
Rated Output Current | 42A | 86A | 104A | ||
System | |||||
Protection Level | IP65 | ||||
Operation Temperature | -25~60℃ | ||||
Cooling Way | Force cooling | ||||
Display | LCD | ||||
Communicaton | RS485/GPRS | ||||
Altitude | 3000m, above3000m need derate operating | ||||
Noise Emission | <50dB | ||||
Compliance | EN 50178; IEC/EN 62109-1;IEC61800 | ||||
Dimension（W/H/D） | 260/518.5/173(mm) | ||||
Weight | 35kg | ||||
Solar Submersible AC Pump
Feature:
1.Italian efficient and precise mechanical seals.
2.Motor housing and bottom cover adopt stainless steel 304.
3.Cold-rolled high-efficient and precise silicon steel sheet is adopted for lamination,with low loss and good magnetic conductivity.
4.High precision silent bearing enables the pumps long service life,more stable operation.
5.The stator adopts H class (200 degrees)high temperature resistant pure copper wire,low temperature rise,safe and reliable,suitable for long-term continuous work,long service life,environmental protection and energy saving
1.Italian efficient and precise mechanical seals.
2.Motor housing and bottom cover adopt stainless steel 304.
3.Cold-rolled high-efficient and precise silicon steel sheet is adopted for lamination,with low loss and good magnetic conductivity.
4.High precision silent bearing enables the pumps long service life,more stable operation.
5.The stator adopts H class (200 degrees)high temperature resistant pure copper wire,low temperature rise,safe and reliable,suitable for long-term continuous work,long service life,environmental protection and energy saving
Certificates
Production lines and testing
Product packing and shipping
Delivery ways:
Less than 5pcs, inverters are shipped out by express via DHL, FEDEX, UPS, TNT or EMS accordingly. Bulk order will be shipped out
by air or by sea according to customer's requirement.Delivery time:
1-10pcs, delivery time is in 3-7 days.
Bulk order delivery time is in 10-30 days.
Less than 5pcs, inverters are shipped out by express via DHL, FEDEX, UPS, TNT or EMS accordingly. Bulk order will be shipped out
by air or by sea according to customer's requirement.Delivery time:
1-10pcs, delivery time is in 3-7 days.
Bulk order delivery time is in 10-30 days.
Projects reference
1.144MWp Anhui and Zimbabwe Solar Water Irrigation Project.
Location：Zimbabwe
Application：Agricultural irrigation
System Configuration:
1. Solar panels: 550W * 2080 pieces
2. Solar off grid energy storage system，AC grid connected cabinet，DC distribution cabinet
Application：Agricultural irrigation
System Configuration:
1. Solar panels: 550W * 2080 pieces
2. Solar off grid energy storage system，AC grid connected cabinet，DC distribution cabinet
Projects in Yemen.
The XRISE team has been developing innovative energy products since 2010.
We have always put our customers’ needs;
First, focusing on the quality of our solar pump inverters and providing customer service that’s second to none.
First, focusing on the quality of our solar pump inverters and providing customer service that’s second to none.
Twelve years of hard work have paid off, with a strong global reputation and our solar pump inverters currently in use in more than 50 countries. XRISE products have passed tests from government engineers, NGOs, UNDP, UNHCR, UNICEF, OCHA, and ICRC in Asia, Africa and the Middle East, and their specifications and features have set the standard for solar pump system tenders in these countries.
Projects in Pakistan .
Pakistan is an energy-deficient country. A longstanding energy crisis has greatly subdued the country’s economic
growth, with billions of rupees in losses in the industrial and agricultural sectors alone.
Meanwhile, power consumption has been growing steadily, and an average annual increase of 7% has been forecast for the next four years. As a result of this power shortage, the agriculture sector has been facing acute irrigation water shortages – making our solar pumping system the optimal choice.
growth, with billions of rupees in losses in the industrial and agricultural sectors alone.
Meanwhile, power consumption has been growing steadily, and an average annual increase of 7% has been forecast for the next four years. As a result of this power shortage, the agriculture sector has been facing acute irrigation water shortages – making our solar pumping system the optimal choice.
Project Location | Gilgit Baltistan |
Application | Agriculture irrigation |
Head | 160 feet |
Daily Water Output | 1500 litres/min |
Running Time | 12 hours in Summer, 8 hours in Winter |
Full Load Time | 8 hours in Summer, 5 hours in Winter |
Module Type | 550w Solar Panel |
Solar Panels | 4 Strings, each string is 14pcs |
Solar Pump Inverter | JNP22KH-V5 |
Submersiblle Pump | 30HP |
Exhibition
Related Solar Pump Product
Single phase solar pump system 370w to 2.2kw
Solar pump inverter ranges from 370W, 550W, 750W, 1.1KW, 1.5KW, 2.2KW. Output can be both 220V-240V, 1/3 phase, 50/60Hz.
Solar pump inverter 3kw, 3.7kw 4kw output 220V-240V, 3 phase, 50/60Hz.
Three phase solar pump system 2.2kw to 7.5kw
Solar pump inverter ranges from 2.2KW, 3KW, 3.7KW, 4KW, 5.5KW, 7.5KW.
Input hybrid with solar and AC input.
Output 380-460V, 3 phase, 50/60Hz.
Three phase solar pump system
11kw to 18.5kw
Solar pump inverter ranges from 11KW, 15KW, 18.5KW.
Input hybrid with solar and AC input.
Output 380-460V, 3 phase, 50/60Hz.
Output 380-460V, 3 phase, 50/60Hz.
Three phase solar pump system
22kw to 55kw
Solar pump inverter ranges from 22KW, 30KW, 37KW, 45kw, 55kw.
Input hybrid with solar and AC input.
Output 380-460V, 3 phase, 50/60Hz.
Output 380-460V, 3 phase, 50/60Hz.
Three phase solar pump system
75kw to 132kw
Solar pump inverter ranges from 75KW, 90KW, 110KW, 132kw.
Input hybrid with solar and AC input.
Output 380-460V, 3 phase, 50/60Hz.
Output 380-460V, 3 phase, 50/60Hz.
Three phase solar pump system
160kw to 350kw
Solar pump inverter ranges from 160KW, 180KW, 200KW, 250kw, 300kw, 350kw.
Input hybrid with solar and AC input.
Output 380-460V, 3 phase, 50/60Hz.
Output 380-460V, 3 phase, 50/60Hz.
Solar DC Pumps and Acontroller
Solar DC pumps ranges from 180W upto 4kw. Support solar panels input and single phase 220V AC 50/60Hz（90-240Vac）electricity/generator input.
solar pump system can realize AC or DC input switching by operating a external knife switch.
solar pump system can realize AC or DC input switching by operating a external knife switch.
