Заводской запас 12 В 100 А/ч свинцово кислотная батарея глубокого цикла Лучшая цена лодки бытовая электроника 150 50 250 опции

Заводской запас 12 В 100 А/ч свинцово кислотная батарея глубокого цикла Лучшая цена лодки бытовая электроника 150 50 250 опции

Категория: >>>
Поставщик: Guangzhou Future Green Machinery Co. Ltd .Guangzhou .

Цена:78,00 $*

Количество:

В избранное

Описание и отзывы

Характеристики

Factory Stock 12V 100Ah Lead Acid Deep Cycle Battery Best Price Boats Consumer Electronics 150ah 50ah 250ah Sealed Options

1. Long battery life, high capacity, Superior recovery after discharge.
2. ABS material: Increase the strength of the battery container. (Flame-retardant ABS is optional)
3. High purity raw material: Ensure a low self-discharge rate.
4. Silver-coated copper terminals, brass insert terminals, and lead terminals improve the electric conductivity.
5. Pb CaSn alloy for plate grids: less gassing, less self-discharging high quality.
6. Maintenance-Free Operation
7. Low Self-Discharge

Product Description

T11 Terminal Brass Coated With Tin;
Threaded Insert 8mm STUD; Torque: 11~14.7 N*m

Specification

1. Functional Parameter			5. Environment Temperature
Nominal Voltage	12V	Discharge Temperature	-20~60ºC
Nominal Capacity (20 hour rate)	100Ah	Charge Temperature	0~50ºC
Number of Cells	6cells	Storage Temperature	-20~60ºC
2. Rated Capacity at 25ºC (77° F)			6. Inner Resistance & Max . Discharge Current
20 hour rate (0.1C, 10.8V)	100Ah	Fully Charged battery at 25ºC (77° F)	<7.5mΩ
5 hour rate (0.25C, 10.8V)	79.5Ah	Max. Discharge Current (7 min)	300A
1 hour rate (0.55C, 10.5V)	55.9Ah	Short Circuit Current (10 sec)	750A
3. Capacity affected by Temperature (20 hour rate)			7. Shelf Life at 25ºC (77° F)
40ºC (104° F)	103%	Capacity after 3 month storage	91%
25ºC (77° F)	100%	Capacity after 6 month storage	82%
0ºC (32° F)	85%	Capacity after 9 month storage	73%
-15ºC (5° F)	65%	Capacity after 12 month storage	64%
4. Dimension and Weight			8. Constant voltage charging at 25ºC (77° F)
Length	328mm	Cyclic use	14.4~14.9V
Width	172mm	Maximum charging current	30A
Height	215mm	Temperature compensation	-30mV/ºC
Total Height	220mm	Float use	13.6~13.8V
Reference Weight	30.0kg	Temperature compensation	-20mV/ºC

Similar Products

Model	Voltage	Capacity(20h)	Size(mm)	Plate Number	Weight(kg)
SM12V100Ah	12V	100Ah	307168208*227	66	28
SM12V120Ah	12V	120Ah	406174208*233	90	33
SM12V120Ah	12V	120Ah	406174222*238	78	34
SM12V134Ah	12V	134Ah	340.5173280(285)	66	36
SM12V145Ah	12V	145Ah	340.5173280(285)	78	40
SM12V150Ah	12V	150Ah	483170241*241	114	43
SM12V180Ah	12V	180Ah	532207215*240	126	52
SM12V200Ah	12V	200Ah	522240219*244	138	59
SM12V210Ah	12V	210Ah	522240219*228	150	61
SM12V260Ah	12V	260Ah	522268219*228	162	69

Production Process

Product packaging

Company Introduction

Certifications

FAQ

Q1: Are you factory?
A1: Yes, we are factory which located in Guangzhou, China.
Q2: How about the delivery time?
A2: 7 days for sample; about 15 working days for bulk order.
Q3: How to choose the right solar battery?
A3: Tell us your demands, then we will recommend suitable solar battery for you. Choosing solar batteries for your solar panel system can be a difficult task. There are many different types of solar battery technologies to choose from, and choosing the right solar battery will depend on what your needs are.
Q4: How to solve the technical problem?
A4: 24 hours after-service consultancy just for you and to make your problem to solve easily.
Q5: How to Ask for Support if product failure in a warranty?
A5: 1. Email us about the PI number, serial number, Product S/N number, show us more details such as Pictures, your testing report or video, if it is the quality problem of the product itself, we will resend a new one in the next order.
2. We will submit your case to our after-sales department, and solve it in 24 hours.
