Фабрика FEICHI 3 оси 45000l танк из углеродистой стали прицеп Топливозаправщик полуприцеп
10 500,00-12 500,00 $
Сохранить в закладки 1601292583462:
Outer size | 12.500x2.500x1.560mm | ||||
Tare Weight | 7000KG | Loading Capacity | 40T | ||
Semi trailer Frame | Main beam | Material | Carbon steel Q345 | ||
Height: 500mm, upper plate thickness is 14mm, Width 140mm;middle plate thickness is 6 mm; down plate thickness is 14mm,Width 14 0mm; | |||||
Floor thickness | The floor thickness is 3mm ,Material is Q235 carbon steel. | ||||
Twist Lock | 12 pcs | ||||
Running Mechanism | Axle | Type | 13T | ||
Number | 3 pcs | ||||
Rim | Type | 9.0-22.5 | |||
Number | 13 pcs | ||||
Tire | Brand | china brand | |||
Type | 12R22.5 | ||||
Number | 13 pcs | ||||
Suspension | Heavy Duty Mechanic Suspension with Leaf Springs | ||||
King pin | Type | Bolts type | |||
Diameter | 2 inch | ||||
Brake system | Brake valve | WABCO valve | |||
Air tank | 45L air tanks | ||||
Brake chamber | 6 double spring brake chamber | ||||
Landing gear | Brand | JOST Brand | |||
Type | 28 two speed | ||||
Accessories | Spare tire carrier | 2 pcs | |||
Light | LED light | ||||
Voltage | 24v | ||||
Receptacle | 7 ways(7wire harness)and quick change type | ||||
Tool box | One piece,900mm*600mm | ||||
Paiting | Polyurethane paint&anti-rust primer&sand blasting |
