Applications
1. Drain Water system;
2. Flood Protection and drainage;
3. Sewage Water Treatment;
4. Water treatment in pump stations;
5. Other industrial applications.
The Axial / Mixed Flow Submersible Pump can be installed vertically, horizontally, tilting.
3. Sewage Water Treatment;
4. Water treatment in pump stations;
5. Other industrial applications.
The Axial / Mixed Flow Submersible Pump can be installed vertically, horizontally, tilting.
Products Description
The Axial/Mixed flow submersible pump, which is a large flow low head water submersible pump, the motor driving the pump is submerged type fully enclosed three phase asynchronous submersible motor. The Axial /Mixed flow submersible pump and motor shaft
are integrated. Flexible installation, pumping clean water and sewage water. Especially for rain flood water, large capacity, longer service life. Convenience in operation, it is not necessary to lubricate the ruber bearing of pump prior to turning on the machine, in addition, remote control and automatic control are realized.
are integrated. Flexible installation, pumping clean water and sewage water. Especially for rain flood water, large capacity, longer service life. Convenience in operation, it is not necessary to lubricate the ruber bearing of pump prior to turning on the machine, in addition, remote control and automatic control are realized.
In order to solve the problem of different application scenarios and different pumping media, Our Axial/Mixed flow submersible pumps are available in Cast iron, Ductile cast iron, SS
304, SS 316, SS 316 L.
304, SS 316, SS 316 L.
Technical Parameters
Part of parameters, for reference only. Contact us for more information.
Model | Power | Flow range | Head range | Discharge Dia. | ||
QS Series | kw | hp | m3/h | m | mm | |
200QSZ-4.5-7.5KW | 7.5 | 10 | 450 | 4.5 | 200 | |
300QSZ-5.4-18.5KW | 18.5 | 25 | 800 | 5.4 | 300 | |
350QSZ-2.7-18.5KW | 18.5 | 25 | 1500 | 2.7 | 350 | |
350QSZ-5.4-30KW | 30 | 40 | 1250 | 5.4 | 350 | |
350QSZ-7.8-37KW | 37 | 50 | 1180 | 7.8 | 350 | |
400QSZ-4-30KW | 30 | 40 | 1600 | 4 | 400 | |
400QSZ-5.4-37KW | 37 | 50 | 1600 | 5.4 | 400 | |
500QSZ-4-40KW | 40 | 55 | 2000 | 4 | 500 | |
500QSZ-3.8-55KW | 55 | 75 | 2880 | 3.8 | 500 | |
500QSZ-8.2-65KW | 65 | 88 | 2160 | 8.2 | 500 | |
600QSZ-4-65KW | 65 | 88 | 3000 | 4 | 600 | |
600QSZ-3.5-75KW | 75 | 100 | 3200 | 3.5 | 600 | |
150QSH-15-11KW | 11 | 15 | 160 | 15 | 150 | |
150QSH-16-18.5KW | 18.5 | 25 | 260 | 16 | 150 | |
200QSH-10-11KW | 11 | 15 | 260 | 10 | 200 | |
200QSH-12-18.5KW | 18.5 | 25 | 350 | 12 | 200 | |
250QSH-5.5-11KW | 11 | 15 | 450 | 5.5 | 250 | |
250QSH-8-18.5KW | 18.5 | 25 | 450 | 8 | 250 | |
300QSH-12-25KW | 25 | 35 | 450 | 12 | 300 | |
250QSH-14-30KW | 30 | 40 | 450 | 14 | 250 | |
250QSH-16-37KW | 37 | 50 | 500 | 16 | 250 | |
300QSH-8-25KW | 25 | 35 | 750 | 8 | 300 | |
300QSH-10-30KW | 30 | 40 | 700 | 10 | 300 | |
300QSH-12-37KW | 37 | 50 | 750 | 12 | 300 | |
300QSH-16-45KW | 45 | 60 | 600 | 16 | 300 | |
350QSZ-9-37KW | 37 | 50 | 1000 | 9 | 350 | |
350QSZ-10-45KW | 45 | 60 | 1100 | 10 | 350 | |
350QSZ-15-65KW | 65 | 88 | 900 | 15 | 350 | |
350QSZ-13-75KW | 75 | 100 | 1200 | 13 | 350 | |
350QSZ-15-75KW | 75 | 100 | 1000 | 15 | 350 | |
400QSH-8-45KW | 45 | 60 | 1600 | 8 | 400 | |
Advantages
1. Installation methods: horizontal, vertical, tilting;
2. Big flow, non-clogging, fluids flowing easily;
3. The Pump and motor share the same shaft, improving rotor concentricity, less damage to shaft when pump working;
4. The impeller angle is adjustable, highly improve the flow adjusted range;
5. The motor adopts triple sealing structure, ensuring that there is no water leakage.
