Performance Indicators | YH-3400 | |||
YH-3400 W | YH-3400 B | YH-3400 G | ||
Before curing | Appearance | White | Black | Grey |
Relative density(g/cm3,25℃) | 1.55±0.05 | 1.55±0.05 | 1.55±0.05 | |
Surface drying time(min ,25℃) | 5~10 | 5~10 | 5~10 | |
Complete curing time(d, 25℃) | 1~2 | 1~2 | 1~2 | |
Curing type | Deethanol | Deethanol | Deethanol | |
After curing | Hardness(Shore A) | 40±5 | 40±5 | 40±2 |
Tensile strength (MPa) | 1.0±0.2 | 1.1±0.2 | 1.1±0.2 | |
Shear strength(MPa) | 1.0±0.2 | 1.1±0.2 | 1.1±0.2 | |
Elongation at break(%) | 100~150 | 100~150 | 100~150 | |
Peel strength(N/mm) | >5 | >6 | >6 | |
Using temperature range(℃) | -40~200 | -40~260 | -40~200 | |
Volume resistivity (Ω·cm) | ≥2.0×1016 | ≥2.0×1016 | ≥2.0×1016 | |
Dielectric strength(kV/·mm) | ≥16 | ≥16 | ≥16 | |
dielectric constant(1.2MHz) | 2.8 | 2.9 | 2.9 |
About The Statement
All product data in the store is the material that the company believes to be reliable after the test. Due to the difference in the use conditions, the product data cannot be the performance guarantee that the user must obtain. It is recommended that the user test and analyze the data and description before use. Do not guarantee any problems arising from the use of the product or the specific working conditions, and do not assume any responsibility for direct, indirect or accidental damage. If you have any questions or have problems during use, please contact us in time and we will be happy to help you.
