PRODUCT DESCRIPTION
Single Box Single Cell Cantilever Forming Traveler (CFT)
Single Box Single Cell Cantilever Forming Traveler(CFT) refers to the main beam of the bridge adopts a single box section to support and pour concrete. It is widely used in the construction of medium-span bridges, especially suitable for the suspension casting construction of continuous beams, T-frames, continuous rigid frames and cable-stayed bridges.
Single Box Single Cell Cantilever Form Traveler | ||||||||
Number of Rhombic Frame for One Pair | 4 PCS Per Pair | |||||||
Typical Span of Continuous Beam | 32+48+32m; 48+56+48m; 40+64+40m; 48+80+48m; 60+100+60m; 72+120+72m; 72+128+72m. | |||||||
Typical Length of Pier Table | 9m; 12m; 15m; 18m | |||||||
Heaviest Cantilever Beam Girder in Tonnage | About 90-200T | |||||||
Cantilever Pouring Length | 3-5m | |||||||
Material | Q235B, Q355B Steel. | |||||||
Standard Configuration | Main truss, walking system, suspension system, bottom support system, formwork system | |||||||
Options | Protection system (bottom support protection, full facade protection), hydraulic system, suspension accessories | |||||||
RELATED PRODUCTS
WHY CHOOSE US
Why selecting Boyoun CFT?
1. Simple structure and standardized design.
2. Main nodes are connected by pins, facilitating easy assembly and disassembly, and saving time and labor resources.
3. Ensure safety through Midas modeling and force calculation.
4. Light weight and can move flexibly and smoothly.
5. High stiffness and small deformation.
6. Standardization rate exceeds 90%, demonstrating high versatility.
2. Main nodes are connected by pins, facilitating easy assembly and disassembly, and saving time and labor resources.
3. Ensure safety through Midas modeling and force calculation.
4. Light weight and can move flexibly and smoothly.
5. High stiffness and small deformation.
6. Standardization rate exceeds 90%, demonstrating high versatility.
CERTIFICATIONS AND HONORS
COMPANY PROFILE
Introduction of Shandong Boyoun Industries Co., Ltd.
Shandong Boyoun Heavy Industries Co., Ltd, founded in 2006, is committed to supplying a wide range of formwork for bridge, viaduct and tunnel engineering. The headquarter and main factory are located in Binzhou city of Shandong China, with International Department located in Beijing.
The annual output is more than 75,000 tons, Boyoun has been qualified by ISO QM System since its foundation. More than 30 patents have been approved each year. Main products cover: Cantilever Form Traveller, Underslung Form Traveler, Precast Segmental Box Girder Formwork, PC I shape T shape U shape Girder Formwork, Tunnel Lining Trolley, Pier formwork, etc. Besides supplying the formwork, customized services like technical proposals, on-site installation supervision, buying back and rental service can be also provided by Boyoun.
Replying on advanced processing machines, such as laser cutter and automatic welding robot, Boyoun has completed over 1,200 projects Worldwide,including China-Maldives Friendship Bridge in Maldives, Padma Bridge and BRT Dhaka in Bangladesh, Pulau Balang Cable Stayed Bridge and Kendari Cable Stayed Bridge in Indonesia, East Coast Railway in Malaysia, Malaysia MRT 2 and LRT 3, BGC-Ortigas Bridge in Philippines, No.6 Expressway and Tha Chin River Bridge in Thailand, North-South Corridor Project in Singapore, etc.
Painting Workshop
Ready for Painting
Welding Workshop
DELIVERY
FAQ
Q1. How to connect large rods?
It is simple and convenient to assemble large rods using bolt connections.
Q2. What material is used for the rear anchor of the form traveler?
The rear anchorage of the form traveler is made of precision-rolled rebar, which has clear stress and a safe and reliable
structure.
structure.
Q3. What are the characteristics of the single box single cell cantilever form traveler?
The characteristics of the single box single cell cantilever form traveler mainly include: simple structure, clear force, light
weight, complete structure, easy operation, safety and reliability, etc. At the same time, it also has high construction
efficiency, can shorten the construction period and reduce project costs.
weight, complete structure, easy operation, safety and reliability, etc. At the same time, it also has high construction
efficiency, can shorten the construction period and reduce project costs.
