Брикетировочная машина из биомассы с основным компонентом двигателя для брикетирования рисовой шелухи

Описание и отзывы

Характеристики

Welcome! Discover China's Superior Mechanical MasterpieceQuality, Design, and Efficiency Await Come Explore!

NEXT I WILL INTRODUCE THE MECHANICAL DETAILS TO YOU

TOP"Global Favorite Procurement Product"TOP

Ball Press Machine Is Also Called: Strong Ball Press Machine, Mineral Powder Ball Press Machine, Roller Ball Press Machine, Dry Powder Ball Press Machine, Goose Egg Molding Machine, Etc. Ball Press Machine Is Mainly Used for Making Balls and Blocks of Non-Ferrous and Black Metal Mineral Powder Directly Entering the Furnace for Smelting, Improving Added Value. All Waste Materials and Auxiliary Materials in Metallurgical Industry Need to Be Put on the Furnace, Which Need to Be Completed by Ball Press Machine. For Example, Dust Removal, Pool Mud, Oxide Scale, Steel Slag, Iron Concentrate Powder, Aluminum Ash Powder Silicon Manganese Ore Powder, Etc.
Ball Press Machine Can Be Used to Suppress Various Powders, Powders, Powders, Such as Pulverized Coal, Iron Powder, Coking Coal, Aluminum Powder, Iron Filings, Scale Oxide, Carbon Powder, Carbon Powder, Slag, Gypsum, Tailings, Sludge, Kaolin, Activated Carbon, Coke Powder, Etc Waste and Waste Residue Are Widely Used in Refractory Materials and Electricity. Plant, Metallurgy, Chemical Industry, Energy, Transportation, Heating and Other Industries, after Ball Press Machine Production and Molding Materials, Energy Saving and Environmental Protection, Convenient Transportation, Improve the Utilization Rate of Waste, It Has Good Economic and Social Benefits.

Briquette Ball Press Machine Structure
The Feeding Part Is Mainly to Realize Quantitative Feeding to Ensure That the Materials Enter the Pairs Evenly. The Screw Feeding Device Is Driven by Electromagnetic Speed Control Motor and Rotates through the Pulley and Worm Reducer to Force the Pressed Material into the Main Feeding Port. Due to the Constant Moment Characteristic of Electromagnetic Speed Control Motor When the Amount of Material Pressed by Spiral Feeder Is Equal to the Amount of Material Required by the Host, the Constant Feeding Pressure Can Be Maintained to Stabilize the Mass of the Pellet. If the Feeding Amount Is Too Large, the Electric Overload of the Feeding Device: If the Feeding Amount Is Too Small It Will Not Be a Ball. Therefore, Skilled Operation Is an Important Condition to Ensure the Normal Operation of Pigeonhole Ball.
2. for the Transmission Part, the Main Transmission System Is: Motor-Triangle Belt-Reducer... -Open Gear... -Roll. The Main Engine Is Powered by Electromagnetic Speed Control Motor and Transmitted to Stick Pin through Driving Shaft Coupling through Pulley and Cylindrical Gear Reducer. Driving Shaft and Passive Shaft Ensure Synchronous Operation through Open Gear. Hydraulic Device Is Installed behind the Passive Bearing Seat. The Hydraulic Protection Device Drives High-Pressure Oil into the Hydraulic Cylinder by the Hydraulic Pump, Causing Axial Displacement of the Piston. The Front Connector of the Piston Rod Is Topped on the Bearing Seat to Meet the Production Pressure Requirements. 3. the Molding Part Mainly Refers to the Host Part, and the Core Part Is Roll. When the Feed between the Two Pressures Is Too Much Or Enters Derby, the Hydraulic Cylinder Piston Rod Is Overloaded, the Hydraulic Pump Will Stop, Energy Accumulator Will Buffer the Pressure Change, and Relief Valve Will Open the Oil Return,: the Displacement of the Piston Rod Makes the Gap between the Pressure Rollers Plus-Sized So That Hard Objects Can Pass through the Pressure Rollers, and the System Pressure Returns to Normal, Which Can Protect the Pressure from Damage. This Machine Can Adjust the Pressure According to the Requirement of Pigeonhole Ball Density, and the Production Is Flexible and Flexible.

You Can Contact Us OEM Customized

MINE OVERALL SOLUTION PROVIDER
