Products Description
Hydrogen Application
1. 0-4L hydrogen production and charging integrated equipment is a system that integrates proton exchange membrane (PEM) and electrolyzes pure water to produce high-purity hydrogen. The water circulation system is used to send deionized water that meets the requirements into the electrolyzer for electrolysis to form hydroxide anions and hydrogen ions. Hydroxide anions release electrons at the anode to form oxygen and carry part of the water into the water tank, and the oxygen is exhausted from the water tank by the oxygen exhaust pump. Hydrogen ions obtain electrons at the cathode to form hydrogen, and after gas-water separation, hydrogen with a maximum pressure of 1.6Mpa is obtained. The system includes the development and implementation of hydrogen production systems including electrolyzers, including but not limited to electrolyzers, power supply facilities, gas-liquid separation facilities, hydrogen purification facilities, PLC control facilities, etc. Complete set of technical utility engineering auxiliary system design, including but not limited to energy management system, instrument air system, auxiliary system power supply, etc. Specific equipment includes: circulating water pump, water-gas separator, gas dryer, valve and pipeline components, constant current power supply, control panel and control system, safety system, etc.
2. It has the function of hydrogen gas-liquid separation and processing, and the liquid level is automatically drained when it approaches the threshold;
3. It has the function of remote monitoring, automatic system control, and 24-hour unmanned safe dynamic operation;
4. The operating conditions can be freely edited, or prefabricated conditions can be selected;
5. Power supply output voltage, current, power monitoring and protection;
6. It has temperature and pressure monitoring and protection;
7. It has the function of alarming and processing abnormal conductivity of circulating water;
8. The purity of hydrogen produced by ultra-pure hydrogen is greater than 99.99%; the hydrogen production pressure can reach 1.6Mpa;
2. It has the function of hydrogen gas-liquid separation and processing, and the liquid level is automatically drained when it approaches the threshold;
3. It has the function of remote monitoring, automatic system control, and 24-hour unmanned safe dynamic operation;
4. The operating conditions can be freely edited, or prefabricated conditions can be selected;
5. Power supply output voltage, current, power monitoring and protection;
6. It has temperature and pressure monitoring and protection;
7. It has the function of alarming and processing abnormal conductivity of circulating water;
8. The purity of hydrogen produced by ultra-pure hydrogen is greater than 99.99%; the hydrogen production pressure can reach 1.6Mpa;
Modle | HL-2000 |
Output Flow Rate (ml/min) | 0-2020 |
Output Pressure (MPa) | 2 |
Purity of Hydrogen (%) | >99.999 |
Pressure Value for Overpressure Protection (MPa) | 0.46 |
Power Voltage (V) | 220±15%V 50～60Hz |
Input Power (W) | < 1000 |
Net Weight of a Complete Set (Kg) | < 30 |
Dimension (L*W*H)(mm) | 500×400×480 |
Company Profile
Hunan Moreshine is a subsidiary of Okay Energy Equipment,aiming at providing high-tech laboratory and energy saving gas generation equipments. With the 15years of company development,Hunan Moreshine has been independent as a integrated water treatment machine manufacturer since 2020,which is specializing in the production of laboratory ultrapure water machine, medical water machine,watersoftener and other related water treatment equipment. Our 2000 squre meters factory and sales office is located in Xinggong International Industrial Park in Changsha City.There are complete before and after sales service network all over the country.
With ISO 9001:2015 and CE certification, amazing technical staff, a comprehensive business network and timely after-sales services, our company has been widely recognized and exported to the world market,such as UK, Australia, Mozambique, Kuwait,Malaysia, Thailand and etc. Focusing on pure and ultrapure water solution for over 10 years,Hunan Moreshine is the best choice for tens of thousands of users.
With ISO 9001:2015 and CE certification, amazing technical staff, a comprehensive business network and timely after-sales services, our company has been widely recognized and exported to the world market,such as UK, Australia, Mozambique, Kuwait,Malaysia, Thailand and etc. Focusing on pure and ultrapure water solution for over 10 years,Hunan Moreshine is the best choice for tens of thousands of users.
Paking & Shinpping
FAQ
Q1 :What's the delivery time after an order placed?
A1 :Our standard delivery is 3-7days if we have stock, otherwise we will let you know in time.
Q2 :What is your term of delivery?
A2 :We accept EXW, CIF, FOB Shenzhen / Guangzhou/ Shanghai or any other ports of China. You can choose the one which is the most convenient or cost effective for you.
Q3 :What about the lead time for the mass production?
A3 :It depends on the order quantity and the time you place the order.
Q4 :Can I use my own forwarder ?
A4 :Of course you can. If you have your own forwarder, we can send the goods to your forwarder according to your requirement.
Q5:Language?
A5:Pure English operation panel, display, manuals; installation&operationvideo will be provided to you as guidance.
A1 :Our standard delivery is 3-7days if we have stock, otherwise we will let you know in time.
Q2 :What is your term of delivery?
A2 :We accept EXW, CIF, FOB Shenzhen / Guangzhou/ Shanghai or any other ports of China. You can choose the one which is the most convenient or cost effective for you.
Q3 :What about the lead time for the mass production?
A3 :It depends on the order quantity and the time you place the order.
Q4 :Can I use my own forwarder ?
A4 :Of course you can. If you have your own forwarder, we can send the goods to your forwarder according to your requirement.
Q5:Language?
A5:Pure English operation panel, display, manuals; installation&operationvideo will be provided to you as guidance.
