H-лучевой сварочный робот сварочная ячейка рабочая станция: позиционер пешеходная дорожка Китай фабрика поддерживает настройку
3 000,00-3 200,00 $
Китайский производитель прецизионных автоматизированных сварочных роботов рабочих станций для тяжелой стальной сварки
- Категория: >>>
- Поставщик: Jinan Guansen Automation Equipment Co. Ltd.Jinan Ltd.
Сохранить в закладки 1601299955175:
Описание и отзывы
Характеристики
Product Paramenters
Type | Single Axis Positioner with Adjustable Tailstock | ||
Model | AUT-SWP-ZW-500-WT | AUT-SWP-ZW-1000-WT | |
Rated payload | 500kg((Axis radius≤R400mm) | 1000kg(Axis radius≤R800mm) | |
Standard radius of gyration | R650mm | R900mm | |
Maximum load eccentricity | ≤150mm | ≤200mm | |
The height of clamping | ≤300mm(Over 300mm ,the bob-weight will increase with the actual load) | ≤450mm(Over 450mm ,the bob-weight will increase with the actual load) | |
Maximum angle of gyration | ±360° | ±360° | |
Rated speed of gyration | 50°/S | 50°/S | |
Repeat positioning accuracy | ±0.08mm( At =R400mm) | ±0.12mm (At R=800mm) | |
Adjustable travel of the tailstock | 0-3000mm | 0-5000mm | |
Adjustment method of the tailstock | Electric control/manual control | Electric control/manual control | |
Positioner dimension(L*W*H) | 4000mm*700mm*1050mm | 6200mm*850mm*1500mm | |
Height of gyration center | 830mm | 1050mm | |
Equipment net weight | About 600kg | About 1600kg | |
Product Lineup
Product Lineup
Robot peripheral supporting equipment
Standard servo welding positioner
Standard robot welding track
Robot integrated workstations and production lines for welding, cutting, handling, forging, casting, machining, painting, etc.
Peripheral safety protection smoke removal system and other supporting equipment.
Non-standard CNC welding machines, CNC cutting machines and other automatic welding cutting equipment.
※The specifications of non-standard welding positioner and walking track can be customized .
Robot peripheral supporting equipment
Standard servo welding positioner
Standard robot welding track
Robot integrated workstations and production lines for welding, cutting, handling, forging, casting, machining, painting, etc.
Peripheral safety protection smoke removal system and other supporting equipment.
Non-standard CNC welding machines, CNC cutting machines and other automatic welding cutting equipment.
※The specifications of non-standard welding positioner and walking track can be customized .
WELDING POSITIONER
The welding positioner is an auxiliary device for industrial welding robots, which can greatly improve the work efficiency of welding robots. The positioner is suitable for welding and cutting complex workpieces to achieve ideal machining positions and speeds.
TYPE:Single Axis Horizontal Servo Positioner
Company Profile
Jinan Guansen Automation Equipment Co., Ltd
Jinan Guansen Automation Equipment Co., Ltd is located in Jinan, Shandong, China. As a high-tech enterprise, we focus on integrating research and development, design, production, and sales of various types of automation equipment. The company is committed to manufacturing professional industrial peripheral equipment and non-standard automation equipment. The products are widely used in construction machinery, locomotive vehicles, automobile manufacturing, ship heavy industry, petrochemical equipment, power engineering, coal machinery, heavy machinery and other industries.
Certifications
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
1. Q: Is your company a manufacturer?
A: Yes, we have our own factory in Jining City and our own foreign trade company in Jinan City. We are a company that integrates factory and foreign trade.
2. Q: What is the quality of the company's products?
A: The company's products have been produced in China for over 10 years and have cooperative relationships with multiple trading companies. Our products are exported to various parts of the world.
3. Q: Does the product support personalized customization?
A: Products can be personalized and customized according to the actual needs of customers. Customizable content includes: specifications, colors, logos, etc.
4. Q: What are the transportation and packaging methods?
A: We will use wooden boxes for packaging, and the transportation method can be negotiated and arranged for shipment.
A: Yes, we have our own factory in Jining City and our own foreign trade company in Jinan City. We are a company that integrates factory and foreign trade.
2. Q: What is the quality of the company's products?
A: The company's products have been produced in China for over 10 years and have cooperative relationships with multiple trading companies. Our products are exported to various parts of the world.
3. Q: Does the product support personalized customization?
A: Products can be personalized and customized according to the actual needs of customers. Customizable content includes: specifications, colors, logos, etc.
4. Q: What are the transportation and packaging methods?
A: We will use wooden boxes for packaging, and the transportation method can be negotiated and arranged for shipment.
Accepted Delivery Terms: FOB, EXW
5.Q: What after-sales service can you provide?
A: We provide complete technical support and a one-year warranty.
5.Q: What after-sales service can you provide?
A: We provide complete technical support and a one-year warranty.
