Product Description




Strict inspection principle

* Self inspection
* Mutual inspection
* Special inspection

Strict inspection procedure

* Raw materials inspection
* Parts inspection
* assembly inspection





Main Features


1).Remove the thorn, fine polish, and prevent the handle

2).All our equipment use brand motor(18 months warranty) and bearing.

3).Screen frame, medical grade using double-sided 8K mirror panel, smooth, high cleanlines.

4).The reinforced rubber spring has good elasticity, uniform vibration force and good stability.

5).Swift locking device, easy to operate for cleaning, suitable for food, medicine and other industries.

6).Input reasonable designing, avoid the raw materials outflow.

7).Beam ring buckle with reinforced head, safer, longer life, less deformation, high strength.

8).Output part, the whole plate data cutting, blanking, more solid, good appearance







Technical Parameter


Model
Power(kw)
Valid Diameter of screen(mm)
Volume(mm)
Layers
DY-600-1S
DY-600-2S
DY-600-3S
0.55kw
550mm
800*800*680
800*800*780
800*800*880
1
2
3
DY-800-1S
DY-800-2S
DY-800-3S
0.75 kw
750mm
900*900*780
900*900*930
900*900*1080
1
2
3
DY-1000-1S
DY-1000-2S
DY-1000-3S
1.1 kw
950mm
1160*1160*880
1160*1160*1030
1160*1160*1180
1
2
3
DY-1200-1S
DY-1200-2S
DY-1200-3S
1.5 kw
1150 mm
1360*1360*980
1360*1360*1160
1360*1360*1360
1
2
3
DY-1500-1S
DY-1500-2S
DY-1500-3S
2.2 kw
1450mm
1850*1850*1130
1850*1850*1330
1850*1850*1550
1
2
3
DY-1800-1S
DY-1800-2S
DY-1800-3S
3 kw
1750mm
2200*2200*1360
2200*2200*1460
2200*2200*1680
1
2
3




Detailed Images


Machine Parts

Name: vibration motor

Brand: Dayong

Original: China

Motor, wire package is all copper group winding, winding line after dipping paint, vacuum dip paint, insulation good.
The motor shell is made of ball milling cast iron and aluminum shell, all aluminum is fast and light in weight



Main Features

Name: Screen

Brand: Dayong

Original: China

Fully screen with all wonderful parts, ASTM standard sieve mesh size, mother sieve support design, adding the sieve using life, solid screen frame, food grade pu ring and bonucing balls.




Machine Parts

Name: Welding


Brand: Dayong


Original: China


Domestic famous  welding draft, good appearance



Main Features

Name: Input view


Brand: Dayong


Original: China


flexible input design, could be designed according to your working site, greatly improve the working effencicy.





Notice:

Our machine could use any industrys.(powder/particles,liquid).
Please tell me your raw material details, we will provide you the suit model.
If you want to know the sieving effencicy, we can test the machine before you place a order
We promise to save your working cost, and bring benefits to you.



Packing & Delivery


Delivery
production
7 days
Delivery
1-2 days



Remark
Actual delivery time will be a little different if you need special design solutions.


Certifications




Our Company


Xinxiang Dayong Vibration Equipment Co., Ltd.

Xinxiang Dayong Vibration Equipment Co., Ltd. is a international manufacturing factory with research and development, design, production and sales services, it is committed to provide customers with reasonable screening, conveying and crushing equipment design solutions.

The company have more than 100 employers, and setted with R & D, technology and other departments, of which graduate students, college education accounted for more than 80%.

The company is located in Henan, Xinxiang province. The main products are divided into: Fine screening equipment; Mining screen equipment;

Conveyor equipment;Crusher. etc.)


The pruducts has passed the ISO9001 quality system and CE certification, and all the equipment fittings are famous brand in China.

The equipment is not only popular in China and have been exported to the United States; Russia; Australia;  Britain; Spain; Germany; Japan; Holland;  Poland; Turkey; Oman; Philippines; Thailand; Indonesia; Singapore and other countries and regions.





Our Service


Pre-Sales Service

*Customer consultant 24 hour online
*Engineer team provide design drawing
*Skilled staff responsible for production
*Take pictures for all Production process

After-Sales Service

*Provide installation instruction
*Solve any problems involved
*Tell the machinery maintain guidance
*Regular monthly sales tracking
