Сельскохозяйственная радиостанция Farlink H6 C10 контроллер визуальной съемки инженерное строительство Rtk Gps Gnss приемник Kolida K6
295 260,50-318 881,34 ₽
Дешевая продажа Подержанный South G6 G1 PLUS Gps Rtk геодезический инструмент Gnss приемник Galaxy G2 G3 G4 G9
- Категория: >>>
- Поставщик: Jining Dingsheng Surveying And Mapping Instrument Co. Ltd.Jining Ltd.
Сохранить в закладки 1601318076660:
Описание и отзывы
Характеристики
Surveying Performance SOUTH G1 PLUS | ||
Channel | 336 Channels | |
Signal Tracking | BDS B1, B2, B3, | |
GPS L1C/A, L1C, L2C, L2E, L5 | ||
GLONASS L1C/A, L1P, L2C/A,L2P, L3 | ||
SBAS L1C/A, L5( Just for the satellites supporting L5 ) | ||
Galileo GIOVE-A, GIOVE-B, E1, E5A, E5B | ||
QZSS,WAAS, MSAS, EGNOS, GAGAN, SBAS | ||
GNSS Feature | Positioning output rate: 1HZ~50HZ | |
Initialization time : <10s | ||
Initialization reliability : | ||
Initialization reliability: >99.99% | ||
Positioning Precision | ||
Code Differential GNSS Positioning | Horizontal: 0.25 m + 1 ppm | |
Vertical: 0.50 m + 1 ppm | ||
SBAS positioning accuracy: typically<5m 3DRMS | ||
Static GNSS Surveying | Horizontal: 2.5 mm + 0.5 ppm | |
Vertical: 5 mm + 0.5 ppm | ||
Real-Time Kinematic Surveying (Baseline<30km) | Horizontal: 8 mm + 1 ppm | |
Vertical: 15 mm + 1 ppm | ||
Horizontal: 8 mm + 0.5 ppm | ||
Vertical: 15 mm + 0.5 ppm | ||
Network RTK | RTK initialization time: 2~8s | |
Physical | ||
Dimension | 15.2cm × 13.7cm | |
Weigh | 1.44kg (including battery) | |
Material | Magnesium aluminum alloy shell | |
Environmental | ||
Operating | −45℃~+60℃ | |
Storage | −55℃~+85℃ | |
Humidity | Non-condensing | |
Waterproof/Dustproof | IP67 standard,protected from long time immersion to depth of 1m | |
IP67 standard,fully protected against blowing dust | ||
Shock and Vibration | Not operating: Withstand 2 meters pole drop onto the cement ground naturally | |
operating : Withstand 40G 10milliseconds sawtooth wave impact test | ||
Electrical | ||
Power consumption | 2W | |
Battery | Rechargeable, removable Litium-ion battery | |
Battery Life | Single battery: 7h( static mode ) 5h( interual UHF base mode ) | |
6h( rover mode ) | ||
Communications and Data storage | ||
I/O Port | 5PIN LEOM external power port + RS232 | |
7PIN LEOM RS232 + USB | ||
1 network/radio data link antenna port | ||
SIM card slot | ||
Wireless Modem | Integrated internal radio receiver and transmitter 0.5W/2W | |
External radio transmitter 5W/25W | ||
Working frequency | 410-470MHz | |
Communication protocol | TrimTalk450s, TrimMark3, PCC EOT, SOUTH | |
Cellular Mobile Network | WCDMA3.5G network communication module, GPRS/EDGE compatible, | |
CDMA2000/EVDO | ||
3G optional | ||
Double Module | support for android, ios cellphoon connection | |
EDR standard | ||
NFC communication | Realizing close range ( shorter than 10cm ) automatic pair between | |
Galxy G1 and controller | ||
( controller equipped NFC wireless communication module needed) | ||
Data storage/Transmission | 4GB internal storage, more than 3 year raw observation data (1.4M/day) | |
base on recording from | ||
14 satelites Plug and play more of USB data transmission | ||
Data Format | Differential data format: CMR+, CMRx, RTCM2.1, RTCM2.3, RTCM3.0, | |
RTCM3.1, RTCM3.2 | ||
GPS output data format: NMEA0813, PJK plan, cordinates binary code | ||
Network model support: various, FKP, MAC, supporting NTRIP protocol | ||
Intertial Sensing System | ||
Tilt survey | Built-in tilt compensator, correcting coordinates automaticlly according to the | |
tilt direction and angle of the centering rod | ||
Electornic Bubble | Conteroller software display electronic bubble, checking leveling status of | |
the centering rod real time | ||
User Interaction | ||
Buttons | One-button operation, Visual operation, convenient and efficient | |
