Pavement width of 2.5m to 6.0m and flexibility of transition of tire paver, fully hydraulic four-wheel drive, continuously variable, with Cummins engine (93kw/2200rpm), hydraulic system using electro-hydraulic proportional control Technology, independent transmission and distribution drive, so that the power output is efficient, 13t hopper design is large, the new compact left and right independently drive the delivery bin, the distribution device can be easily moved up and down to adapt to different paving thickness, reduce the material segregation, electricity The control system design is based on the CAN bus technology. The automatic leveling device can be used to control the paving thickness and slope accurately. The vertical flatness can reach 3mm/3m and the transverse gradient is within 0.02%.
FEATURES AT A GLANCE
PRODUCT SPECIFICATIONS
Item
Unit
VSRP6000L
Traveling type
Rear wheel drive
Basic paving width
m
2.5
Max. paving width
m
6
Max. paving thickness
mm
150
Working Speed
m/min
0-11
Traveling speed
km/h
0-11
Theoretical productivity
t/h
400
Hopper capacity
t
12
Gradeability
%
≥20
Flatness deviation (longitudinal wave)
mm/3m
2
Transverse wave deviation
%
±0.02
Degree of adjustment
%
-1~+3
Manufacturer
Dongfeng Cummins
Model
QSB3.9-C125
Fuel tank capacity
L
116
Rated power
kW
93
Rated speed
rpm
2200
Electric system
V
24
Emission
State Ⅲ
Screed type
Hydraulic
Telescopic range
m
2.5~4.5
Compaction type
Single
Compaction frequency
HZ
25
Compaction amplitude
mm
5
Vibration frequency
HZ
40
Heating type
Diesel
Length
mm
6290
Width (Basic)
mm
2690
Height (Cabin)
mm
3650
Transport height
mm
3000
Weight
t
16(1±5%)
PRODUCT CONFIGURATION
CHANGCHAI high power engine
Imported EATON control valve
Japan Shimadzu hydraulic motor
SALES AND SERVICE NETWORK
Successful Project
Recommand Products
Earthmoving Machinery
Piling Machinery
Road Machinery
Concrete Machinery
Heavy-duty Machinery
Warehousing Logistics Machinery
Company Profile
FAQ
Q1: Where your products have been exported before?
A1: Our products have been sold to Asia, Africa, South America, middle East,Europe and so on.
Q2: What about the payment method?
A2:T/T, L/C is available
Q3: What about after-sale service?
A3:12 months warranty for all kinds of products.
We provide one-stop solution for the world’s foundation construction users. While providing customized quality products, our services will leave you with no worries. We boast a group of experienced foundation construction experts and consultants, who not only recommend the use of suitable products based on customer needs, but also give reasonable advice on the operation of construction equipment and construction methods.
