Промышленное электрическое Двухслойное 316 из нержавеющей стали VBJX ротационное вибрационное сито оборудование для просеивания

Сохранить в закладки 1601331805504:


Цена:124 599,07-137 313,26 ₽*

Количество:

  • В избранное

Описание и отзывы

Характеристики



Product show


VBJX Stainless Steel Electric Vibrating Screen Sifter Machine
S49 -B Rotary vibration screen is a kind of high-precision screening machinery, its low noise, high efficiency, fast change the screen(3-5 minutes), fully closed structure, suitable for particles, powder, liquid and other materials classification, filtration and removal of impurities.
Working Principle:
Rotary vibration screen is made of an upright motor as a source of vibration, the motor is installed at the upper and lower ends of the eccentric heavy hammer, the motor rotation motion into horizontal, vertical, oblique three-dimensional motion, and then the motion to the screen surface. Adjust the phase Angle of the upper and lower ends to change the motion track of the material on the screen surface.




customer installation site










Product details



Structural design
The structure design is reasonable and the material is excellent.
The opening direction and the number of discharge ports can be designed according to customer requirements, and the machine material can be selected according to the requirements of carbon steel or high-quality 304/316 stainless steel.



Equipment surface treatment
Internal and external mirror surface polishing, leaving no dead angle.
According to customer requirements, spray painting, sand blasting and other processing methods can also be used.



Screen
The screen mesh is made of high quality 304 stainless steel, screening size can be customized according to customer
requirements.


Vibration motor
VBJX rotary vibrating screen uses world famous brand motor --OLI motor, more durable, maintenance free, CE certification.


Screen cleaning device
According to the characteristics of the material, choose different screen cleaning device: bouncing ball or ultrasonic
generator.






Technical Parameters


Model
Diameter
(mm)
Deck
Screen mesh area
(mm)
Mesh size
(mesh)
Max particle size
(mm)
Power(kw)
S494-B
Φ400




1-5
Φ380
3-500
<20
0.25
S496-B
Φ600
Φ600
3-500
<20
0.6
S498-B
Φ800
Φ750
3-500
<30
0.6
S4910-B
Φ1000
Φ900
3-500
<30
0.8
S4912-B
Φ1200
Φ1100
3-500
<30
1.5
S4915-B
Φ1500
Φ1450
3-500
<50
2.2
S4918-B
Φ1800
Φ1750
3-500
<50
2.5
S4920-B
Φ2000
Φ1950
3-500
<60
2.5


Applied range




1.Chemical industry: resin pigment, calcium carbonate, decorative coatings, medicine, grease, paint, palette, etc.
2.Abrasive material and ceramic industry: building sand, mica, alumina, silica sand, abrasive, refractory material, slurry, etc.
3.Food industry: sugar, salt, alkali, flour powder, nut powder, whey protein powder , maltodextrin , flavors , sucralose , xanthan gum, soy lecithin ,farina, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice, etc.
4.Paper-making industry: coated slurry, exhaust liquid, paper making liquid and waste water reclamation, etc.
5.Metallurgy and mining industry: quartz sand, sand, ore, titanium oxide, zinc oxide, etc.
6.Mechanical industry: casting sand, charcoal, grafito, powder metallurgy, electromagnetic material and metal powder, etc


Our Advantages


1. High efficiency screening: rotary vibrating screen screening efficiency is high, can quickly separate different particle sizes of materials, suitable for industrial production in large quantities ‌.
2.large capacity: rotary vibrating screen can handle a large number of materials, suitable for chemical industry, food, medicine and other industries ‌.
3.high precision: the rotary vibrating screen has high screening precision and can meet the screening requirements of different particle sizes ‌.
4.wide screening range: rotary vibrating screen can adapt to different particle sizes of material screening, suitable for a variety of industries ‌.
5.high reliability: rotary vibrating screen is made of high quality materials, has high wear resistance and corrosion resistance, and stable and reliable operation ‌.




Company Profile




Henan Vibrate Machinery Equipment Co., Ltd.
1.With 36 years of professional production of rubber, food, medicine, chemical and mineral equipment experience, and has a good cooperative relationship with the world 500.
2.All raw materials purchased with domestic and foreign well-known manufacturers.
3.We have designed production lines for many companies, such as cosmetics production line ,clove production line, blue bubble production line, flour production line, yeast production line, detergent production line,etc.
4.1 Years Warranty, 14 Days Delivery, Factory Price.
5.14800㎡ factory, Own R&D Team.
6.Free design service, free professional solutions.
7.Passed ISO9001, CE, SGS, Intetek certificates.
8.Provide complete transportation service and after-sales service.

Pre-Sales Service
* Inquiry and consulting support.
* Free solutions .
* View our Factory.
* Make plans for choice according to the needs and special requirements of users in different sectors .

After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
* Establish long-term and friendly relationship.




Certifications




FAQ


1.How we control our quality?
Products are designed by technicians and engineers to ensure the quality of product structure design; Product parts and raw materials are purchased from famous brand manufacturers, the machine is produced by the company's own factory, and the design and quality inspection personnel are strictly checked to ensure that the product is strong and durable, and each machine is arranged to test the process before leaving the factory to ensure product quality.

2.How we fufil our service?
Our company provides perfect pre-sales and after-sales service, all sales staff have a high level of professional knowledge, can quickly solve customer problems, for the sake of customers, anticipate customer needs in advance, ‌ take the initiative to solve problems for customers, and cooperate with technical personnel to put forward professional personalized solutions and drawings.

3.How do we do after-sales service?
We provide on-site installation service, if the machine fails, we will provide professional technical support such as remote
technical support, on-site technical support, training, etc, the specific way needs to be determined according to the nature of the problem and customer needs. Communicate with customers frequently, understand the use of products, find problems and solve them in time. Regular maintenance of sold products, provide professional maintenance personnel and equipment.

4.How we support our agent?
To provide dealers with high quality, innovative or distinctive products, timely addition of new products, replace the old
products. Provide technical training, systematic training of product technology and marketing strategies, help dealers improve sales and management capabilities, provide higher rebate levels to excellent dealers, and face problems together with a win-win attitude.
