NSK высокое качество 6306DDU шаровой подшипник с глубоким пазом Однорядный бесплатный образец поставка 2RS ZZ уплотнения C3 Клиренс ресторанная печать
117,43-119,80 ₽
Поставка от производителя микро подшипник качения скользкий колеса NTN 62214 2RS1 радиальные шарикоподшипники
- Категория: >>>
- Поставщик: Timson Power Technology (shanghai) Co. Ltd.Timson Ltd.
Сохранить в закладки 1601332342493:
Описание и отзывы
Характеристики
Product Description
The NTN 62214-2RS1 is a deep groove ball bearing designed to handle both radial and axial loads. It is equipped with rubber seals on both sides (indicated by 2RS1) to protect the internal components from contamination and ensure better lubrication retention.
Key Features:
Type: Deep groove ball bearing
Seals: 2RS1 indicates that the bearing has rubber seals on both sides. These seals protect the bearing from contaminants like dirt, moisture, and other debris, as well as help retain lubrication within the bearing.
Dimensions:
Bore diameter (d): 70 mm
Outer diameter (D): 125 mm
Width (B): 24 mm
Bearing Design:
Deep Groove Ball Bearing: This design allows the bearing to support both radial and axial loads in both directions. Deep groove ball bearings are typically used in applications where smooth, efficient, and quiet operation is important, even at high speeds.
Seals (2RS1): The rubber seals provide added protection against contaminants and moisture, extending the bearing's lifespan, especially in harsh environments where dirt or water exposure is a concern.
Common Applications:
Electric motors (including industrial motors, household appliances)
Automotive components (alternators, pumps, wheel hubs)
Pumps and compressors
Conveyors and material handling systems
Agricultural machinery
HVAC systems (fans, blowers)
General machinery and industrial equipment
Advantages:
Protection from Contaminants: The rubber seals ensure the bearing is sealed against dirt, dust, and moisture, which enhances its reliability and service life in demanding environments.
Low Friction: The deep groove design minimizes friction, making it suitable for high-speed applications, which improves the overall efficiency of rotating machinery.
Versatile Load Handling: It can handle both radial and axial loads, making it a versatile option for many different types of mechanical applications.
Key Features:
Type: Deep groove ball bearing
Seals: 2RS1 indicates that the bearing has rubber seals on both sides. These seals protect the bearing from contaminants like dirt, moisture, and other debris, as well as help retain lubrication within the bearing.
Dimensions:
Bore diameter (d): 70 mm
Outer diameter (D): 125 mm
Width (B): 24 mm
Bearing Design:
Deep Groove Ball Bearing: This design allows the bearing to support both radial and axial loads in both directions. Deep groove ball bearings are typically used in applications where smooth, efficient, and quiet operation is important, even at high speeds.
Seals (2RS1): The rubber seals provide added protection against contaminants and moisture, extending the bearing's lifespan, especially in harsh environments where dirt or water exposure is a concern.
Common Applications:
Electric motors (including industrial motors, household appliances)
Automotive components (alternators, pumps, wheel hubs)
Pumps and compressors
Conveyors and material handling systems
Agricultural machinery
HVAC systems (fans, blowers)
General machinery and industrial equipment
Advantages:
Protection from Contaminants: The rubber seals ensure the bearing is sealed against dirt, dust, and moisture, which enhances its reliability and service life in demanding environments.
Low Friction: The deep groove design minimizes friction, making it suitable for high-speed applications, which improves the overall efficiency of rotating machinery.
Versatile Load Handling: It can handle both radial and axial loads, making it a versatile option for many different types of mechanical applications.
Specification
Designation | Principal dimensions | dynamic | static | Reference speed | Limiting speed | ||||
d/mm | D/mm | B/mm | C/kn | Co/kn | r/min | r/min | |||
6314 | 70 | 150 | 35 | 111 | 68 | 9 500 | 6 300 | ||
6314 N | 70 | 150 | 35 | 111 | 68 | 9 500 | 6 300 | ||
6314 NR | 70 | 150 | 35 | 111 | 68 | 9 500 | 6 300 | ||
6314-2RS1 | 70 | 150 | 35 | 111 | 68 | 3 000 | |||
6314-2Z | 70 | 150 | 35 | 111 | 68 | 9 500 | 5 000 | ||
6314-RS1 | 70 | 150 | 35 | 111 | 68 | 3 000 | |||
6314-Z | 70 | 150 | 35 | 111 | 68 | 9 500 | 6 300 | ||
6211-2Z | 55 | 100 | 21 | 46.2 | 29 | 14 000 | 7 000 | ||
6211-2ZNR | 55 | 100 | 21 | 46.2 | 29 | 14 000 | 7 000 | ||
6211-RS1 | 55 | 100 | 21 | 46.2 | 29 | 4 300 | |||
6211-Z | 55 | 100 | 21 | 46.2 | 29 | 14 000 | 9 000 | ||
6211-ZNR | 55 | 100 | 21 | 46.2 | 29 | 14 000 | 9 000 | ||
62211-2RS1 | 55 | 100 | 25 | 43.6 | 29 | 10 000 | 4 300 | ||
62311-2RS1 | 55 | 120 | 43 | 71.5 | 45 | 3 800 | |||
6311 | 55 | 120 | 29 | 74.1 | 45 | 12 000 | 8 000 | ||
6311 M | 55 | 120 | 29 | 74.1 | 45 | 12 000 | 11 000 | ||
6311 N | 55 | 120 | 29 | 74.1 | 45 | 12 000 | 8 000 | ||
62306-2RS1 | 30 | 72 | 27 | 28.1 | 16 | 6 300 | |||
63006-2RS1 | 30 | 55 | 19 | 13.3 | 8.3 | 8 000 | |||
6306 | 30 | 72 | 19 | 29.6 | 16 | 20 000 | 13 000 | ||
6306 N | 30 | 72 | 19 | 29.6 | 16 | 20 000 | 13 000 | ||
6306 NR | 30 | 72 | 19 | 29.6 | 16 | 20 000 | 13 000 | ||
6306-2RS1 | 30 | 72 | 19 | 29.6 | 16 | 6 300 | |||
6306-2RZ | 30 | 72 | 19 | 29.6 | 16 | 20 000 | 11 000 | ||
6306-2Z | 30 | 72 | 19 | 29.6 | 16 | 20 000 | 11 000 | ||
6304-2Z | 20 | 52 | 15 | 16.8 | 7.8 | 30 000 | 15 000 | ||
6304-2ZNR | 20 | 52 | 15 | 16.8 | 7.8 | 30 000 | 15 000 | ||
6304-RSH | 20 | 52 | 15 | 16.8 | 7.8 | 9 500 | |||
6304-Z | 20 | 52 | 15 | 16.8 | 7.8 | 30 000 | 19 000 | ||
6304-ZNR | 20 | 52 | 15 | 16.8 | 7.8 | 30 000 | 19 000 | ||
4206 ATN9 | 30 | 62 | 20 | 26 | 20.8 | 17 000 | 9 500 | ||
4306 ATN9 | 30 | 72 | 27 | 41 | 30 | 16 000 | 8 500 | ||
6006 | 30 | 55 | 13 | 13.8 | 8.3 | 28 000 | 17 000 | ||
6006 N | 30 | 55 | 13 | 13.8 | 8.3 | 28 000 | 17 000 | ||
6006 NR | 30 | 55 | 13 | 13.8 | 8.3 | 28 000 | 17 000 | ||
6006-2RS1 | 30 | 55 | 13 | 13.8 | 8.3 | 8 000 | |||
6006-2RZ | 30 | 55 | 13 | 13.8 | 8.3 | 28 000 | 14 000 | ||
6006-2Z | 30 | 55 | 13 | 13.8 | 8.3 | 28 000 | 14 000 | ||
Packing & Delivery
Packing:
1, Universal packing.
2, nsk ntn EXPLO DIMSEN Packing.
3, Customized Packing.
4, Original brand packing. Contact us for more pictures.
1, Universal packing.
2, nsk ntn EXPLO DIMSEN Packing.
3, Customized Packing.
4, Original brand packing. Contact us for more pictures.
Delivery:
We usually send goods by sea or by air freight depends on the weight and volum of your pakcage, such as UPS, Fedex, DHL, TNT, EMS,etc. If buyer has designated forwarder, we can also send goods to them directly based on buyer's requirement.
We usually send goods by sea or by air freight depends on the weight and volum of your pakcage, such as UPS, Fedex, DHL, TNT, EMS,etc. If buyer has designated forwarder, we can also send goods to them directly based on buyer's requirement.
How long will it take to ship to my country?
If deliver by air express such as DHL, UPS, FEDEX, It will takes about 4-9 working days to arrive. If deliver by sea, It usually
takes about 30 to 45 working days to arrive.
What is the shipping cost?
The shipping cost depens on the gross weight and delivery address.
As for customized bearings, you can contact us for the exact shipping cost.
As for the RTS products, the shipping cost will be calculated by system automatically. you can see it on product page.
If deliver by air express such as DHL, UPS, FEDEX, It will takes about 4-9 working days to arrive. If deliver by sea, It usually
takes about 30 to 45 working days to arrive.
What is the shipping cost?
The shipping cost depens on the gross weight and delivery address.
As for customized bearings, you can contact us for the exact shipping cost.
As for the RTS products, the shipping cost will be calculated by system automatically. you can see it on product page.
Payment:
We accept T/T (Bank Wire), Trade Assurance through alibaba.com, Western Union, Money Grame, Paypal, L/C. Buyer can pay in USD, AUD, CAD, SGD, EUR, GBP, HKD, JPY and cash.
If you have any further question, please feel free to contact us.
We accept T/T (Bank Wire), Trade Assurance through alibaba.com, Western Union, Money Grame, Paypal, L/C. Buyer can pay in USD, AUD, CAD, SGD, EUR, GBP, HKD, JPY and cash.
If you have any further question, please feel free to contact us.
