Высокопроизводительное вибрационное сито Gaofu из нержавеющей стали химическое порошковое скрининг круговой роторный вибрационный экран siev
2 165,00-4 369,00 $
4 слойное вращающееся вибрационное сито DZJX пищевое круглое для карбоната кальция химический порошковый материал батареи
- Категория: >>>
- Поставщик: Xinxiang Dongzhen Machinery Co. Ltd.Xinxiang Ltd.
Сохранить в закладки 1601332645349:
Описание и отзывы
Характеристики
Products Description
DZJX Fine Powder Round Vibrating Screen Vibrating Screen Machine Ultrasonic Sieving Separator Powder Detergent Vibro Sieve
S49 -B Rotary vibration screen is a kind of high-precision screening machinery, its low noise, high efficiency, fast change the screen(3-5 minutes), fully closed structure.It's widely used in food, pharmaceutical ,mineral and chemical industries.It's suitable for particles, powder, liquid and other materials classification, filtration and removal of impurities
Screening range: 2-600 mesh
Machine material optional: carbon steel, 304/316 stainless steel
Equipped with screen cleaning device (bouncing ball or ultrasonic) to avoid clogging
Machine material optional: carbon steel, 304/316 stainless steel
Equipped with screen cleaning device (bouncing ball or ultrasonic) to avoid clogging
Working Principle
Rotary vibration screen is made of an upright motor as a source of vibration, the motor is installed at the upper and lower ends of the eccentric heavy hammer, the motor rotation motion into horizontal, vertical, oblique three-dimensional motion, and then the motion to the screen surface. Adjust the phase Angle of the upper and lower ends to change the motion track of the material on the screen surface.
Why choose us
Observation hole & Inlet
* Observation holes can be added on the cover of the machine according to customer requirements, convenient to check the material screening at any time.
*According to customer requirements, the inlet can be designed into various shapes (such as funnel, round, rectangular, etc.)
Equipment surface treatment
* Internal and external mirror surface polishing, leaving no dead angle.
*According to customer requirements, spray painting, sand blasting and other processing methods can also be used.
Vibration motor
* DZJX rotary vibrating screen uses world famous brand motor --OLI motor, more durable, maintenance free, CE certification.
* Voltage, frequency, and plug can be customized according to customer requirements.
* According to the characteristics of the material, choose different screen cleaning device: Bouncing ball（Larger sized materials） or Ultrasonic generator（Fine powder).
Product shows
Application
Chemical industry: resin pigment, calcium carbonate, decorative coatings, medicine, grease, paint, palette, etc.
Abrasive material and ceramic industry: building sand, mica, alumina, silica sand, abrasive, refractory material, slurry, etc.
Food industry: sugar, salt, alkali, flour powder, nut powder, whey protein powder , maltodextrin , flavors , sucralose , xanthan gum, soy lecithin ,farina, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice, etc.
Paper-making industry:coated slurry, exhaust liquid, paper making liquid and waste water reclamation, etc.
Metallurgy and mining industry: quartz sand, sand, ore, titanium oxide, zinc oxide, etc.
Mechanical industry: casting sand, charcoal, grafito, powder metallurgy, electromagnetic material and metal powder, etc
Abrasive material and ceramic industry: building sand, mica, alumina, silica sand, abrasive, refractory material, slurry, etc.
Food industry: sugar, salt, alkali, flour powder, nut powder, whey protein powder , maltodextrin , flavors , sucralose , xanthan gum, soy lecithin ,farina, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice, etc.
Paper-making industry:coated slurry, exhaust liquid, paper making liquid and waste water reclamation, etc.
Metallurgy and mining industry: quartz sand, sand, ore, titanium oxide, zinc oxide, etc.
Mechanical industry: casting sand, charcoal, grafito, powder metallurgy, electromagnetic material and metal powder, etc
Product Parameters
Model | Diameter(mm) | Deck | Screen mesh area(mm) | Mesh size(mesh) | Max particle size(mm) | Power(kw) |
S494-B | Φ400 | 1-5 | Φ380 | 3-500 | <20 | 0.25 |
S496-B | Φ600 | 1-4 | Φ600 | 3-500 | <20 | 0.6 |
S498-B | Φ800 | 1-4 | Φ750 | 3-500 | <30 | 0.6 |
S4910-B | Φ1000 | 1-5 | Φ900 | 3-500 | <30 | 0.8 |
S4912-B | Φ1200 | 1-5 | Φ1100 | 3-500 | <30 | 1.5 |
S4915-B | Φ1500 | 1-4 | Φ1450 | 3-500 | <50 | 2.2 |
S4918-B | Φ1800 | 1-3 | Φ1750 | 3-500 | <50 | 2.5 |
S4920-B | Φ2000 | 1-3 | Φ1950 | 3-500 | <60 | 2.5 |
Packing & Delivery
About us
Xinxiang Dongzhen Machinery Co. LTD
(1) 36 years professional pharmaceutical ,food and chemical machinery manufacturer and supplier.
(2) 1 Years Warranty, 14 Days Delivery, Factory Price.
(2) 1 Years Warranty, 14 Days Delivery, Factory Price.
(3) 14800㎡ factory, Own R&D Team.
(4) Free design service, free professional solutions.
(5) Passed ISO9001, CE, SGS, Intetek certificates.
(6) Provide alibaba quality and delivery guarantee services.
(4) Free design service, free professional solutions.
(5) Passed ISO9001, CE, SGS, Intetek certificates.
(6) Provide alibaba quality and delivery guarantee services.
FAQ
Q:What factors I need to get a quotation?
A: Name & bulk density of materials; Capacity per hour; Mesh size and decks; Material of the machine; Voltage&Frequency(Hz).
Q:What is the real delivery time of your factory?
Q:What is the real delivery time of your factory?
A: 7 to 15 days for general series products, meanwhile, batches products & customized products would need 30 days to 60 days based on different situations.
Q: How do your after-sale service work if the product got damaged?
Q: How do your after-sale service work if the product got damaged?
A: In the guarantee time 12 months, our general after-sale service is changing the damaged parts for the customer, but if the damage could be repaired by slight cost, we would wait for the customer's bill for the fix cost and refund this part of cost.(note: Vulnerable parts do not include.)
