Китайский туннельный бурильный станок EBZ200R для добычи 72-тонного бурового оборудования
220 000,00-280 000,00 $
Китай горячая Распродажа туннель расточный станок трубы Jaking машина
- Категория: >>>
- Поставщик: Gansu Temas Technology Equipment Co. Ltd.Gansu Ltd.
Сохранить в закладки 1601342158593:
Описание и отзывы
Характеристики
1 | complete machine | |
Model | φ8780 Earth pressure balance shield tunneling machine | |
Excavation diameter（mm） | 8820 | |
rotational speed of cutterhead（rpm） | 0.1～4.0 | |
Maximum propulsion speed（mm/min） | 100 | |
Maximum thrust（T） | 7200 | |
Total length of the entire machine（m） | 81.18 | |
Total length of host (including cutterhead) （mm） | 12000 | |
Total weight (main engine+rear supporting equipment) （T） | 900 | |
Applicable pipe segment specifications (outer diameter/inner diameter width/division)（mm） | Outer diameter 8500 Inner diameter7700 Width 1600 | |
Maximum design pressure（MPa） | 0.6 | |
Horizontal turning radius（m） | 550 | |
Vertical climbing ability（‰） | 40 | |
2 | Cutterhead | |
Cutterhead specification (diameter x length)(mm) | 8820×800 | |
Cutterhead opening rate(%) | About 30% | |
Total weight of structure(T) | 90 | |
Main structural component materials | Q345C | |
Number of foam mouth (piece) | 4 | |
Number of Bentonite Mouth (piece) | 4 | |
Number of active mixing arms | 5 | |
3 | cutters | |
Rolling cutter | 49 | |
Number of center replaceable roller cutters (pieces) | 9 | |
Number of replaceable roller cutters (pieces) | 40 | |
Extension of rolling cutter (mm) | 150 | |
Knife spacing | 4.0～104.6 | |
Scraper quantity (pieces) | 120 | |
Radial extension of scraper (mm) | 110 | |
Number of edge scrapers (pieces) | 36 | |
Number of wear monitoring points | 2 | |
12.5+12.5 composite steel plate area (outer circle) (㎡) | ||
6.4+6.4 Composite steel plate area (panel) (㎡) | ||
4 | Center swivel | |
Number of foam channels (channel) | 4 | |
Number of channels for bentonite (channels) | 4 | |
Number of hydraulic channels (channels) | 6 | |
5 | Main drive | |
Drive type (electric drive, hydraulic drive) | electric drive | |
Number of driving groups (groups) | 14 | |
Total driving power (kW) | 2380（170kW×14） | |
Speed range (rpm) | 0.1～4.0rpm | |
Rated torque (kN · m) | 10046 | |
Relief torque (kN · m) | 12056 | |
Main bearing life (h/km) | 10kilometre | |
Sealing type | Lip shape | |
Number of inner lip seals (pieces) | 3 | |
Number of outer lip seals (pieces) | 3 | |
6 | Shield body | |
Type | Earth pressure balance | |
Front shield specifications (diameter) (mm) | 8780 | |
Front Shield Weight (T) | 96 | |
Number of passive mixing arms | 3 | |
Number of lubrication holes on the front shield housing (pieces) | 16 | |
Number of pressure sensors | 6 | |
Number of advanced grouting holes for the partition (pieces) | 8 | |
Middle Shield Specification (diameter) (mm) | 8780 | |
Weight of Middle Shield (T) | 196 | |
Number of lubrication holes in the middle shield housing (pieces) | 6 | |
Tail shield specification (diameter) (mm) | 8770 | |
Tail shield weight (T) | 52 | |
Number of lubrication holes on the tail shield housing (pieces) | 6 | |
Number of rows of tail shield sealing brushes (rows) | 4 | |
Tail shield grouting plate (row) | 1 | |
Number of emergency airbag seals (track) | 1 | |
Shield tail installation gap (mm) | 30 | |
Number of single liquid injection pipes (pieces) | 4 | |
Number of grease injection tubes (pieces) | 26 | |
Articulated type (active, passive) | active | |
Material of the main structural components of the shield body | Q345C | |
7 | Human cabin | |
type | Double cabin sliding door type | |
Working pressure (MPa) | 0.6 | |
8 | Spiral conveyor (only filled when using earth pressure balance shield tunneling machine) | |
Spiral shaft type | With shaft type cantilever type | |
Specification (diameter x length) (mm) | 1000×13440 | |
Maximum passing particle size (mm) | 320 | |
Maximum slag discharge capacity (m3/h) | 317 | |
Driving form | Peripheral hydraulic motor drive | |
Number of driving groups (groups) | 2 | |
Drive power (kW) | 75kw×2 | |
Maximum torque (kN · m) | 147 | |
Speed range (r/min) | 1.5~13.3 | |
Rotation direction | Positive and negative | |
Number of gates (gates) | 3 | |
Soil improvement injection port (number) | 3 | |
Number of pressure sensors | 1 | |
Telescopic mechanism (piece) | 2 | |
Expansion length (mm) | 695 | |
Total weight (T) | 24 | |
Is it equipped with a secondary screw conveyor | No |
A) You are a trade company or manufacture?
We are a Manufacturer.
B) What can you do if the machine is broken?
Our machine's warranty period is 12 months. if the broken parts can't repair, we can send the new parts to replace the broken
parts, but you need to pay the shipping cost by yourself. if the warranty period is expired, we will negotiation for solving the
problems, and we supply the technical support for the whole life of the equipment.
C) Whether you could make our brand on your products?
Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
D) Can you customize the product according to our requirements?
Yes, if you can meet our minimum order quantity, the product can be customized.
E) How to guarantee the quality of your products?
1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
We are a Manufacturer.
B) What can you do if the machine is broken?
Our machine's warranty period is 12 months. if the broken parts can't repair, we can send the new parts to replace the broken
parts, but you need to pay the shipping cost by yourself. if the warranty period is expired, we will negotiation for solving the
problems, and we supply the technical support for the whole life of the equipment.
C) Whether you could make our brand on your products?
Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
D) Can you customize the product according to our requirements?
Yes, if you can meet our minimum order quantity, the product can be customized.
E) How to guarantee the quality of your products?
1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
