Product Application
Laser processing can be carried out on non-metallic materials such as bamboo, crystal, horn, paper, plexiglass, marble, cloth, leather, rubber, plastic, etc. Clothing, embroidery, cloth toys, home furnishings, handbags, gloves, toys, leather, leather cutting and surface carving. Precision cutting of non-metal sheets such as acrylic, medium-density decorative panels for crafts, models, advertising, decoration, electrical appliances, plastics
XY axis line guide rail (15mm width guide rail) work area: 600*900mm, Ruida system 6445, leadshine 57 -step motor, 3M belt, import focusing mirror,red light ,air pump,fans ,up and down table honeycomb or knife panel. working area 600*900mm. Air pump, water pump,
Specification for 6090 laser engraving cutting machine | ||
Main configuration | Laser power | EFR tube ( 60w/80w/100w/130w/150w ) or Reci w2 /w4 |
Controller | Ruida 6442s /6445G controller ( Rdworks v8 ) | |
Guide rail | Hiwin X-Axis and Y-Axis double linear guide rail | |
Work table | 600*900mm work size blade work table | |
Main performance parameters | Engraving speed | 0-1000mm/s |
Cutting speed | 0-100mm/s | |
Support Fils | BMP,HPGL,PLT,DST and AI etc. | |
Resolution | ±0.05mm/1000DPI | |
Minimum Letter | English 1×1mm (Chinese Characters 2*2mm) | |
Position system | Red dot position | |
Other parameters | Power Voltage | AC 110 or 220V±10%,50-60Hz |
Power cable | European Type/China Type/America Type/UK Type | |
Cooling way | Water cooling and protection system | |
Machine Size | 162*114*80cm | |
Gross Weight | 185kgs | |
Package | Standard plywood case for export | |
Warranty | All life free tech support, one year warranty, except consumables | |
Free accessories | Air Compressor/Water Pump/Air Pipe/Water Pipe/Software and Dongle/ English User Manual/USB Cable/Power Cable |
Machine details:
Name | Amount | Units |
water pump 005 | 1 | set |
Air pump 185W 150L/min | 1 | set |
Large Exhaust fan 550W | 1 | set |
Smoke pipe | 2 | pcs |
Power line | 2 | pcs |
Water pipe | 1 | pcs |
Air pipe | 1 | pcs |
Inner hexagon spanner | 1 | set |
Manual book | 1 | pcs |
Software CD | 1 | pcs |
USB line | 1 | pcs |
Focus ruler | 1 | pcs |
Paper for adjusting laser light way | 1 | pcs |
Plugs and Socket | 1 | pcs |
Tools bag or box | 1 | pcs |
water chiller cw3000/cw5000/cw5200 | (choose) | |
rotary | (choose) |
Applicable Materials:
Leather, cloth, wool, fur, acrylic, plexiglass, wooden board, plastic, resin and other non-metal materials.
Applicable Industry:
Processing industries of engraving and cutting, such as garment, leather, package and printing, advertisement decoration, building upholster, art gift, computer embroidery, paper prodct, acylic product, middle density board ect. non-metal sheet precision cutting and other industries.
machine with 3 years warrantry,laser tube with 12 months warrantry
Notice: Express Seller's Shipping Method means that we will pay for the freight by sea to your basic sea port, we pay for freight , need customer clear the customs ,pay the customs tax and local sea port charges. it is not door to door service.
Q1. How to get the most suitable machine and best price Please tell us the material you want to engrave or cut? Max size and thickness?
Q2. If we don't know how to use the machine,can you teach us?
Yes, we will, English manual and video will come along with the machine. You also can contact our service team if you need any help during use our machines.
Q3.How about your after-sales service?
we offer you 24 hours service by phone, Skype or Whatsapp.
Q4. Quality Control: The whole production procedure will be under regular inspection and strict quality control. The complete machine will be tested to make sure they can work very well before being out of factory.Our machine passed CE Certificate, meet European and American standard, were exported to more than 100 Countries.
Q5. How we pay you?
A. Consult us about this product on line or by e-mail. B. Negotiate and confirm the final price , shipping , payment methods and other terms. C. Send you the proforma invoice and confirm your order. D. Make the payment according to the method put on proforma invoice. E. We prepare for your order in terms of the proforma invoice after confirming your full payment.And 100% quality check before shipping. F.Send your order by air or by sea.
