HuanSheng 52 кВт ковшоптрам дизельный подземный для добычи полезных ископаемых 0 75 ярдов мини-совок продажи
26 600,00-26 800,00 $
HuanSheng 1200 кг подземный карьерный совок 0 75 дизельный 52 кВт мини совок
- Категория: >>>
- Поставщик: Henan Huansheng Mechanical Equipment Co. Ltd.Henan Ltd.
Сохранить в закладки 1601346107471:
Описание и отзывы
Характеристики
HuanSheng Underground Mini Scooptram Diesel Scooptram 0.75 1 1.5 Yarda Mining Equipment
Products Description
This is a reliable 1.2 ton Underground Diesel Loader .Underground diesel loaders are designed with a high-strength steel frame and feature a heavy-duty, all-mechanical powertrain. It has the characteristics of compact structure, convenient operation, low energy consumption, low noise, high protection level, good power performance, low operating cost and high production efficiency. It is a new type of equipment for small and medium-sized underground mines or mine renovation and upgrading.
The underground mining loader offers high payload capacity while operating efficiently in height-restricted mines. Thanks to proven engine technology, this workhorse loader delivers high productivity in hard rock conditions.
The underground mining loader offers high payload capacity while operating efficiently in height-restricted mines. Thanks to proven engine technology, this workhorse loader delivers high productivity in hard rock conditions.
It is easy to operate and maintain, and it features an operator compartment that is located in the rear frame of the machine to ensure increased operator safety. It help mines maximize tons and minimize extraction costs. It has been engineered to optimize machine width, length and turning radius, enabling operation in narrower tunnels for less dilution and lower operational costs.
Product Parameters
WJ-0.6 Scooptram | ||
Bucket volume (m3) | 0.6m³ | |
Rated load capacity (t) | 1.2t | |
Driving speed (km/h) | 0-9.7km/h | |
Forward speed(km/h) | Gear Ⅰ: 0-4.6km/h; Gear Ⅱ：0-9.7km/h | |
Reverse speed(km/h) | Gear Ⅰ: 0-4.6km/h; Gear Ⅱ：0-9.7km/h | |
Maximum climbing slope(°) | 16° | |
Minimum ground clearance | 180mm | |
Wheelbase | 2300mm | |
Wheel distance | 980mm | |
Max Unloading Height(mm) | 1260mm | |
Unload distance | 745mm | |
Tire Model | 255/70D406 | |
Gear shift type | Power Shift | |
Power type | Diesel | |
Diesel Engine Model | Yunnei Brand YN33 | |
Power (kw) | 52kw | |
Steering method | Fully hydraulic steering wheel | |
Overall Size | 5000*1260*1850mm | |
Weight | 5.1t | |
Product Details
NOTICE
1. Before using the machine, the driver must check the liquid storage of breaking pump .Liquid level should be kept at 1/2. Please add breaking liquid if below 1/2 and drain the air in breaking system, otherwise it will influence the safety.
2. Hydraulic oil
Summer: L- HL 46 or L- HN 46
Summer: L- HL 46 or L- HN 46
Winter: L- HL 46 or L- HM 46
3. When changing the direction forward and back, the first step is to step on the brake pedal,after the vehicle stops steadily and walking hydraulic unloads, then change the direction,or they will reduce the useful life of vehicles causing serious accident.
4. When the temperature is below 0°C and antifreeze is not used, please drain the water in engine radiator ,oil cooler and pipes after parking the loader, or the engine, radiator and oil cooler etc . will freeze to be cracked.
5. When the machine is working, fan housing is prohibited to take down so as to avoid the casualty accident.
6. When the temperature is high in the tank, do not open the tank cover, so as to avoid the scalding incident.
Application scenario
Scrapers are widely used for earthmoving operations in highways, railways, ports and large-scale construction projects. For example:
1. In highway construction, it is used to excavate roads, fill embankments, move earth, etc.;
2. In water conservancy projects, it is used to excavate rivers and channels, fill earth dams, earth embankments, etc.;
3. in farmland infrastructure construction, it is used for land leveling. , eradicate mounds, fill depressions, etc.; perform
earthwork shoveling operations in airport and mine construction;
4. Under suitable conditions, it can also be used in the construction of soft stone projects where
stone is broken. Scrapers are also widely used in underground mining, oil development and other occasions.
2. In water conservancy projects, it is used to excavate rivers and channels, fill earth dams, earth embankments, etc.;
3. in farmland infrastructure construction, it is used for land leveling. , eradicate mounds, fill depressions, etc.; perform
earthwork shoveling operations in airport and mine construction;
4. Under suitable conditions, it can also be used in the construction of soft stone projects where
stone is broken. Scrapers are also widely used in underground mining, oil development and other occasions.
Service and warranty
Services：
* Pre-sale
We hope to establish a good, long-term and mutually beneficial relationship with our customers. We will understand customers’demand so that recommend the most suitable products for them.
* In sale
Customers’ requirements will be put in the first place. During this period, we will communicate with customers in time if they have any questions need to be confirmed.
* Post-sale
24 Hours Online service. We will provide technical support on the line if customers have problems.
Warranty ：(1)The underground loader parts quality assurance period for 12 months. In normal use circumstances, there is any
quality problem during warranty period, we will use DHL, UPS, or other express delivery to send the accessories for customers after determine the damaged parts.
(2)We will try our best effort to solve, whenever customers have a problem
quality problem during warranty period, we will use DHL, UPS, or other express delivery to send the accessories for customers after determine the damaged parts.
(2)We will try our best effort to solve, whenever customers have a problem
Company Profile
HuanSheng Mechanical Equipment
Henan HuanSheng Mechanical Equipment CO.,LTD, is a specialized manufacturer and trade of underground loader, dumper trucks, loaders, mucking loaders, crushers etc., integrating development and production. We are holding this line for more than 10 years, with well-equipped testing facilities and strong technical force. Our products are exported to many countries all over the world. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in construction, woodworking and other industries. Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs.
We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
