Product Description
The mortar spraying machine is suitable for spraying scope: cement mortar, putty powder, paint, latex paint, real stone paint, thermal insulation mortar, waterproof material, fireproof material, thermal insulation material, sound-absorbing material and other water-soluble materials
Tatooine cement spray plaster machine building mortar spraying machine cement mortar spray gun
Specification
Metric | ||||||
Model | 311 | 511 | 711 | |||
Conveying Pipe Diameter | 32 mm | 38 mm | 38 mm | |||
Air Pump Power | 2.2kw | 2.2 kw | 2.2 kw | |||
Motor Power | 4 kw | 7.5 kw | 7.5 kw | |||
Voltage | 380V Three Phase Electric/Diesel Engine(customized) | 380V Three Phase Electric/Diesel Engine(customized) | 380V Three Phase Electric/Diesel Engine(customized) | |||
Spraying Area | 150-170 m²/h | 180-200 m²/h | 220 m²/h | |||
Working Pressure | 5-8 mpa | 5-8 mpa | 5-8 mpa | |||
Conveying Flow | 3 m³/h | 3 m³/h | 4 m³/h | |||
Water:Cement:Sand | 1:1:3 | 1:1:3 | 1:1:3 | |||
The Maximum Passing Particle | 4 mm | 4 mm | 4 mm | |||
Maximum Vertical Distance | 10-15 m | 15-20 m | 20-25 m | |||
Maximum Horizontal Distance | 25-35 m | 30-40 m | 40-50 m | |||
Overall Dimensions | 1600*450*900 mm | 1700*600*1100 mm | 1800*650*1000 mm | |||
Total Weight | 150 kg | 300 kg | 360 kg | |||
Scope of Application | motar,putty,paint,etc | motar ,putty,paint,etc | motar ,putty,paint,etc | |||
IMPERIAL | ||||||
Model | 311 | 511 | 711 | |||
Conveying pipe diameter | 1.26'' | 1.5'' | 1.5'' | |||
Air pump power | 3hp | 3hp | 3hp | |||
Motor power | 5.5hp | 10hp | 10hp | |||
Voltage | 110v/380v/220v/415v/440v(customized) | 110v/380v/220v/415v/440v(customized) | 110v/380v/220v/415v/440v(customized) | |||
Spraying area | 1615-1830ft*2/h | 1938 -2153ft*2/h | 1938 - 2153ft*2/h | |||
Conveying flow | 106bcf/h | 106bcf/h | 141bcf/h | |||
Maximum passing particle | 0.16'' | 0.16'' | 0.16'' | |||
Maximum vertical distance | 394''-591'' | 591''-788'' | 788''-985'' | |||
Maximum horizontal distance | 985''-1378'' | 1182''-1575'' | 1575''-1969'' | |||
Overall dimensions(L*W*H) | 63 ''*18''* 36'' | 67''* 24 ''*44'' | 71''* 26''* 39'' | |||
Total weight | 331ib | 662ib | 794ib | |||
Scope of application | motar,putty,paint,etc | motar,putty,paint,etc | motar,putty,paint,etc | |||
Product Details
Product advantage
1. Copper core motor, stable performance, not easy to burn machine
2. The connection between the spray gun and the feeding tube can be rotated, which is easy to operate
3. High construction efficiency, good quality, and small size, easy to handle on site
4. Sealing rubber sleeve, made of black rubber, wear-resistant and corrosion-resistant
Tatooine cement spray plaster machine building mortar spraying machine cement mortar spray gun
Packing & Delivery
We adopt wooden and iron box to pack machines, better guarantee the safety and quality of products.And we adopt multiple port, multiple exit point. Such as Shanghai, Qingdao, Guangdong and other regions. Product transportation will be faster and more convenient
Company Profile
Henan Tatooine Mechanical Equipment Co.,Ltd. is a professional production and processing company for steel machinery, concrete mixers, road machinery, batching machines, etc. It has a complete and scientific quality management system. Henan Tatooine Mechanical Equipment Co.,Ltd was established in the nineties of twenty century and is one of the earliest professional manufacturers in the field of construction machinery In the spirit of professionalism and excellence,we have gradually developed into a large factory with a history of 30 years. The equipment we provid includes steel bar bending machine,steel bar cutting machine steel bar straightening machine concrete laser screed,concrete cutting machinepower plastering machinerollerconcrete screedconcrete mixer and so on. Has more than 100 engineering and technical experience. Construction machinery we can meet your different orders. In addition, our professional R &:D team will provide you with the most convenient service, Since your order, we can provide the best products and service for you.
Certifications
Customer Photos
FAQ
1. Who are we?
We are based in Henan, China, start from 2005,sell to Domestic Market(40.00%),North America(15.00%),Southeast Asia(10.00%),Africa(10.00%),South America(5.00%),Oceania(5.00%),Western Europe(5.00%),Eastern Europe(3.00%),Mid East(2.00%),Eastern Asia(00.00%),Central America(00.00%),Northern Europe(00.00%),Southern Europe(00.00%),South Asia(00.00%). There are total about 21-50 people in our office.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
Concrete Mixer,Concrete Pump,Concrete Road Paver,Steel Bar Straightening and Cutting Machine,Steel Bar Bending Machine
4. Why should you buy from us not from other suppliers?
Henan Tatooine Machinery Manufacturing Co., Ltd. is a professional production and processing company for steel machinery, concrete mixers, road machinery, batching machines, etc. It has a complete and scientific quality management system.
5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,
We are based in Henan, China, start from 2005,sell to Domestic Market(40.00%),North America(15.00%),Southeast Asia(10.00%),Africa(10.00%),South America(5.00%),Oceania(5.00%),Western Europe(5.00%),Eastern Europe(3.00%),Mid East(2.00%),Eastern Asia(00.00%),Central America(00.00%),Northern Europe(00.00%),Southern Europe(00.00%),South Asia(00.00%). There are total about 21-50 people in our office.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
Concrete Mixer,Concrete Pump,Concrete Road Paver,Steel Bar Straightening and Cutting Machine,Steel Bar Bending Machine
4. Why should you buy from us not from other suppliers?
Henan Tatooine Machinery Manufacturing Co., Ltd. is a professional production and processing company for steel machinery, concrete mixers, road machinery, batching machines, etc. It has a complete and scientific quality management system.
5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,
Italian
Tatooine cement spray plaster machine building mortar spraying machine cement mortar spray gun
