ZLP630 подвесная платформа для работы на большой высоте с регулируемой скоростью и улучшенными функциями безопасности
- Категория: >>>
- Поставщик: Wuxi Watsond Machinery Technology Co. Ltd.Wuxi Ltd.
Сохранить в закладки 1601353202664:
Описание и отзывы
Характеристики
ZLP630 Suspended Platform Details
Product Description
| ZLP630 ZLP800 Suspended Platform Parameter | ||||||
| Description | ||||||
| Model | ZLP630 | ZLP800 | ||||
| Rated load | 630 Kg | 800 Kg | ||||
| Lifting speed | 9.3+0.5 m/min | 8.0+0.5 m/min | ||||
| Lifting Height | 100 m | 100 m | ||||
| Working Platform | Working Cage | 1 Sets | Dimension L×W×H(m) | 6m(2+2+2)×0.69×1.42m | 7.5m(2+2+2+1.5)×0.69×1.45m | |
| Material | Q235 Steel or Aluminum Alloy | Q235 Steel or Aluminum Alloy | ||||
| Surface | Painting or HDG | Painting or HDG | ||||
| Bottom Wheels | 4 pcs | 4 pcs | ||||
| Wall Roller | 2 pcs | 2 pcs | ||||
| Hoist | 2 Sets | Model | LTD6.3 | LTD8.0 | ||
| Lifting Speed | 9.3±0.5 m/min | 9.3±0.5 m/min | ||||
| Pulling power | 6.3KN | 8.0KN | ||||
| Quantity | 2 sets | 2 sets | ||||
| Electric Motor | Power | 1.5 kw*2 | 1.8 kw*2 | |||
| Voltage | 380v/50Hz or 220V/60HZ | 380V/50Hzor220V/60HZ | ||||
| Rotational speed | 1420 rpm | 1420 rpm | ||||
| Braking Torque | 15N.m | 15N.m | ||||
| Safety Lock | 2 Sets | Model | LSG20 | LSG30 | ||
| Quantity | 2 sets | 2 sets | ||||
| Locking Rope Angle | 3°~8° | 3°~8° | ||||
| Allow impulsive force | 20 KN | 20 KN | ||||
| Steel Wire Diameter | 8.3 mm | 8.6 mm | ||||
| Electric Cabinet | 1 Sets | Component Brand | CHNT | CHNT | ||
| Surface | Galvanized | Galvanized | ||||
| Suspension Mechanism | 2 Sets | Front beam overhanging | 1.3~1.6 m | 1.3~1.6 m | ||
| Beam adjustable height | 1.06~1.66 m | 1.06~1.66 m | ||||
| Surface | Painting or HDG | Painting or HDG | ||||
| Electric Cable | l pcs-100 m | 3x2.0+2x1.0YC-5 | 3x2.5+2x1.5YC-5 | |||
| Steel Wire Rope | 4x31SW+FC | D-8.3 m | D-8.6 mm | |||
| 100 m/ pcs 4 pcs | 100 m/ pcs4 pcs | |||||
| Safety Rope | 1 pcs(Forced Nylon) | 100 m | 100 m | |||
| Heavy Hammer | 2 pcs | 4 pcs | 4 pcs | |||
| Travel Limit Disc | 2 pcs | 2 pes | 2 pes | |||
| Load Quantity of 20" Container | 13 sets | 13 sets | ||||
Our Services
Plan drawing cooperation:
Make the best plan according to customers' requirements
Product design:
using 3D software design, finite element analysis, to ensure the product safety and rationality.
Manufacturing:
Implement a quality management system conforming to international standards in manufacturing and product quality management,with the CE/TUV/ISO9001 quality management system certification.
After-sales service:
provide 24-hour emergency maintenance service
365 days/24hrs
Packaging & Shipping
our company
China Watsond Technology Group Co.,LTD is a professional manufacturer of BMU, Suspended platform and aerial work equipment, integrating design, manufacturing, construction, installation and after-sales. We have R&D center, manufacturing center and testing center. Through long-term unremitting efforts, Watsond brand has won wide praise both at home and abroad. At present, our products have been exported to more than 10 countries around the world. Our goal is to use our expertise and experience to serve our clients so that they can do their jobs in a safe, efficient and beneficial way.
Certifications
We not only think of quality assurance and safety when we design and manufacture our products.
Our goal is to achieve the highest degree of customer satisfaction, for which reason we intensely work on aspects, such as product quality, test on factory, with a "direct line" to our clients, communications with supplies and after-sales services that guarantee continuity and total guarantee of our products.
We will make every effort to manage company activities and resources as processes, in order to attain the expected results.
FAQ
Q :Are you factory or trade company?
A:We are a professional manufacturer of BMU, Suspended platform and aerial work equipment, integrating design, manufacturing, construction, installation and after-sales.
Q: What quality guarantee for your products?
A:We have passed the ISO 9001,CE,TUV certificates. We have own QC to check mass productions in the factory before each of shipment.
Q:What about the Price?
A:Please send us inquiry, A consideration solution or preferable quotation will be sent within 24 hours
Q:Payment term
A: T/T or L/C at sight.
Q:What is the MOQ?
A:No MOQ requirements.
Q:Can you produce with our logo?
A: We can provide OEM service to make your logo on the product.
