Высокое качество древесная дробилка молотковая мельница каменная зерновая для завода по переработке зерна или золота
888,00-1 000,00 $
Низкая Стоимость известняка бетона гранита гидравлическая конусная дробилка для дробления камня
- Категория: >>>
- Поставщик: Zhengzhou Hanfa Imp & Exp Trading Co. Ltd.Zhengzhou Ltd.
Сохранить в закладки 1601353883694:
Описание и отзывы
Характеристики
Product Description
Product Introduction
Cone crusher is widely used for the metallurgical industry, construction material industry, road building industry, chemical industry and silicate industry etc. It can be used as secondary, tertiary or quaternary crushing.can crush materials of above medium hardness, such as iron ores, copper ores, limestone, quartz, granite, gritstone, etc. The paryicle size is even and using this crusher decreases the circulating, and using multi-cylinder hydraulic clearing system can decrease downtime and save the working strength.
Specification
Technical Parameter
Model | Cavity | Feeding port size（mm） | Max feeding size (mm) | Mini discharge opening size (mm) | Processing capacity (t/h) | Motor power (kw) |
HF-HPM200 | C1 | 185 | 145 | 22 | 160~250 | 160 |
C2 | 125 | 100 | 18 | 145~250 | ||
C3 | 95 | 75 | 14 | 120~250 | ||
F1 | 76 | 60 | 12 | 108~210 | ||
F2 | 54 | 45 | 10 | 81~210 | ||
HF-HPM300 | C1 | 235 | 190 | 26 | 230~445 | 220 |
C2 | 211 | 170 | 20 | 200~445 | ||
C3 | 150 | 120 | 16 | 180~445 | ||
C4 | 107 | 85 | 14 | 160~220 | ||
F1 | 53 | 40 | 12 | 140~220 | ||
HF-HPM400 | C1 | 299 | 240 | 35 | 270~630 | 315 |
C2 | 252 | 200 | 25 | 252~630 | ||
C3 | 198 | 160 | 25 | 243~630 | ||
C4 | 111 | 90 | 18 | 210~630 | ||
F1 | 92 | 75 | 15 | 162~370 | ||
F2 | 50 | 40 | 13 | 126~370 | ||
HF-HPM500 | C1 | 335 | 270 | 38 | 365~790 | 400 |
C2 | 286 | 235 | 30 | 328~790 | ||
C3 | 204 | 165 | 22 | 280~790 | ||
F1 | 133 | 105 | 20 | 202~450 | ||
F2 | 95 | 75 | 16 | 175~450 | ||
F3 | 52 | 42 | 8 | 158~450 |
Structural composition
The structure of HPM multi-cylinder cone crusher mainly consists of fixed cone, moving cone eccentric sleeve, transmission, frame, adjustment ring, feed bin, discharge port, locking protection, oil cylinder, fan, motor hydraulics, etc.
The structure of HPM multi-cylinder cone crusher mainly consists of fixed cone, moving cone eccentric sleeve, transmission, frame, adjustment ring, feed bin, discharge port, locking protection, oil cylinder, fan, motor hydraulics, etc.
Product Advantages
1.Laminated Crushing
The crushing chamber adopts the advanced laminated crushing principle, making full use of the crushing force of physical mutual extrusion, improving the crushing efficiency and reducing the loss of vulnerable parts.
1.Laminated Crushing
The crushing chamber adopts the advanced laminated crushing principle, making full use of the crushing force of physical mutual extrusion, improving the crushing efficiency and reducing the loss of vulnerable parts.
2.High wear resistance and bolt fixing structure
The liner is made of ultra-high alloy manganese steel (ZGMn18Cr2), with a long service life; no filler is required, and it is easy to replace.
3.Positive pressure dust prevention system
Effectively prevent dust and other debris from entering the equipment and oil tank, avoiding lubricating oil pollution.
4.Protective device
HPM series cone crusher can release the impact force smoothly, protect the main machine from damage by iron, and the discharge port automatically returns to its original position after the iron passes.
5.Easy to adjust the discharge port
The hydraulic motor adjusts the discharge port, which can achieve precise control of the discharge port.
6.Zero degree spiral bevel gear
High transmission efficiency, quiet, and prevent burning sleeves.
The liner is made of ultra-high alloy manganese steel (ZGMn18Cr2), with a long service life; no filler is required, and it is easy to replace.
3.Positive pressure dust prevention system
Effectively prevent dust and other debris from entering the equipment and oil tank, avoiding lubricating oil pollution.
4.Protective device
HPM series cone crusher can release the impact force smoothly, protect the main machine from damage by iron, and the discharge port automatically returns to its original position after the iron passes.
5.Easy to adjust the discharge port
The hydraulic motor adjusts the discharge port, which can achieve precise control of the discharge port.
6.Zero degree spiral bevel gear
High transmission efficiency, quiet, and prevent burning sleeves.
Applicable Materials
If you need our products, please contact us, this is my WhatsApp. Or you can directly click the blue font below to send an
inquiry, we will help you make more money.
WhatsApp：+8617739786040
E-mail：betty@hanfagroup.com
inquiry, we will help you make more money.
WhatsApp：+8617739786040
E-mail：betty@hanfagroup.com
Company Profile
FAQ
1. Are you a trading company or a manufacturer?
We are a professional manufacturer. Our factory mainly produces water well
drilling rigs, core drilling rigs, down-the-hole drilling rigs, pile drivers, etc. The products have been exported to hundreds of countries around the world and enjoy a high reputation all over the world.
2. How is the quality of your machine?
Our products pass strict quality inspections before they leave the factory to ensure that they are qualified before they are shipped.
3. How to inspect the goods?
1) Support customers to come to the factory for on-site inspection.
2) Support customers to designate third-party companies to inspect goods.
3) Support video inspection.
4. Do you have after-sales service?
Yes, we have a dedicated service team that will provide you with professional technical guidance. If you need, we can send our
engineers to your workplace and provide training for your employees.
5. How about quality assurance?
We provide a one-year quality guarantee for the main machine of the machine.
6. How long is your delivery cycle?
1) In the case of stock, we can deliver the machine within 7 days.
2) Under standard production, we can deliver the machine within 15-20 days.
3) In the case of customization, we can deliver the machine within 20-25 days.
drilling rigs, core drilling rigs, down-the-hole drilling rigs, pile drivers, etc. The products have been exported to hundreds of countries around the world and enjoy a high reputation all over the world.
2. How is the quality of your machine?
Our products pass strict quality inspections before they leave the factory to ensure that they are qualified before they are shipped.
3. How to inspect the goods?
1) Support customers to come to the factory for on-site inspection.
2) Support customers to designate third-party companies to inspect goods.
3) Support video inspection.
4. Do you have after-sales service?
Yes, we have a dedicated service team that will provide you with professional technical guidance. If you need, we can send our
engineers to your workplace and provide training for your employees.
5. How about quality assurance?
We provide a one-year quality guarantee for the main machine of the machine.
6. How long is your delivery cycle?
1) In the case of stock, we can deliver the machine within 7 days.
2) Under standard production, we can deliver the machine within 15-20 days.
3) In the case of customization, we can deliver the machine within 20-25 days.
