NUP317 Подшипник подвижного состава NUP 317 E

NUP317 Подшипник подвижного состава NUP 317 E

Категория: >>>
Поставщик: Anhui Kaifu Bearing Import Export Co. Ltd.Anhui Ltd.

Цена:120,50-1 204,96 ₽*

Количество:

В избранное

Описание и отзывы

Характеристики

Cylindrical roller bearing NUP317E

What is a Cylindrical Roller Bearing?

Cylindrical roller bearing are of high load capacity and can operate at high speeds because they use rollers as their rolling elements. They can therefore be used in applications involving heavy radial and impact loading.

The rollers are cylindrical in shape and crowned at the end in order to reduce the stress concentrations. They are also suitable for applications that require high speed because the rollers are guided by ribs which are either on the outer or inner ring.

Product Description

Bearing Model					Main Dimensions(mm)			Weight(kg)
NU	NJ	NUP	N	NF	d	D	B	NU	N
NU2315E	NJ	NUP			75	160	55	5.25
NU415	NJ	NUP	N	NF	75	190	45	6.22	6.06
NU1016	NJ	NUP	N		80	125	22	0.98	0.965
NU216	NJ	NUP	N	NF	80	140	26	1.5	1.47
NU216E	NJ	NUP			80	140	26	1.67
NU2216	NJ	NUP	N		80	140	33	1.93	1.89
NU2216E	NJ	NUP			80	140	33	2.12
NU316	NJ	NUP	N	NF	80	170	39	3.86	3.77
NU316E	NJ	NUP			80	170	39	4.22
NU2316	NJ	NUP	N		80	170	58	5.79	5.67
NU2316E	NJ	NUP			80	170	58	6.25
NU416	NJ	NUP	N	NF	80	200	48	7.32	7.14
NU1017	NJ	NUP	N		85	130	22	1.03	1.01
NU217	NJ	NUP	N	NF	85	150	28	1.87	1.83
NU217E	NJ	NUP			85	150	28	2.11
NU2217	NJ	NUP	N		85	150	36	2.44	2.39
NU2217E	NJ	NUP			85	150	36	2.68
NU317	NJ	NUP	N	NF	85	180	41	4.54	4.44
NU317E	NJ	NUP			85	180	41	4.81
NU2317	NJ	NUP	N		85	180	60	6.7	6.57
NU2317E	NJ	NUP			85	180	60	7.16
NU1018	NJ	NUP	N		90	140	24	1.33	1.31
NU218	NJ	NUP	N	NF	90	160	30	2.3	2.25
NU218E	NJ	NUP			90	160	30	2.44
NU2218	NJ	NUP	N		90	160	40	3.1	3.04
NU2218E	NJ	NUP			90	160	40	3.33
NU318	NJ	NUP	N	NF	90	190	43	5.3	5.18
NU318E	NJ	NUP			90	190	43	5.72
NU2318	NJ	NUP	N		90	190	64	7.95	7.79
NU2318E	NJ	NUP			90	190	64	8.56
NU1019	NJ	NUP	N		95	145	24	1.4	1.38
NU219	NJ	NUP	N	NF	95	170	32	2.78	2.72
NU219E	NJ	NUP			95	170	32	3.02

More information

With the absence of ribs, either the inner or outer ring will move freely so as to adjust to axial movement hence can be used as free side bearings. This enables them to absorb shaft expansion to a certain extent, relative to the housing position.

NU and NJ type cylindrical roller bearing produce high performance results when used as free side bearings because they possess the required characteristics for that purpose. NF type cylindrical roller bearing also supports the displacement of the axial to a certain extent in both directions and therefore can be used as a free side bearing.

In applications where heavy axial loads have to be supported, cylindrical roller thrust bearings are the most suitable. This is because they are designed to contain shock loads, are stiff and the axial space required is little. They only support axial loads that are acting in a single direction.

Detailed applications

Specifically, our cylindrical roller bearings can be used in industrial transmission, automotive, electric motor, generator sets, elevating machinery, machine tool spindles as well as internal-combustion engines, etc.

Packaging & Shipping

bearing packing and pallet picture:

1.color single box package 1 pcs.

2.outer container,five larges of corrugated paper cases 300*260*190mm 10 pcs.

3.Tray:material quality do not smoke to steam woodiness lron quality project plastic 1200*950*750mm.

4.pressing non-standard bearing bearing repair is our advantage.

Of course we can make packaging according to customer's requirement !
