SAP120 асфальтированное дорожное оборудование асфальтовый завод 120 тонн в час

SAP series Stationary Asphalt Mixing Plant own wide adaption range and ideal for middle and large projects.
Supply various capacity stationary asphalt plants for different projects across the world.
SINOSUN asphalt plant is designed for international market and personalized customer demand, with a wide facility choice from 40 TPH to 240 TPH.
SAP series asphalt hot mix plant is the final solutions for customer requirement of quality, environment-friendly and economically investment.
With complete set of accessories,SINOSUN asphalt batch mix plant can process different material,10%-35% RAP, modified bitumen emulsified bitumen etc ,and also produced special products,such as stone mastic asphalt,colorful asphalt ,additives of liquid ,fibers of granular or cotton-shaped.

Parameter of SINOSUN hot sale stationary SAP120 portable hot mix asphalt plant

Components of SAP120 batching asphalt mixing plant machinery

1,Cold Aggregate Feeding System
SAP120 Asphalt Mixing Plant consists of 4 units of cold aggregate bins. Each cold aggregate bin includes one set of variable speed discharge belt feeder.
There is one set of alarming device in each cold aggregate bin in case of no aggregates supplying during operation.
The belt feeder adopt variable speed to discharge the aggregates.
Each aggregate bin has a screen to prevent the big size being discharged into the drying drum.
The Sand bin adopts vibrating device to prevent sticky aggregates hard being discharged into the belt feeder.

2,Drying system
The drying drum adopts four wheel friction to work.motor is started by reducing voltage, insulating layer adopted in outside of drying drum. And drying surface is packaged by stainless steel.
Burner choose well-known brands (opel, riello, black &decker, etc.), more can choose such as coal or natural gas combustion medium.
Cylinder and ejecting blade of heat-resisting steel manufacturing, longer life.

3,Hot aggregate elevator
The hot aggregate elevator adopts flat link chain to drive, the chain bucket has protective device.
The non-return device adopted in drive wheel can prevent the chain from reversing.
4,Mixing tower
(1)The vibrating adopts four layer’s design. The outside of screen is closed by protective cover, so that dust won’t going out from the screen.
(2)Uniaxial external structure make the maintenance work more convenient.
(3)Hot aggregate storage bin has level indicator,the hot aggregate storage bin has big volume so that feeding aggregates will be more stable.
(4)Aggregate weighing system and filler weighing system all have anti-dust device.
(5)The bitumen adopt secondary weighing, which will be more accurate. The usage of spiraling pump discharge the bitumen into the mixer uniformly.
(6)The asphalt mixer adopt twin shaft design, pneumatic discharging finished product. Surrounding of discharging gate including attemperator.
(7)The high locating structure can guaranty the dump truck loading the finished products easily.
(8)The bottom of finished bin can be extensible.

5,Dust Collecting System
Adopting primary dust collecting by gravity, secondary dust collecting by water filter dust collecting design,which is more environmentally friendly and more environmentally friendly.
The bulky grain can be recycled after primary dust collecting.
The dust can be discharged or reused after secondary dust collecting,higher environmental standards.

6,Bitumen System
Asphalt by heat conduction oil heating, convenient operation, safe and reliable. Asphalt aging.
Heat conduction oil central heating, more economical and practical.
Capacity expansion of asphalt tank number is simple and convenient ,and the cost is low.
7,Filler system
Mineral powder is centralized storage by storehouse,and equipped with centralized dedusting, no dust overflow.
Powder storehouse is equipped with high and low material level meter, real-time detection powder capacity.
8,Electronic Control
(1)We adopt famous international brand (like SIEMENZ, Schneider, ABB) electronic elements, working performance is reliable and stable.
(2)The adoption of PLC and Industrial computer make the operation more easy.
(3)The Multifunctional printer can print and storage date anytime.
(4)Big capacity formula function can meet client’s various need.
(5)Optional remote fault detection.
(6)Container type control room, strong and durable, economy and beautiful.
(7)The Manual/automatic operation can be shifted freely.

For over years, we supplied the asphalt industry with high quality asphalt batching plant parts, mobile asphalt mixing plant,continous asphalt mixing plant and other reletaed products.

Our asphalt  plant products are cost effective, user friendly, easy to maintain and strong after - sales services.

Now these asphalt plant products  have been widely used in home and abroad road construction project, such as Russia, USA,Thailand, Romania , Poland , Brazil , Philippines , Indonesia, Peru, Canada, Bangladesh etc. In Africa , we have exported to Ethiopia , Angola , Algeria and Libya etc.

SINOSUN is one of China’s dominant and professional manufacturers and exporters of Precisioned Asphalt Mixing Plants and related asphalt plant equipment.

We mainly supply:

1.Stationary asphalt mixing plant (SAP series)

2.Recycle asphalt mixing plant (SR series)

3.Mobile asphalt mixing plant ( MAP series)

4.Continuous asphalt mixing plant (CAP series)

5.Twin-shaft asphalt mixing plant (QLB series)

6.Twin-drum asphalt mixing plant (SLB series)

7.Emulsion Bitumen Plant (RH series)

8.Bitumen Melting Machine (DT series)

Q:Which countries your equipment have been exported?

A:Thailand, Philippines, Indonesia, Myanmar, Russia, Bangladesh, Kazakhstan, Uzbekistan, Russia, Romania, Somalia, Kenya, Malawi, Nigeria, Togo, Mozambique, Oman, South Africa, America, Peru, Chile, Colombia, Venezuela, Australia, etc.

Q:How many workers are needed to operate one set of asphalt plant?

A:1 loader operator, 1 mechanical, 1 electrician, 1 supervisor ,1 the operator of the whole plant.

Q:How many days are used for installation of one set asphalt plant?

A:Around 20-30 days, according to local situation.

Q:Do you provide overseas erection and training service?

A:Yes, we can send experienced engineers to your country, guide erection and commissioning and train your workers how to operate the plant.

Q:How long is the delivery time?

A:30-40 days, according to different configuration. We promise to delivery on time.

Q:Can you sent me some spare parts freely?

A:Some spare parts will be sent to you together with asphalt plants freely.

Q:How to go to your asphalt plant factory easily?

A:Our city has airport. If by air, you can fly from Guangzhou/Beijing/Shanghai no more than 2 hours. Also you can fly to Zhengzhou, we send car to pick you up there.

Q:Can I visit your factory?

A:Of course. We warmly welcome you to visit our factory. And we provide you great services like airport pick up, hotel booking, etc.

Q:How long is the warranty of your asphalt plant?

A:12 months

Q:What payment terms you accept?

A:We accept T/T, L/C,D/A,D/P, Western Union, MoneyGram and other ways  according to the practical situation.

Get the quotation of asphalt mixing plant, welcome contact us  at any time.

Pls following us for more information of asphalt plant and related equipment.
