S200 8P4S 98011301 8 Порт 10GE SFP сетевой коммутатор

S200 8P4S 98011301 8 Порт 10GE SFP сетевой коммутатор

Категория: >>>
Поставщик: Chongqing Yujia Technology Co. Ltd.Chongqing Ltd.

Цена:130,00-159,00 $*

Количество:

В избранное

Описание и отзывы

Характеристики

Product Description

The S1700 series switches are next-generation energy-saving Ethernet access switches. They provide easy installation and maintenance methods and various service features to help users build secure, reliable, and high-performance networks. The S1700 series switches can be widely used in Ethernet access scenarios such as small- and medium-sized enterprises, Internet cafes, hotels, and schools.

Part Number	98011301
Model	S200-8P4S
Description	S200-8P4S (810/100/1000BASE-T ports, 4GE SFP ports, PoE+, AC power)

Details Images

Specification

Wide [mm]	300.0 mm
Depth [mm]	220.0 mm
Height [mm]	43.6 mm
Chassis height [U]	1
Weight with packaging [kg(lb)]	3.17 kg (7 lb)
Weight without packaging [kg(lb)]	2.25 kg (4.96 lb)
Typical power consumption [W]	28.4
Maximum power consumption [W]	- Not providing the PoE function: 38.6 W - 100% PoE loads: 162.6 W (PoE: 124 W)
Typical heat dissipation [BTU/hour]	96.9
Maximum heat dissipation [BTU/hour]	- Not providing the PoE function: 131.71 - 100% PoE loads: 554.81
Heat dissipation mode	Heat dissipation with fan, intelligent fan speed adjustment
Power supply mode	AC built-in
Rated input voltage [V]	AC input: 100 V AC to 240 V AC, 50/60 Hz
Input voltage range [V]	AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz
Maximum input current [A]	3 A
Number of card slots	0
Number of power slots	0
Memory	512 MB
Flash memory	512 MB
Redundant power supply	Not supported
Types of fans	Built-in
Noise at normal temperature (acoustic pressure) [dB(A)]	30.5
Noise at normal temperature (acoustic power) [dB(A)]	42.2
Airflow direction	Air intake from left and front, air exhaustion from right
Long-term operating temperature [°C(°F)]	-5°C to +50°C (23°F to 122°F) (0 m to 1800 m altitude, non-industrial optical modules) -5°C to +55°C (23°F to 131°F) (0 m to 1800 m altitude, industrial optical modules with transmission distances less than or equal to 10 km)
Storage temperature [°C(°F)]	-40°C to +70°C (-40°F to +158°F)
Restriction on the operating temperature variation rate	When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). The switch cannot be started when the ambient temperature is lower than 0°C (32°F). The operating temperature ranges from -5°C to +45°C (23°F to 113°F) when optical modules with transmission distances greater than or equal to 70 km are used.
Long-term operating relative humidity [RH]	5% to 95%, noncondensing
Long-term operating altitude [m(ft.)]	0-5000 m (0-16404 ft.)
Storage altitude [m(ft.)]	0-5000 m (0-16404 ft.)
MTBF [year]	66.56
MTTR [hour]	2
Availability	>0.99999
Maximum number of physical ports on the entire device	12
Maximum number of 100GE ports	0
Maximum number of 40GE ports	0
Maximum number of 25GE ports	0
Maximum number of 10GE ports	0
Maximum number of GE ports	12
Maximum number of FE ports	12
1000M electrical interface	8
1000M optical interface	4
USB	Not supported
Console port	RJ45
Eth Management port	Not supported
Service port surge protection	Common mode: ±7 kV
Power supply surge protection	±6 kV in differential mode, ±6 kV in common mode
RPS input	Not supported
PoE	Supported
PoE power supply	Supported

Packing & Delivery

Company Profile

Chongqing Yujia Technology Co., Ltd. was established in 2010, we have been engaged in this industry more than 10 years. In order to meet the needs of customers, we have eatablished a perfect supply chain system to provide super products with reliable quality and reasonable price. we are devoted to offering Switches, Routers, OLTs, SDHs, Network Modules, Interface Cards, Security Firewalls, Wireless AP etc. our long-term aim is to provide users high-quality, efficient, economic, timely services. The rich experience of our wealth, serious and responsible attitude is our responsibility. Looking forward to establish long-term and win-win business relations with you.

Why Choose Us

1. More than 10 years of in-depth experience in the automotive field and technological innovation ability
2. Multi-brand, Full series. Achieve cooperation with many brands, and provide first-hand vehicle source.
3. The same demand, more abundant vehicle sources; the same product, more favorable price; the same price, shorter delivery time; the same delivery time, more convenient service
4. One-stop service. Vehicle export service capability, serve the whole process.

FAQ

1. Why choose us?
We are the leading Chinese supplier of quality networking equipments and we have over 10 years experience in this field.

2. What's the quality of the products?
All the items are brand original.

3. How to place an order?
After customer confirm the order , we will create an order as your request. We accept many terms of trade such as T/T,
Wester,Union, Alibaba Orders, Alipy and etc.

4. How about the shipment?
We deliver products by FEDEX, DHL, ARAMEX, EMS, UPS, TNT and Air shipping & Ocean transportation. We are also able to deliver goods to your forwarder in China if you need.

5. How about the warranty?
1 Year warranty.

6. Do you test all your goods?
A: Yes, we have professional engineer to test all devices before shipping.

7. What if machine not work during warranty?
Technical support avaliable,if can't fixed, replacement or return with full refund acceptable.

8. How about your main products?
Our product lines include Switches, Routers, SFP Modules, OLTs, SDHs, Network Modules, Interface Cards, Security Firewalls, Wireless AP etc.

9. What brand of products do you offer?
A: We can provide all common brands in the market
