Гидравлический пресс 63 ~ 3000 тонн может использоваться для заводского производства и обеспечить соответствующее решение производственной линии
28 368,00-82 800,00 $
Бесплатная доставка Лидер продаж двойной нагревательный элемент 2 тонны гидравлические ручные мини пластины термопресс Масляный Пресс сделано в Китае
- Категория: >>>
- Поставщик: Jiangsu Miya Cnc Machine Tool Manufacturing Co. Ltd.Jiangsu Ltd.
Сохранить в закладки 1601375834427:
Описание и отзывы
Характеристики
Products Description
Item | unit | Y27-200 | Y27-250 | Y27-315 | Y27-400 | Y27-500 | Y27-630 | Y27-800 | ||
Nominal force | KN | 2000 | 2500 | 3150 | 4000 | 5000 | 6300 | 8000 | ||
Return force | KN | 240 | 400 | 600 | 500 | 900 | 850 | 900 | ||
Worting pressure | Mpa | 25 | 25 | 25 | 25 | 25 | 25 | 25 | ||
Cushion pressure | KN | 400 | 400 | 630 | 630 | 1600 | 2000 | 2000 | ||
Daylight of side | mm | 1120 | 1120 | 1200 | 1250 | 1500 | 1500 | 1500 | ||
Stroke | Upper slide | mm | 710 | 710 | 800 | 800 | 900 | 900 | 900 | |
Cushion | mm | 250 | 250 | 300 | 300 | 300 | 350 | 300 | ||
Table size | L-R | mm | 900 | 1000 | 1200 | 1200 | 1400 | 1600 | 3200 | |
F-B | mm | 900 | 1000 | 1200 | 1200 | 1400 | 1600 | 2200 | ||
Cushion size | L-R | mm | 660 | 700 | 800 | 800 | 900 | 1120 | 2550 | |
F-B | mm | 600 | 600 | 650 | 650 | 900 | 1120 | 1700 | ||
Speed of side | descent | mm/s | 80 | 100 | 100 | 100 | 100 | 100 | 300 | |
Pressing | mm/s | 5-12 | 4-10 | 5-12 | 4-10 | 4-10 | 5-12 | 8-22 | ||
Return | mm/s | 70 | 60 | 60 | 60 | 50 | 60 | 200 | ||
Table hight above floor | mm | 700 | 700 | 750 | 750 | 700 | 500 | 500 | ||
L-R | mm | 2450 | 2600 | 2850 | 2850 | 3800 | 4150 | 5400 | ||
F-B | mm | 1300 | 1300 | 1500 | 1500 | 2600 | 2600 | 2900 | ||
Motor powes | KW | 15 | 15 | 22 | 22 | 30 | 2*22 | 96 | ||
Item | unit | Y27-1000 | Y27-1000A | Y27-1250 | Y27-1600 | Y27-2000 | Y27-2500 | Y27-3000 | ||
Nominal force | KN | 10000 | 10000 | 12500 | 16000 | 20000 | 25000 | 30000 | ||
Return force | KN | 1250 | 1250 | 1250 | 2000 | 2000 | 2250 | 2250 | ||
Worting pressure | Mpa | 25 | 25 | 25 | 25 | 25 | 25 | 25 | ||
Cushion pressure | KN | 1600 | 1600 | 1600 | 2400 | 2400 | 3000 | 3000 | ||
Daylight of side | mm | 1800 | 2200 | 1800 | 2000 | 2100 | 2000 | 2500 | ||
Stroke | Upper slide | mm | 1000 | 1500 | 1000 | 1200 | 1300 | 1100 | 1600 | |
Cushion | mm | 365 | 500 | 400 | 400 | 350 | 400 | 400 | ||
Table size | L-R | mm | 3200 | 4000 | 4000 | 4000 | 4500 | 4500 | 4500 | |
F-B | mm | 2300 | 2300 | 2500 | 2500 | 2500 | 2500 | 2500 | ||
Cushion size | L-R | mm | 2550 | 3500 | 3370 | 3820 | 3750 | 3820 | 3820 | |
F-B | mm | 1800 | 1800 | 1870 | 1870 | 1800 | 1700 | 1600 | ||
Speed of side | descent | mm/s | 300 | 300 | 350 | 350 | 350 | 350 | 350 | |
Pressing | mm/s | 12-30 | 12-30 | 12-30 | 12-30 | 12-30 | 12-30 | 12-30 | ||
Return | mm/s | 250 | 250 | 300 | 300 | 300 | 300 | 300 | ||
Table hight above floor | mm | 900 | 400 | 400 | 400 | 350 | 350 | 350 | ||
L-R | mm | 5400 | 6200 | 6200 | 6200 | 6700 | 6700 | 6700 | ||
F-B | mm | 3000 | 5200 | 3200 | 3200 | 3300 | 3300 | 3300 | ||
Motor powes | KW | 160 | 160 | 160 | 200 | 380 | 410 | 500 | ||
Our Advantages
2.The four-column structure is simple, economical, and the frame structure has good rigidity, high precision, and strong anti-eccentric load capacity.
3.The hydraulic control adopts an integral cartridge valve integrated system, which reduces the leakage point, reliable operation and long service life.
4.The electrical system controlled by PLC is compact in structure, sensitive, reliable and flexible.
5.The working pressure stroke can be adjusted according to the process requirements within the specified range, and the operation is simple
6.Through the selection of the operation panel, not only can the two molding processes of fixed range and constant pressure can be realized, but also the three process cycles of pad and pad ejection can be realized
