Биметаллический термостат KSD020

Категория: Запчасти для газового водонагревателя >>>
Поставщик: Ningbo Newlite International Trade Co. Ltd.Ningbo Ltd.

Цена:0,50 $*

Количество:

В избранное

Описание и отзывы

Характеристики

Specifications

good quality , competitive price

1. APPLICATION

This specification is special to thermostat model No. KSD020.

2. CONSTRUCTION

2.1 TYPE

Single pole, single contact point, fixed temperature, and snap action type thermostat with bimetal.

2.2 APPEARANCE

To exclude the thermostat with crack, dirt, rust, stain, etc, and thermostat to be considered disqualification as at appearance.

2.3 TERMINAL STRENGTH

Terminal can’t have displacement and damage, when terminal endure thrust force (5Kgs) and pull force (10 Kgs).

2.4 DIMENSION

See the attach page.

3. ELECTRICAL RATING

3.1 Rated voltage: 250V

3.2 Rated current: 10A (Resistance load)

3.3 Frequency: 50 HZ

4. PROPERTY

4.1 OPERATING TEMPERATURE

OPEN TEMPERATURE: 83±3°C

CLOSE TEMPERATURE: 65±5°C

4.2 INSULATION RESISTANCE

Insulation resistance is to be over 100MΩ at check with DC 500V

4.3 INSULATION INTENSITY

Not to be cause electronic breakdown at AC 3 KV for 1 second or AC 1.5 KV for 1 minute at 50 HZ between terminals and cover.

4.4 INSULATION SPACING

To be complied with UL, TUV, CQC standard.

4.5 CIRCUIT RESISTANCE

To be under 50 mΩ.
