Цена по прейскуранту завода полу авто четыре полости ПЭТ пластиковые бутылки выдувная формовочная машина
- Категория: Выдувная машина >>>
- Поставщик: Jiangsu Faygo Union Machinery Co. Ltd.
Сохранить в закладки 1700005009823:
Описание и отзывы
Характеристики
Product Description
4 cavity Semi-automatic PET Bottle Blowing Machine
Configuration
Components Name | Brand | Origin |
PLC | Bothfit | China |
Cylinder | Yongcheng | China |
Blowing valve | Yongcheng | China |
Operating valve | Yongcheng | China |
Circuit Breaker | DELIXI | China |
Workflow
(Take one cavity for exapmle)
Technical Parameter
Model | 4 cavity Semi-automatic PET Bottle Blowing Machine | ||||
Theoretical output | 1600~2000 pcs/h | ||||
Finished bottle | Max. bottle volume | 2L | |||
Max. neck diameter | 38mm | ||||
Max. bottle diameter | 38mm | ||||
Max. bottle height | 460mm | ||||
Cavity | 1 cavity | ||||
Mold thickness | 210 mm | ||||
Open stroke | 160mm | ||||
Power voltage | 380v/3Phase/50HZ | ||||
Installation power | 17.5 kw | ||||
Actual power consumption | 8kw | ||||
Airsource | Recommend air compressor | 1.2m³/min 30Kg | |||
Cooling water | Recommend waterchiller | 5HP | |||
Blowing machine size | Length*width*height/weight | 2000*630*1570mm/850kg | |||
Heater size | Length*width*height/weight | 2170*565*1360mm/450kg | |||
Detailed Image
High Pressure Air Compressor (1.2m3/30kg)
1.Air Discharge: 1.2 m3/min
2.Pressure: 3Mpa
3.Motor Power: 15kw
4.Tank: 150L
5. Running speed: 730 r.p.m
6. Weight: 600kg
7.Package: 1900mm*1000mm*1300mm
Air Dryer (2.0m3/30kg)
1.Throughput: 2.6m3/min
2.Inlet pressure: 3 Mpa
3.Inlet temperature: below 80℃
4.Dew point: 2℃——10℃
5.Refrigerant: R-22
6.Power:0.22kw
7.Size:630mm*420mm*800mm
8.Weight: 63kg
Water chiller 5HP
1.Chilling capacity: 11180Kcal/hr
2. Max.Flow rate of chilled water: 90 Ltr/min
3.Tank capacity: 50L
4.Power: 3.75kw
5. External dimension: 1200*680*1350mm
6. Weight: 195kg
Air Filter (2.0m3/min,30kg)
1.Flow rate: 2.6m3/min
2.Weight: 17kg
3.Height: 660mm
4.Diameter:300mm
Related products
Semi-auto series
Full auto series
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Our comapny
Faygo Group is located in Korean Industrial Park, Zhangjiagang City, Jiangsu Province, Phoenix, covering more than 40 acres,and many have a standard plant and warehouse. Companies have strong scientific research and technology. professional research and development and manufacturing air compressors in the industry has made quality leader. Funds into U.S. companies and the introduction of high-tech companies to a new levelon the production of high-tech products reached the international first-class level. The foreign hired Engineers Singapore Permanent factory site guidance to ensure a reliable and stable product quality.Advantages of our products are handsome in appearance,with a compact, low noise, small vibration, wind cooling, no need to install, qualit really a 24-hour serice.The companysproducts are widely used all over the world, especiallyy in the power station, blowing factloy is very popular.
The company with distribution services nitis in Singapore,. Manila, Bangkok. Kuala Lumpur. Karachi, Souh Arica, NewZealand, and more convenient for users and ficient services.
The company with distribution services nitis in Singapore,. Manila, Bangkok. Kuala Lumpur. Karachi, Souh Arica, NewZealand, and more convenient for users and ficient services.
Our staff
Playing basketball
New Year Day's party
Tour of Tonglu
Our customers
Through thick and thin.
Our service
1.One year warranty. During warranty, we provide free of charge for repairing cost.
2. Lifetime maintenance. After-sales department can provide life long maintenance service.
2. Lifetime maintenance. After-sales department can provide life long maintenance service.
Our certification
FAQ
Q:Are you machinery factory or trading company?
A:We are machinery factory
Q:If we have very special request for the production line,could you help me to do the design?
A:Experienced mechanical designer customized-design provided.
Q:Installation and stuff training available from you?
A:Yes, our engineers will guide machine installation and train your workers.
Q:How can we visit your company and machines?
A:We are located in Zhangjiagang City which is about 2.5 hours nearby Shanghai Airport.If customer want to visit our factory, we
will pick up you at the airport.
Q:What`s the payment method?
A: T/T, L/C,Western Union,etc
Q:How long is the warranty?
A:1 year
Q:How long is the delivery time?
A:Under normal conditions, products are delivered within 45 working days.
Q:How can I know the stauts of my order?
A:We will send you photos and videos of your order at different satge in time and keep you informed of the latest information..
A:We are machinery factory
Q:If we have very special request for the production line,could you help me to do the design?
A:Experienced mechanical designer customized-design provided.
Q:Installation and stuff training available from you?
A:Yes, our engineers will guide machine installation and train your workers.
Q:How can we visit your company and machines?
A:We are located in Zhangjiagang City which is about 2.5 hours nearby Shanghai Airport.If customer want to visit our factory, we
will pick up you at the airport.
Q:What`s the payment method?
A: T/T, L/C,Western Union,etc
Q:How long is the warranty?
A:1 year
Q:How long is the delivery time?
A:Under normal conditions, products are delivered within 45 working days.
Q:How can I know the stauts of my order?
A:We will send you photos and videos of your order at different satge in time and keep you informed of the latest information..
