Handheld Portable Thin Client 5000-A
Introduction of Thin Client PC Station:
Like all Thin-Client access terminals, the 5000-A Thin-Client dramatically cut computing costs by sharing the untapped power of standard PCs. Best of all, IT staff and end users do not need special training because our solutions are easy to manage, eco-friendly and compatible with standard PC applications. And like all of Thin-Client series, the 5000-A Thin-Client can use standard Ethernet infrastructure, so that your users can be located as far away from your shared PCs as you need them to be.
The 5000-A Thin-Client bring enhanced graphics performance (with improved color depth and widescreen support) in a stylish new smaller chassis (just 1 inch tall and 4.5 inches square) that takes absolutely no desktop space at all when mounted to the back of a monitor. We even include the mounting bracket at no charge.
Of course, the 5000-A Thin-Client include VGA support (resolutions up to 1024x768 or 1280x1024 for widescreen), an Ethernet connection, PS/2 keyboard and mouse ports, audio output, and power cable connections. The 5000 Thin-Client does not have the USB port or microphone input and is recommended for the ultimate in economy and security.
Features for Thin Client PC Station:
| Hardware | ||
Size
| Access Device: 115*115 *26 mm Shipping Size: 251*205*68mm | ||
Power Supply
| Input: 100-250 VAC, 50-60 Hz; Output: 5 VDC, 2 A Nominal consumption: 5 Watts | ||
Front LED
| Power: connection to power supply LAN: connection to network Ready: connection to host PC | ||
Rear Ports
| 01 –Speaker Output 02 – Keyboard Port 03 – Mouse Port 04-– LAN port (RJ45)
| 05 – Video port 06 – DC Power Input 07–On/Off Power Switch | |
Connection to Host PC | Via 100 Mb/s switched Ethernet connection | ||
Video Resolution
| 640x480, 800x600, 1024x768 (at 60 or 75 Hz refresh rate), 1280x1024 (~63 Hz). All feature up to 16-bit color support. | ||
Audio | Stereo output via speaker port | ||
Data Security
| No USB ports on terminal ensure absolute data security | ||
Internal HW
| All solid-state design, no moving parts, no fans, no local user storage SPEED System-on-Chip with SDRAM and flash Embedded SPEED operating firmware (no local user OS) | ||
Reliability (MTBF)
| >>100,000 hours (calculated using Bellcore Issue 6 TR-332, Case 2, Part I at 40°C) | ||
HW Security | No local user storage | ||
Software | |||
Max Users Per PC
| 30 users* when using a server host OS (i.e. Windows Server 2003) 10 users when using a desktop OS (i.e. Windows 2008/7) | ||
User Software | Terminal services software | ||
OS supported | Microsoft: Windows XP Professional and Media Center Edition 2005 Windows Server 2003, Small Business Server 2003 Linux: several variants (refer to support section of Website for latest supported revisions of Linux) |
Configuration for Thin Client PC Station:
With the 5000-A Thin-Client solution, each user has an individual workstation that consists of a standard monitor, keyboard, mouse . However, instead of connecting directly to a PC, these peripherals connect to the Thin-Client Series access terminal.
The very inexpensive and highly reliable Thin-Client Series access terminal connects to our terminal services software on the host PC over standard Ethernet cables (plus routers, switches, etc.). Our terminal services software enables the host PC to create unique and simultaneous user sessions so that each user gets their own rich and robust PC experience. A PC that is running a desktop OS (such as Microsoft Windows XP?) can support up to ten users. Server operating systems (like Microsoft Windows 2003 Server? or Linux) support up to 32 simultaneous users.
By delivering all the key components of this multi-user computing system, Thin-Client uniquely delivers a high-performance solution at the lowest possible cost. Thin-Client breaks the affordability and complexity barrier that has limited computing from being deployed everywhere, to everyone.
Kit Contents
Each Thin-Client terminal comes with a power adapter, a CAT 5e cable, mounting bracket and documentation. A CD with the Thin-Client terminal services software is included. Note that the host PC, user peripherals and networking equipment are not included and must be purchased separately.
Contents and packing for Thin Client PC Station:
About Us - Wotng
We are highly committed to researching, developing and manufacturing of innovative electronics products. We have been closely following the world consuming trends and in position to provide our clients with the best and latest items at the most competitive prices.
As a professional manufacturer and exporter, we fully understand that quality is of vital importance to our sustainable development. Thanks to our strict QC and test procedures carried out from raw materials, in-process production and final inspections, we have been proud that every piece of our products delivered to our clients is in good condition and meet with their requirements. Meanwhile, we highly value our service, ensuring that each order reaching to us is delivered on time.
Furthermore, our all-around after-sales services can provide our clients with enough guarantees on the repair, replacement of units with problems. Apart from choosing our existed items, our clients are warmly welcome to develop new items in cooperation with us. Our experienced R&D team can fully realize your dream designs. Take advantage of our products and services, you and us will surely have double-win relationship.
Factory and Mould Workshop:
Welcome OEM & ODM! Welcome to China. Welcome to our factory. Believe that we will have a win-win business together in near future! Contact us now!
Thin-Client Series Benefits:
Share one host PC with up to 32 users
Dramatically reduces acquisition & support costs
Easy to set up, maintain and secure
Connects to host PC via Ethernet
Supports Windows and Linux
Compact, reliable & energy-efficient (no moving parts)
Web-quality multimedia support
Our optional NControl and NShield software add more centralized management capabilities-such as remote monitoring and host PC data backup.
