High Speed CNC Tufting Machine for Nail Brush, it can make below products:

2

Product features

1. This machine with two drilling head and one tufting head, can realize drilling and tufting steel wire at the same time;

2. Largest wire length as 2cm-4cm it can adjustable. Servo motor wire, wire length convenient adjustment;

3. Panel control system, displays in either Chinese or English, simple to understand and easy to change types;

4. Wearing parts and spare parts are standardized designs to reduce hair mechanic technology dependence.

Technical characteristic:

1.Quantity of heads: 3 Heads, 2drilling heads and 1 tufting head.

2.The swing angle of Z-axis: 360°

3.Setting of Worktable: high-precision straight-line rail and ball screw, steady and durable.

4.Material of Brush Handle: Polyethylene, polystyrene, return materials, wood

5.Material of filaments: Stainless steel or iron,

6.Application: To make varieties of roller brushes

Technical parameters



temModelGSJ403
1Tufting StyleAnchor tufting
2NO. of Axis2 Axis
3Max Length of The Fiber (Outside The Hole)40mm
4Max Speed:3-4 Hole/Min
5Diameter of The Hole2.5-4.0mm
6Journey of X Axis600mm
7Journey of Y Axis300mm
9Max Program Quantity100 Pcs
10Air Pressure:5-6 Mpa
11Power Voltage:220V, 50HZ
12Machine Power:3 KW
14Size:1.47*1.4*2m
16Weight:1200KGS



Control SystemCNC Controller
Disturbance DisplayEnglish edition
Safty ProtectionOverload,Short circuit protection
LubricationAuto Lubrication System
Main Speed ControlFrequency inverter
Fiber box

Frequency inverter



  QQ20191107210314
