1500 мл 1:1 пистолет распылитель воздуха полиуретановая пена распылитель

Описание и отзывы

Характеристики

1500ml 1:1 spray gun air polyurethane spray foam

Product Description:

Material: Reinforced Nylon Handle

Aluminum Cartridge Holder

Aluminum Air Cylinder

Thrust: 625kg ~ 800kg

Air supply: 6.8 bar (100 PSI) ~ 10 bar (145 PSI)

Male: 1/4” BSP Air Supply Fitting (EU)

1/4” NPT Air Supply Fitting (US)

Weight: 3.9 kg

Product Features:

Workable Cartridges as following:

Illustration:

1. Tapping Hole

2. Aluminum bar

3. Front barrier chip

4. Inner hexagon screw

5. Front Handle

6. Compressed air supply

7. Trigger

8. Pressure regulating valve

9. Retract piston rod

10. Hand ring

Assembling Instructions:

Step One: Assembling 2.

Screw aluminum bars2 into tapping holes 1, and fasten them.

Step Two: Assembling 3 and 2.

Aim the three tapping holes on front barrier chip towards the inner tapping holes of aluminum bar, and fasten them by screwing the inner hexagon screw.

Step Three: Assembling 5.

Screw front handle into the side tapping hole of front barrier chip, and fasten it.

Function Keys Instructions:

5Front Handle /10Hand ring: Share the partial weight to reduce operator’s work when the volume of cartridge is large

6Compressed air supply: 1/4” BSP/NPT(International Standard)

7Trigger: Control the output of materials.

8Pressure limiting valve: Adjust the pressure from 6.8bar-10bar to control the output speed of material.

9Retract piston rod: Retract the piston rod back to the end-stop, and ready for changing new cartridge. .

Packaging & Shipping:

Packaging: Master Carton or to be customized.

Carton Size: 40*44*19CM

Packing: 1pcs/ctn

Weight:4.5kg/ctn

Our Service:

1. Online fast professional technical advice

2. Best quality products.

3. Best after-sales Service

4. Complaint Service

5. OEM produce, if none of our products meet your requirement, pls contact us for customizing.

Company Information:

Shanghai NSJ Hardware Factory is engaged in the R&D, production, sales, and after-sales services. We specialize in producing medium/high-grade caulking guns, AB cartridges, static mixers, blowing pumps, plastic sleeves and other related products.

While our products are being continuously up-graded in accordance with the demands from the market, we always insist on offering our customers the most-favorable prices, high-quality products, and first-class services.

Our products are export mainly to USA, Germany, Denmark, Russia, Singapore, Korea, Spain, Brazil and so on, where we get high reputation.

Factory Advantages:

Competitive prices, High-grade quality, Large production capacity, Short Lead time, OEM services.

NSJ’s Slogan:

Keep upgrading!

Do what you need!

Think what you think!

You just need to wait for the goods arrive without troubles bake at home!
