5 semi automatic LCD separator LY 948B screen separating machine for mobile phone screen refurbishment

This machine helps with the screen removal process of Samsung Galaxy S2, S3, Note,
iPhone 4 4S 4 and many other phone models.

Specifications

Automatic LCD Separator Machine

Package: dimensions 61x47x42cm

Weight: 14.6kg

Volume weight:  24.08kg

separate lcd

semi-automatic separator hot plate machine

low noise, economical and practical

Fast, high efficiency

The machine is used for separating lcd and touch screen of Apple, Samsung, HTC as well

as other cell phones. if the LCD is still working well, you just need to replace a touch screen

Comes with some small tools, make the operation convenient and easily

Can break up the glue(OCA) at the same time, and water-binder (LOCA) products

Low noise, economical and practical, greatly reduce the production cost

With motor drive, speed and temperature are adjustable, quite convenient

Fast, high efficiency, and easy operation

Product size range: length: 3.3inch, width: 6.3inch, diagonal: 6.8inch

Note 1: As different country has different current or voltage standard,  this machine can

work normally the voltage between 110v from 240v, so you do not need to worry this question.

Note 2: this machine do not include alloy wire, so if you need it, please order TOOL-234

Operating Instruction:

1: Turn the power switch on

2: Turn the temperature controller on, and set the temperature. ( usually lower than 100 degree)

4: Put the wire on by the manual mode

5: Adjust steering button

6: Push the, and adjust the motor speed by rotary switch

Note: Adjust the steering button up, the machine will run clockwise; Adjust the steering

button up, the machine will run anticlockwise; Middle position will run clockwise and

anticlockwise alternatively.

Compatible with:

Most smartphone: iPhone 4 4S 5, Samsung, HTC, Sony etc.
