Высококачественный ПТФЭ лист 1 2 мм * 0 5

Сохранить в закладки 1991577983:


Цена:*

Количество:

  • В избранное

Описание и отзывы

Характеристики


1.2mm*0.5mm high quality ptfe sheet

PTFE Molded sheet is manufactured by suspend PTFE resin after molding. It has the best ability to anti chemistry corrosion, and non-aging, and can be used under -180C ~ +260C without load, and it has the lowest fiction coefficients in known solid materials.

Skived PTFE Sheet, Virgin white Ptfe Sheet of advantages

  • Unaffected by almost all chemical
  • Continuous use at high temperatures
  • Slippery non-stick surface
  • Outstanding dielectric properties
  • Outstanding chemical resistance
  • Superb electrical insulating properties
  • A wide working temperature range from -180 °C + 260°C
  • A very low coefficient of friction, resulting in unique non-stick behaviour
  • High dielectric properties
  • Non-toxic

Virgin White PTFE Sheet, plastic skived ptfe sheet of properties

  •  Excellent chemical resistance
  • Lowest co-efficient of friction
  • Highest operating temperature and stability
  • Physiologically inert
  • Excellent electrical properties

Virgin PTFE Sheets,  plastic ptfe sheets of size

Item

Style

Thickness

Width

Length







PTFE Sheet

(Teflon Sheet)







Skived

0.1 mm ~ 10 mm

1000mm, 1200mm,

1500mm

1000mm ~ 10,000mm

Molded

2 mm ~ 100 mm

300mm, 600mm, 900mm,1000mm,1200mm



300mm, 600mm, 900mm,1000mm,1200mm

Filled

1mm ~100 mm

1000mm, 1200mm,

1500mm

1000mm ~10,000mm



100% virgin PTFE sheet, ptfe sheet products of technology datas

Properties

Unit

Result

Apparent density

g/cm3

2.10~2.30

Tensile strength(min)

Mpa

25

Uitimate elongation(min)

%

200

Working Temp

°C

-180~260

Melting point

°C

327

Produce Max. Temp

°C

385

Hardness Rockwell



M65

Dielectric Strength

 KV/mm

 59

Surface Resistivity

Ohms

>10^7

 Flammability UL94



530





























Skived PTFE Films_meitu_43 .jpgP1030728 .jpgP1000702 .jpg








Test Report 1_meitu_1



Delivery terms







u=560547994,114097473&fm=23&gp=0u=4097423645,946755953&fm=23&gp=0u=1806426672,2315390374&fm=21&gp=0



1: Express Delivery

1) Advantage: Fast (3~6Days), door-to-door, wide-area coverage

2) Volume&weight restricted

3) Advices: Good for samll cargo



2: Sea transportation

1) Advantage: The cheapest, volume unlimited

2) Diavantage: long sailing time(15~30days), influenced by climate and port conditions

3) Advices: Bulk cargo, loose time



3: Air transportation

1) Fast(4~5days) , simple packing

2) The most expensive, volume restricted

3) For valuable cargo, urgent need
