  95hp 4*2 DONGFENG propane lpg gas delivery truck 3000L-5500L





       LPG Dispensing Truck  is mainly used to transport LPG,include propane, isobutane, etc liquefied petroleum gas. We can manufacture LPG Gas Tank Truck  from 5.5 m3 to 35.5 m3, and we also can manufacture LPG Storage Tank from 5m3 to 120 m3, can manufacture LPG trailer from 30 m3 to 59.52 m3.



 Product Description





Production notes:



1 DONGFENG 4*2 chassis, 95hp
2 More than ten year's  Professional production experence
3 ISO9001, 3C certificate
4 High Quality,best price

5 Factory direct sale



Techinical Parameter of 95hp 4*2 DONGFENG LPG Dispensing Truck 3000L-5500L





Product Name

DONGFENG propane lpg gas delivery truck

Product Brand

DONGFENG-CLW

Overall Dimension(mm)

5900×2045×2600

Curb Weight (kg)

4385

Wheelbase (mm)

3300

Number of Axles

2

Tank volume(L)

3000

Max Speed(km/h)

80

Cab Allowed Persons

3

Cab type

single row, air conditioning

Chassis Technical Parameter

Chassis Model

EQ1070

Chassis Manufacturer

DONGFENG Automobile Co., Ltd

Gear Box

5 forward and 1reverse

Transmission type

Manual

Steering Type

RHD

Brake System

Air brake

Leaf Spring No.

8/9+5

Number of Tire

6 with a spare

Drive Type

4*2

Tire Spec.

7.00-16

Engine Technical Parameter

Engine Model

          CY4102-C3F

Engine Brand

DONGFENG CHAOYANG

Fuel Type

Diesel

Emission Standard

Euro 2

Displacement ( ml )

3856

Power (KW)

70(95hp)

Superstructure Parameter

Storage medium

Propane

Unit volume filling capacity

0.42ton/m3

Tank thickness(mm)

10mm,two ellipsoid head form 10mm

Tank material

Q345R carbon steel

Main equipment

1. Equipped with one LPG dispenser with one LPG Filling gun, dispenser to run on electric 220 Volt (Single Phase).

2. Equipped with one LPG filling pump with motor run on electric 220 Volt(Single Phase)(adopt hydraulic motor, more safer)

3. Equipped with one LPG inlet, one LPG reflux outlet on one side, safety valves, thermometers, pressure gauge, emergency shut-off valves, lever meter, fire extinguishers, anti-static grounding tape,





Multi-faceted Show of 95hp 4*2 DONGFENG propane lpg gas delivery truck 3000L-5500L



 conew_ 332.jpg

 conew_ 347.jpg

conew_ 349.jpg



LPG filling Gun



conew_ 334.jpg



Hydraulic motor and LPG gas pump:



conew_ 338.jpg



LPG Filling machine:



conew_ 339.jpg

thermometer







 conew_ 350.jpg



pressure gauge



conew_ 354.jpg



valve box :

conew_ 356.jpg




Company Information



        We,ChengLi Special Automobile Co., Ltd , which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. Our leading productions include more than 300 types of trucks such as Water truck, Fecal suction truck, sewage suction truck, Garbage truck, Road sweeper, Fuel tank truck, Van truck,  Chemical liquid truck, Concrete mixer truck, Pressure vessel, etc.We have registered trademark "CHENLIWEI" and the products code is CLW. We have solid technology, flawless inspection, advanced equipments, reliable quality and flexible modes of operation. What's more, we have roundly passed the CERTIFICATON of ISO 9001-2008, the3C CERTIFICATION (China Compulsory Certification) and other certifications that export needed.







         Since our company was established in Sep.2004, we always strive for the survival by the quality, pursue of development by efficiency. In the past ten years, we had 30% market share of the Special Automobile in China market. From 2004 year, we have entered the international market. And we have established long-term cooperative relationship with many countries.
