Alibaba express новый продукт горелка отработанного масла/горелка

Сохранить в закладки 2018900274:


Цена:*

Количество:

  • В избранное

Описание и отзывы

Характеристики



Product Description


Alibaba express new product waste oil burner/burner/ pellet burnerb-30&40



Specification:

Oil consumption: 2 - 30 (KG/Hour)
Output heat power: 24-355( KW)
Output heat: 20,400-306,000(KCal/h) / 80,000-1,200,000 (Btu/h)
Distance from fire gun to flange: 173mm / 6.8 inch
Distance of screw bore in the flange: 160x160(mm)
Fire gun dia. 114mm / 4.49 inch
Compressed Air Pressure: 0.05-0.1MPa
220V/50Hz & 110V/60Hz both available;
Package weight: 30KGS / 66LBS

Other model type:

MODELB-05B-10B-20B-30
Heat Range(KCAL/H)20,400-51,10020,400-102,00020,400-204,00020.400-306,000
Heat Range(BTU/H)50,000-200,00080,000-400,00080,000-800,00080,000-1,200,000
Output heat Power(KW)24-5924-23724-23724-355
Fuel input (KG/H)2-52-202-202-30
Fuel input (G/H)0.5-1.30.5-2.60.5-5.20.5-7.9
Air Pressure(MPa)0.05-0.10.05-0.10.05-0.10.05-0.1
Power Supply(AC)220v/110v220v/110v220v/110v220v/110v
Cabinet Dimensions(mm)520*440*310520*440*310520*440*310520*440*310
N.W.(KG):27272728



Features:

1.  Various fuels are applicable, e.g. used engine oil, used vegetable oil, used crankcase oils, used Glycerin, used Hydraulic oil, used synthetic oils, waste machine shop cutting oil, waste mineral spirits solvent, waste grades #1, #3, #4 heating oils, waste mixed heavy oil etc., as well as regular oils, such as diesel, etc.
2. Automatic ignition, workers-nursing unnecessary.
3. Flame adjustable freely by air-inlet controller easily; from the “Observing Window” operators can easily see changes of the flame.
4. All parts tested thousands of times and improved to be of good quality and reliable.
5. All errors readable from the front panel, thus SKY burner is just “Smart Burner”!
6. Complete fuel burning ensures very low emissions, reducing pollution as much as possible. Environmentally –friendly, Exhausting air complies with the requirements of EURO III;
7. Big oil tank optional, as big as 100L container for holding waste oil, pumping system is held at the top to pump waste oil into burner machine; At the same time hold the burner machine during shipping from damage;
8. There is heating instrument at the bottom of big oil tank to pre-heat fuel before pumping, esp. considerate for using in cold area.
9. Double safety design for PC program.

Electric oil burner
.JPG
pic.jpgB-05 whole.jpg
The waste oil burner Pump filter
The waste oil burner all parts tested thousands of times and improved
to be of good quality and reliable.
Environment freindly
Burn clean and safety

Burner are in stock
.jpg

 Standard export package




Our Services

 Our waste oil burner services

- One year guarantee, long time free tech support.

- All spare parts are provided for further maintenance.

- Perfect sales and after-sales services for you.

Company Information

YANTAI SKY MACHINERY CO.,LTD is a company making efforts to supply quality garage equipments including Frame Machine, Booth, Heater and Burner, lift, Tire Changer, Wheel Balancer,Wheel Aligner, Decoder, Key Programmer, Oil Drainer, Tools Cabinet,Air Compressor, Jack & Stand, Crane, Pressing Machine etc. Also we could supply parts and accessories for auto repairing shops, such as hydraulic cylinder for lifts, turning plate for wheel aligner, weights for wheel balancer etc.



Our products have been selling to worldwide countries as Canada, U.S, Colombia, U.K, Ireland, Sweden, Poland, Finland, Hungary, Norway, The Netherlands, Deutschland, Denmark,Bolivia, Latvia, Slovenia, UAE, Saudi Arab, Malaysia, Mongolia ,South Africa ec.



From various customers we learnt various experiences in manufacturing applications, and businesses.We have been improved much of the products and are always will to continuously improve.

Our exhibition :

 .jpg

Our factory photoes:



.jpg .jpg




FAQ

The buyer who likes us may ask:

Q:Who are you? Trade Company or manufacturer?

A: We are manufacturer and we have our own trade company.



Q: When the product can be delivered?

A:  Commonly the lead time will be within 15 days after receiving 30% deposit or L/C,

subject to prior sales.



Q:What’s the Min order to your company?

A:1 set.The sample order, if we have stocks, we will send out the products within 1 week.



Q:What’s the advantage of your company?

A:We have exported our lifts and service to more than 50 countries./ we have speclized team work for you, you will get our feedback within 12 hours./ Germany and Italian advanced manufacturering technology



We promise:



Our products are CE proved and one year quality warranty, during the validation, the replacement part can be provided free of charge.
