Product Description



Feature:
Basic instrument for research and small scale production Applicable for: mechanical agitation system adopts magnetic:
Anchorage independent cell suspension cultivation

Anchorage dependent cell cultivation

Fixed bed type cultivation for fiber disk

Suspension cultivation of fiber disks
Shanghai Ritai enterprise develops a new CELLIPOWER 08 bio reactor system with own intellectual property rights, which is based on the deep and comprehensive research and analysis to each kind of Bioreactor on the world market.


Range:
CELLIPOWER 08 Bioreactor system adopts the control set that is made of SIEMENS S7-200 serial PLC controller, and adopts Microsoft Windows CE 5.0 Standard operation system with SIEMENS TFT 10.4 LCD. Equips with colour multi-functional touch screen, which is high reliable and full of abundant order set. This touch screen, convenient for operation, fits with abundant built-in integrated function, real time characteristic, powerful communication capability, and abundant extending module.
Control modes of cultivation control system are included as follow: PH DO,Temperature,Agitation, Aeration, Level, Perfusion and so on..


Technical parameters:

  Type
  Capacity
  Main controller
 Range/mode
 Range/mode
 Condenser/Filter
  Range/mode
  Range/mode
  Air inv
 Standard set
Head plate
RTY-E-3
RTY-E-5
RTY-E-7
RTY-E-10
RTY-E-15
RTY-E-20
3.5L
5L
7L
10L
15L
20L
      Siemens S7-200 PLC
     Room temperature: >4-60, PID control mode
    20-200RPM, PID control mode
     316L SS exhaust condenser, 0.2μair filter (disposable)
     2-14PH, PID control cascades to peristaltic pump and CO2
    0-200, PID control cascades to gas
    0.2μ air filter (disposable)
    Four standard peristaltic pumps, easy to be loaded and unloaded. Assignable.
   316L SS,equip with six fastening knobs. Bearing house equip with special shaft    seal and Aeration caverna. All ports fit with O rings. Threads are not dipped into    solution.

Packaging & Shipping



Packaging: plywood case

Shipping: by sea or by air

loading


Company Information
Shanghai Ritai Medicine Equipment Project Co., Ltd. mainly specializes in innovation and development of sanitary stainless steel pressure vessels, atmospheric pressure vessels, fermenters, valves and piping system which are widely used in the following fields, such as pharmacy, biology, chemistry, food and drinks industry.
Shanghai Ritai is qualified to design and manufacture pressure vessels with the certificates of ASME, PED 97/23/EC, NB, and ISO 9001:2008.
