Инструмент для ремонта винтов M14 * 1 25 TAP HSS

Описание и отзывы

Характеристики

Since the JIAHUACompany established, to ensure the high quality products, and satisfy our customers requirement have always been our purpose, painstakingly producing various specification wire thread insert and install tool, and thread repair kits and so on.

our products is well sold all over the world, extensively believed by our customr,at same timealso testify ours defrayal.

Quality is the lifeline of one enterprise, The customer is always a teacher. these are the quality principles of JIAHUA. The perfect technological process system, and strict quality control system are our first faith to aspire to lead.

Since the material enters the factory producing process control, product examination, products quality tracing after sales, all strict controolled according to the ISO-9000,GJB119,1-86,HB6200-6202-89 quality system request.Use the advanced precise examining instruments check on each step, quality always challenge to No-defects.

JIAHUA Perfect Technical Support:

At JIAHUA,we will fully meet your demands.

At JIAHUA,our engineers are always ready to provide you with perfect technical support and satisfactory service whatever you have purchased or are just interested in our products.

I. Special tap of wire thread
Special tap of wire thread is also called ST tap, which is used for making customized internal thread for mounting hole of steel wire thread. ST tap applies to both machine use and manual use. By its use scope, it can be divided into hand taper for light alloy machine and hand tap for common steel machine.
1. Hand tap for light alloy machine
This kind of taper is used to process non-ferrous alloy, which is mixed by aluminum, magnesium and copper, etc. The thread tapper whose screw pitch is less than 2.5mm is called single tap, while whose screw pitch is over 2.5mm is called dual tap.
Remark method: QS/ST  d*p
Example: apply to the installation of customized screw cap for 7*1 hole thread.
Remark as: QS*ST  7*1
2. Hand tap for common steel machine
This sort of tap is used for dual-tap insert installation
Remark method: PS/ST  d*p
Example: apply to the installation of customized screw cap for 7*1 insert
Remark as: PS*ST  7*1
II. Drill
Make holes before steel inserts installation. Prepare corresponding drills as per relevant parameters provided by attachment. If the hole is bigger, repair as per actual condition. The supporting drills are standard dills. Customers can choose proper drills as per different material and hardness.
III. Handle
The handle is used for the insert’s installation in thread bottom hole. The operation principal is to make insert to go through guide thread, and outer diameter can be narrowed and then the insert can be installed in the bottom hole. The handle can be divided into manual handle and automatic handle, but the manual ones are the mostly used.
1. Manual handle: this is used to manually install inserts. The manual handle can be divided into composed nut handle and integral nut handle.
(1) Composed nut handle
This sort of handle is used to install small insert, ST2*0.4~ST8*1.
Remark method: ZHB/ST d*p
Example: the manual installation handle, used to install ST4*0.7, can be marked as ZHB/ST4*0.7.
(2) Integral nut handle
This sort of handle is used to install ST8*1 insert, or inserts of above. .
Remark method: ZTB/ST  d*p
Example: the manual installation handle, used to install ST10*1, can be marked as ZTB/ST 10*1.
2. Simple installation handle
3. Semi-automatic installation handle: this handle is grouped into pneumatic handle and electric handle. Both kinds are used in the massive inserts installation, or used in assembling line.
IV. Break tool (break tool for installation handle)
Break the installation handle of insert by instant impact.
Remark methods: CD/ST  d*p
Example: install break tool to break the installation handle T  7*1, marked as CD/ST  7*1.
V. Withdraw tool (insert remover)
This is used to remove insert installed in bottom hole.
Remark method: XT/ST   d*p
Example: install the withdraw tool that used to remove insert. Marked as XT/ST 7*1.
VI. Tool set
We can offer different tool sets on base of customers’ variable needs.
