Products Description
Z4 Series DC Motors
This series motors are found wide use for prime mover in various machinery, such as mill auxiliary in metal urgical industry, tetal cutting machine tool, paper-making, print textile, peinting and dyeing, cement-making, plastic extruding machine woodwork machine etc.
Outline mounting dimensions of the motors comply with IEC 72 Standard, except for the axial distance between the mounting holes.
Performances and technical requirements of the motors can be checked in accordance wotj OEC 34-1 Standard of the international Electro technical commission. or DIN 57530 Norm of the Deutsche Industrie-Norm.
Type | Rated Out put Pn | Rated Speed 400V | Rated Speed 440V | Speed with Field Weaking nF | Arm. Curr. In | Field Power Pf | Arm. Circuit Resistance R | Arm. Circuit Inductance La | Field Inductance Lf |
kW | r/min | r/min | r/min | A | W | Ω(20°C) | mH | H | |
Z4-355-12 | 406 | 900 | 1500 | 1094 | 4700 | 0.01259 | 0.36 | 37.6 | |
450 | 1000 | ||||||||
321 | 680 | 1500 | 877 | 0.02087 | 0.59 | 28.1 | |||
355 | 750 | ||||||||
Z4-355-11 | 253 | 540 | 1500 | 697 | 0.02952 | 0.91 | 22 | ||
280 | 600 | ||||||||
180 | 450 | 1500 | 506 | 0.0502 | 1.5 | 8.91 | |||
200 | 500 | ||||||||
166 | 360 | 1200 | 478 | 0.066 | 1.8 | 22.4 | |||
185 | 400 | ||||||||
Z4-355-22 | 361 | 680 | 1600 | 978 | 0.01583 | 0.44 | 15.6 | ||
400 | 750 | ||||||||
284 | 540 | 1500 | 783 | 0.02676 | 0.81 | 34.7 | |||
315 | 600 | ||||||||
225 | 450 | 1600 | 624 | 0.03462 | 1 | 20.5 | |||
250 | 500 | ||||||||
Z4-355-21 | 180 | 360 | 1200 | 511 | 0.05642 | 1.6 | 35.5 | ||
200 | 400 | ||||||||
Z1-355-32 | 406 | 680 | 1100 | 1098 | 6000 | 0.01362 | 0.39 | 19 | |
450 | 7501 | ||||||||
320 | 540 | 1600 | 877 | 0.02153 | 0.7 | 24.3 | |||
355 | 600 | ||||||||
284 | 450 | 1500 | 789 | 0.0293 | 0.91 | 18.5 | |||
315 | 500 | ||||||||
Z4-355 31 | 197 | 360 | 1200 | 559 | 0.04957 | 1.3 | 34.6 | ||
220 | 400 | ||||||||
Z4-355-42 | 361 | 540 | 1300 | 985 | 0.01836 | 0.64 | 29.6 | ||
400 | 600 | ||||||||
320 | 450 | 1200 | 882 | 0.02361 | 0.76 | 17.7 | |||
355 | 500 | ||||||||
225 | 360 | 1200 | 627 | 0.0358 | 1.2 | 17.7 | |||
250 | 400 | ||||||||
Z4-355-12 | 406 | 900 | 1500 | 1094 | 0.01259 | 0.36 | 37.6 | ||
450 | 1000 | ||||||||
321 | 680 | 1500 | 877 | 0.02087 | 0.59 | 28.1 | |||
355 | 750 | ||||||||
Z4-355-11 | 253 | 540 | 1500 | 697 | 0.02952 | 0.91 | 22 | ||
280 | 600 | ||||||||
180 | 450 | 1500 | 506 | 0.0502 | 1.5 | 8.91 | |||
200 | 500 | ||||||||
166 | 360 | 1200 | 478 | 0.066 | 1.8 | 22.4 | |||
185 | 400 | ||||||||
Z4-355-22 | 361 | 680 | 1600 | 978 | 0.01583 | 0.44 | 15.6 | ||
400 | 750 | ||||||||
284 | 540 | 1500 | 783 | 0.02676 | 0.81 | 34.7 | |||
315 | 600 | ||||||||
225 | 450 | 1600 | 624 | 0.03462 | 1.0 | 20.5 | |||
250 | 500 | ||||||||
Z4-355-21 | 180 | 360 | 1200 | 511 | 0.05642 | 1.6 | 35.5 | ||
200 | 400 | ||||||||
Z4-355-32 | 406 | 680 | 1100 | 1098 | 6000 | 0.01362 | 0.39 | 19 | |
450 | 750 | ||||||||
320 | 540 | 1600 | 877 | 0.02153 | 0.7 | 24.3 | |||
355 | 600 | ||||||||
284 | 450 | 1500 | 789 | 0.0293 | 0.91 | 18.5 | |||
315 | 500 | ||||||||
Z4-355-31 | 197 | 360 | 1200 | 559 | 0.04957 | 1.3 | 34.6 | ||
220 | 400 | ||||||||
Z4-355-42 | 361 | 540 | 1300 | 985 | 0.01836 | 0.64 | 29.6 | ||
400 | 600 | ||||||||
320 | 450 | 1200 | 882 | 0.02361 | 0.76 | 17.7 | |||
355 | 500 | ||||||||
225 | 360 | 1200 | 627 | 0.0358 | 1.2 | 17.7 | |||
250 | 400 |
