Features



 1/2 - 5 Hp Integral motors

  • Excellent sand handling capability
  • High motor and pump efficiency
  • Built in dry-run protection
  • Overload / locked rotor protection
  • Over voltage / undervoltage protection
  • Over temperature protection
  • No control box required
  • Soft-start
  • Multiple frequency input (50 - 60 Hz)
  • Pump and motor can be seperated
  • Easy to install
  • Serviceable pump and motor
  • Replaceable motor lead

Operation condition:

1.Submersible depth:1.5m-10m

2.The range of PH:6.5-8.5

3.Voltage fluctuation range:0.9-1.1 times of the rated value



Range of Performance




ModelFlow(m3/h)Head(m)PowerVoltage(v)Pipe size(inch)Speed(r/min)
KwHp
QJD2-40/5-0.372400.370.522012860
QJD2-50/6-0.552500.550.7522012860
QJD2-60/8-0.752600.75122012860
QJD2-55/8-1.12551.11.522012860
QJD3-40/6-0.503400.50.6722012860
QJD3-40/5-0.373400.370.522012860
QJD2-50/6-0.752500.75122012860
QJD3-40/5-0.553400.550.7522012860
QJ3-50/6-0.553500.550.7538012860
QJ2-75/8-1.12751.11.538012860
QJ3-75/12-1.13751.11.538012860
QJ3-85/12-1.53851.523801/1.22860
QJ3-100/20-2.231002.233801/1.22860
