Предложение от производителя baotou north benth beiben 4x2 колесный привод внедорожный септический резервуар вакуумный грузовик для всасывания сточных

Commodity

Beiben Off Road Military UN Septic Tanker Truck

Chassis

ND2161E48J

Cubage (T)

7000Litres to 10,000Litres

Vehicle

Overall dimension(length/width/height)mm

8826×2500×3355

G V W(kg)

16000

Payload (kg)

7960

Kerb mass(kg)

7910

Fuel Type

Diesel

Fuel consumption(L/100km)

22

Top speed

 90

Engine

Model

WP10.270

Exhaust/Power(kw)

9726cc/199kw

270HP

Manufacturer

Weichai Motor Co., Ltd.

Type

6-in-line water cool Turbo Charge engine

Chassis

Drive type

4×4

Wheelbase (mm)

4,800

Tread(front/rear)mm

1995/1800.

Front Bridge

7.5T FRONT AXLE

Number of spring axles(front/rear)

9/9+6

Tire specification

12.00-20 ; 12.00R20

Air condition

with

suction system

suction pump

Single Stage Rotary Oil Seal Vacuum Pump

special parameter

Vertical suction heihgt

≥8

working pressure

8500Pa

rotation speed

500

suction speed

98L/S

power

5.5kw

inlet diatmeter

50mm

filling time

Less than 5s

discharge time

Less than 4s

Remark

Brand: WEICHAI POWER,

Power: 270hp,

Wheelbase: 4500mm,

Displacement: 9726ml,

Emission: EU 3,

Transmission: 10 forward, Fast brand,

Tire: 12.00-20, 6 pcs, 1 spare,

Cab: flat roof, air suspension seat, air conditioner, 1 sleeper, 2 passenger,

Rear axle: 13T, single reduction

Speed: 85km/h

Drive: 4x2, left hand drive

Equipped with

The vacuum sewage suction truck is equipped with :

1.chassis truck

2.Vacuum tank( Back cover can be opened)

3.power take off

4.transmission shaft

5.vacuum pump (rating rotate speed=1400r/m,min rotate speed>800r/m, max suction lift>6m, vacuum>500mmHg)

6.Pipe for sucking and discharging sewage(Time for full suction<5min)

7.fecal pipe for observing and cleanout equipment

this truck can suck the mud, sewage, dejection and the dirty water with small stone under by vacuum pump. Vacuum pump is drived by PTO, to self-suck and self-discharge by four-way valve.
