Acid Cleaner/Degreaser for PCB(Printed Circuit Board)
Acid cleaner MT-3009 is a acid degreaser for printed circuit that has been designed for supplying the users with a product having a double action: degreasing and pickling. The solution cleans the copper plates in function of the detergent power of the tens active agent used in the dressing, at the same time, carries out a pickling action on the surface oxides in relationship to its own acidity. Additionally the product is inhibited for preventing an extremely strong action of the pickling agent which could become a corrosive action as copper is concerned. Therefore it is the acid cleaner which is not only suitable for pre-treatment of Pattern plating and electroless plating, but also suitable for post-treatment of direct plating production.
Working condition for pattern plating process:
Time:3~5min
Temperature:20~30°C
Pattern plating processes
No. | process | product | time | temperature |
1 | Acid degreasing | Acid cleaner MT-3009 | 3~5min | 20~30°C |
2 | rinsing |
|
|
|
3 | Micro Etch |
| 1~1.5min | 22~28°C |
4 | rinsing |
|
|
|
5 | Acid Dip |
|
|
|
6 | Acid copper | Acid copper MT-390H |
| 20~28°C |
7 | rinsing |
|
|
|
8 | Acid dip |
|
|
|
9 | Pure tin | Pure tin MT-3800 | 6~10min | 18~25°C |
10 | rinsing |
|
|
|
11 | stripping |
|
|
|
12 | rinsing |
|
|
|
GOOD Chemical Science & Technology Co., Ltd, the largest production base of Highnic Group, covers an area of 500,000 square meters and is located in Lubao Industrial Development Zone, SanShui City, Guangdong. As a National high-tech enterprise and the Provincial Engineering Technology R&D Center, it has established a large Surface Technology Institute and High-polymer Research Institute, specializing in new environmental-friendly electroplating and adhesive research and development. A complete set of precise testing instruments and advanced production line are introduces, achieving an annual output of 200,000 tons.
GOOD Chemical strives to be the high-tech enterprise for top class quality and services. We pursue the following as its operation goal: professional products, superior quality, advanced management and international development. We are the most advanced, top-scale and top-quality producer for electroplating material in China, of which superior phosphorus copper anode annual output is 35 thousand tons, Golden Kangaroo high purity cupric sulfate 12 thousand tons, nickel sulfate and nickel chloride 10 thousand tons, special wires of copper alloy 50 thousand tons, adhesive series and leather chemical 100 thousand tons, different kinds of electroplating anodes like tin, zinc, chromium and electroplating additives etc. We are willing to dedicate our excellent products, experience and technology to each of our client.
We provide high quality products as well as professional technical supports. Our specialist team delivers the after sales services and technical supports to customers in a quick convenient performance. So don't hesitate to contact us whenever your business needs.
Contact Ms. Lily by phone or message via 0086-139 2865 1530, skype: highnic.lily
Whats app/Wechat id:+86 139 2865 1530
