Популярный прицеп для лошадей с человеческим помещением индивидуальный гусиной

Популярный прицеп для лошадей с человеческим помещением индивидуальный гусиной

Категория: Trailers >>>
Поставщик: Jinan Jinli Hydraulic Machinery Co. Ltd.

Цена:*

Количество:

В избранное

Описание и отзывы

Характеристики

popular horse trailer with human room customized gooseneck trailer

a.with living quarters

b.dip galvanized
c.for 3 horses

d.Austrilian standard

Jinan Jinli Hydraulic Co.,Ltd is a professional manufacturer of horse trailer/ float with 10 years experience in producing horse trailer.Our products are horse trailer, gooseneck trailer, caravan trailer, cargo trailer, dog trailer, mobile homes,fast food trailer etc.

Our horse floats/trailers are mainly used for horsecouper, rececourse, polo sport, equestrian sports and activities relevant to the horses.

Also we can produce trailers/floats according to customers's design and requirement, that is customized type.

Our oversea market mainly focuses on Austrialia, New Zealand, Middle East (Saudi, Arabia, Yemen, UAE etc), southeast countries (Singapore, Malaysia, Thailand, Brunei, etc.), Southeast countries (Chile, Argentina, Brazil)

Model	3HALG-D
Materials	Chassis Material: dip galvanized RHS (3.5mm-4.0mm)
	Frame Material: dip galvanized RHS (2.5mm)
	Body Panel: galvanized sheet (1.2mm)
	Roof: Special molded FRP
Brake	Perfect security structure design, double axle electric brakes
Drawbar	Drawbar Checker Plate 1.2mm aluminum
	Drawbar Safety Chain two & Bracing Wheel one
Suspension	Roll rocker tandem spring 9 plate
Axles	Two special trailer axles
Wheels & Tyre	Five 195R14 Tyre and 14’ aluminum alloy rims, including a spare tire
Rubber Matting	18mm special plywood for floor& ramp door
	Rubber Matting For Inner Side Panel --------- 6mm thick
	Rubber Matting For Floor & Ramp Door 17.5mm &10mm thick
Mudguard	Compact Mudguard
	Mudguard checker plate 1.2mm aluminum in the front of mudguard
	PEDAL & ALUMINIUM STEP 1.2mm aluminum decoration board
Windows& Doors	Front Window (mm) 1220*610
	Side Windows six ,three for each side
	Vents two large size upturning ventilation windows
	Rear Upper Door (mm) 1980*1065 Strut & High-intensity anti-rust strut
	Ramp Door (mm) 2020*1210
	Side Door (mm) 1755*615
	Hinges for Rear Upper Door special 6mm diameter copper hinges
Supporting Wheel	Swing-able knight supporting wheels to make parking safe and reliable
Lights& Petro Reflectors	Trailer Plug Seven-prongs Plug
	Rear Lights brackets aluminum
	LED interior lights, two small LED sidelights, two LED combination taillights
	Retro Reflectors 8
Auxiliary Fittings	Cupboard Front :one group for fridge and microwave oven, one group for sink ,tap and 2 bumper gas stove with glass cover
	Horse Protection Frame fully padded
	Horse Ring 4
	Saddle Rack in saddle box(1500mm height for 3 saddles)
	Rug Rack Side
	Tack Box One set
	Water Tank One set
Dimensions	Body Dimension (L x W x H :mm) : 7250x1980 x 2230
	Overall Dimension(L x W x H :mm): 7900x 2500x2590
	Length of Tone (mm) 850
Empty load	2400 kg
Max Payload	4000kg
Additional Requirement	left open door , a kitchenette : include a microwave oven ,one cupboard ,one gas tank, one fridge .
