Wdr ip модуль TI Davinci DM368 CMOS плата камеры/1080P HD

Model

SIP-1080P

SIP-1080PA

Camera Type

HD 1080P IP Camera Module

Camera

Image Sensor

1/2.5 inch 5.0 Megapixel progressive CMOS sensor

DSP

TI Davinci DM368 DSP 32 dual-core , pure hardware compression

Day/Night

Auto

IR-Cut

Support

Min.Illumination

Color 0.6Lux/F1.2,B/W 0.08 Lux/F1.2

Electronic Shutter

1/50(1/60)s-1/100,000s

Lens Mount

CS Mount (This IP module does not support Auto-Iris Lens)

Digital Zoom

Support

Video/Audio

Compression Standard

H.264

Compression Technology

Dual-stream compression technology

System Structure

Pure hardware compression, watchdog,32M FLASH,128M DDR2;

Video Frames

Real-time PAL 25fps,NTSC 30fps 1-30fps Adjustable

Bitrate

500~8000Kbps Adjustable

Bitrate Control

CBR/VBR/CVBR

Audio Coding Standard

N/A

AAC / G 7.11

Audio Volume

N/A

0-100 Adjustable


Resolution

Main Stream: 2592X1920 10fps,2048X1536 17fps,1920X1080 25fps

Sub Stream:D1,VGA,640X360,480X270,CIF,QCIF

Parameter Settings

Brightness, contrast, chroma saturation,Backlight Control,Mirror

Privacy Mask

Support 4 area can be set

Image Capture

Image quality , capture speed

Time and Title

Transparency, Time position, Time Format, Title Content

Network

Protocol

RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP/SMTP

Support 2.0

User Permission

Multi-user Classification Management

Phone monitoring

Support iPhone and android Mobile phone view

SDK

Provide open SDK

Alarm

Support Motion Detection, Linkage Alarm, Linkage recording, Video Loss Alarm

Interface

Audio Input

N/A

1CH input

Audio output

N/A

1CH output

USB Interface

1 USB interface ( Max: 64G) , front storage supported

Video Output

1CH Video output, Support CVBS standard, PAL/NTSC Optional

Network Interface

1 RJ45 Ethernet interface, 10/100M adaptation

WIFI#

WIFI 802.11bgn

3G#

WCDMA 3G wireless networks

RS485 Interface

N/A

RS485 interface

Alarm Interface

N/A

1CH input/1CH output

Other

Work Environment

-10°C- +60°C;≤95%

Power Supply

DC 12V

Product Size

38X38X38mm

Package Size

50X50X50mm

Net Weight

0.2kg

#The regular camera doesn't have WIFI,3G functions. If you need WIFI,3G functions, please consult with us.
