Морозильная камера Холодильный конденсаторный Вентилятор Мотор 10 ватт
- Категория: Запчасти для холодильника >>>
- Поставщик: Shengzhou Shuanggang Electric Co. Ltd.
Сохранить в закладки 60293113751:
Описание и отзывы
Характеристики
Product Description
Features:
YZF series Manufacturer China manufacturer of Ac Ice cream fan motor 230v 50hz confirm to CCC ,CE,TUV ,UL,CSA standard ,with high efficiency ,good performance,energy saving , lowest noise ,high starting torque ,dustproof , anticorrosion ,long service time .
- Output power : during 5W to 34W
- Fan blade diameter : 150mm ( 6") ,170mm( 7") ,200mm ( 8"),230mm ( 9") ,250mm(10") ,300mm (12") .
- Bracket height : 55mm,72mm,84mm,109mm
- Direction of rotation : CW or CCW ( view from shaft end )
- Bearing : Sleeve bearing (standard) or Ball bearing on request
- Life expectancy : over 30000hours
- Insulation : Class B . Class E and F on request
- Direction of rotation: CW or CCW
- Motor protection: Impedance / thermal protected
- UL listed, TUV approved and CE certificated
- Fan blade , bracket , range of Guards and Shrouds are available
- Direction of airflow : Blowing or Sucking
- Voltage: 110-120V/60Hz , 220-240V,400v/50hz , 400v
Product Photos
Specification
| Model | Voltage | Output Power (W) | Current (A) | Rotation Speed (r/min) | Weight (KGS) | Fan blade size (mm) | Stator height A | Height of Bracket |
| YZF3/10 | 110V | 3 | 0.16 | 1300/1550 | 0.8 | 150 | 13 | 72 |
| YZF5/13 | 115V | 5 | 0.2 | 1300/1550 | 1 | 170 | 13 | 72 |
| YZF7/15 | 120V | 7 | 0.22 | 1300/1550 | 1.1 | 170 | 15 | 72 |
| YZF10/20 | 220V | 10 | 0.25 | 1300/1550 | 1.2 | 200 | 20 | 84 |
| YZF16/25 | 230V | 16 | 0.42 | 1300/1550 | 1.4 | 250 | 25 | 84 |
| YZF18/28 | 240V | 18 | 0.55 | 1300/1550 | 1.5 | 250 | 28 | 84 |
| YZF25/30 | 400V | 25 | 0.62 | 1300/1550 | 1.8 | 300 | 30 | 109 |
| YZF34/40 | 400V | 34 | 0.83 | 1300/1550 | 2 | 300 | 40 | 109 |
| VOLTAGE :110-127,60HZ 220-240V,50/60HZ 400 V/50HZ | ||||||||
Item Name | Freezer Refrigeration Condenser Fan Motor 10 Watt |
Type | Condenser Fan Motor 10 Watt |
Voltage | 110/120/220/240V/400V 50/60Hz |
Material | Aluminum cover with 100% copper wire |
MOQ | 500 PCS |
Capacity | 100,000 PCS / Week |
Port of Loading | Ningbo ,Shanghai or Guangzhou ,China |
Payment Terms | T/T, Western Union,L/C at sight |
Warranty time | 3 years |
Package | Export carton or Pallet |
Packaging & Shipping
1. Packing item: Export Carton and Pallet .
2.Payment item : FOB ,C&F ,CIF ,EXW price term is available .For samples motor ,you can pay via Western Union,T/T. mass production order , please pay by T/T or L/C at sight . we aslo accept Online order by Alibaba Trade Assurance .
3.Delivery time : 30% -50% deposit ,balance before or against the copy of BL or irrevocable L/C.
Our Services
WHY Choose Us
1. 18 years working experience for household appliance motors .
2. we offer 3 years warranty for the whole products .
3. Alibaba 7 years golden supplier .
4. Inspection :100% In coming, in process inspection before final packing.
5. OEM /ODM :we can make the sample as your sample or design drawing.
6. Sample : free of charge when we start to cooperate.Small orders,Mixed orders,Trial orders are accepted . Customers pay the charge of Freight .
7. Prompt reply: we can reply your inquiry and email within 24 hours.
8.Fast Delivery: The delivery time is within 4 weeks (depend on your QTY) after receiving the deposit.
9. Professional Motor Manufacture with 6 production lines and 215 skilled workers .
10.ertifications:Passed the ISO9001:2008 and international certificate as CE,TUV,SGS,UL,CSA,RoHS.ect.
Company Information
About us
*Since 1997
*Specializing in household electric motors include AC & DC motor ,such as Shaded pole fan motor ,range hood motor,Air conditioner motor , shoe polishing machine motor , air purfier motor ,ect
*Professional Motor Manufacture with 6 production lines and 215 skilled workers *Passed the ISO9001:2008 and international certificate as CE,TUV,SGS,UL,CSA,RoHS.ect for electrical motors .
Sincerely welcome your visiting !
FAQ
1.how to Place order Online By Alibabab Trade Assurance ?
You can enter into product detail page , Click “ Start Order “ and then following the steps .
You also can note us , we will start an Online order for you confirmation.
2. What’s the MOQ ?
Normally 1000 pcs for each model , it varies due to the model you choose .
3. Sample can be free ?
We can supply you free sample only for motors , you need pay the cost of freight .
4. How about the delivery time ?
Usually 25 to 30 days after the deposit for first order , following orders can be 20 days base on your demand .
5. How to visit our company ?
Our city Shengzhou near to Ningbo and Hangzhou . You can arrive at Ningbo or Hangzhou airport or train station , then we will pick up you there to our company .
