Gas Boiler For Room Heating And Hot Water Suppling

Gas Boiler For Room Heating And Hot Water Suppling

Категория: >>>
Поставщик: JINHUA VEGA THERMO EQUIPMENT CO. LTD

Цена:*

Количество:

В избранное

Описание и отзывы

Характеристики

Welcome to visit

R Series

Product Description

Place of Origin : Shanghai , China (Mainland)

Product name : Wall mounted gas boiler

Rated heat input : 16 kW

Heating area : 100 m ²

Gas classify : Gas (12T)

Electricity : 220/50/120 (V / Hz / W)

Product Parameter

Product name	—	Wall Mounted Gas Boiler
Production license	—	XK21-005-00209
Model	unit	L1PB16	L1PB18	L1PB20	L1PB24	L1PB28	L1PB32	L1PB36	L1PB40
Rate heating	kW	16	18	20	24	28	32	36	40
Min thermal input	kW	4.8	5.6	6	7.2	8.4	9.6	10.8	12
Rate heating output	kW	14.64	16.4	18.2	22.15	25.9	29.31	32.58	36.64
Min thermal output	kW	4.4	5	5.5	6.6	7.7	8.7	9.7	10.9
Rate hot water	%	91.5	92.1	91.6	92.3	92.5	91.6	91.9	91.6
Electricity	V/Hz/W	220/50/120					220/50/130
Heating water pressure	Mpa	0.05~0.3
Heating temperature range	°C	Switch between floor and radiator heating , from 30 degree to 80 , Max 85
Heating area	m²	100	120	140	170	200	230	270	300
Gas consumption	m³	0.08/kW/h
Hot water pressure	Mpa	0.05~0.6
Hot water capacity (ΔT=30°C)	kg/min	6.7	7.5	8.3	10	11.7	13.3	15	16.7
Min hot water flow	L/min	3
Hot water temperature range	°C	35~36
Gas classify	—	Gas (12T)
Gas pressure	Pa	1500~3000
Anti-proof grade	—	IPX4D
Protection grade	—	I Class
*Weight*	Kg	30	32	35	37	43	46	50
Dimension	mm	740x400x250		740x400x300		740x460x335	740x500x335	740x550x335
Flue pipe	mm	Φ100/Φ60

Packaging & Shipping

Standard package : 1set/CTNS.Every gas boiler is protected with retractile plastic and foam in 5 layer carton box , includes instruction manual, installation accessories .

Delivery detail : 40 Days.

Company Information

Jinhua Vega Thermo equipment co., LTD., established in 2003, mainly engaged in water radiator, gas boilers, electric radiators , bathroom towel rack, pumps, pipe fittings, valves, etc., it is a collection research and development, production, sales in one of the export-oriented enterprises specialized in HVAC system. through ten years unremitting efforts, the product covers Europe, CIS, the Americas, the Middle East, Central Asia and other countries and regions; We always adhere to the "professional, pragmatic, integrity, innovation" , with reliable product quality and professional service, with customers common development and achieve win-win situation, common trust by our clients.
