Автомобильная распылительная камера на заказ 7 м/8 м/9 м/10 м со светодиодным освещением печь для выпечки кузова автомобиля
570 171,68 ₽ - 679 820,08 ₽
Автомобильная покрасочная камера на водной основе инфракрасная/дизельная/газовая тепловая
- Категория: >>>
- Поставщик: Guangzhou Hechuang Coating Equipment Manufacturing Co. Ltd.
Сохранить в закладки 60387299045:
Описание и отзывы
Характеристики
Product Description
Product Description
Specification(European design) of car oven spray booth for water soluble paint
Outside Size: | 7010 x 5570 x 4200 mm (L x W x H) | Inside Size | 6900 x 4000 x 2800 mm (L x W x H) |
Foundation and Floor | Foundation | Full metal foundation, two rows flat steel grids and three rows metal non-slip diamond plates | |
Metal basement | 350mm height, the ventilation effect is better than traditional spray booth | ||
Drive-in Ramps | 2Units, each size: 2000X500mm, diamond plate construction | ||
Wall and door | Wallboard and Roof Panel | Adopt high quality double construction fireproof insulation EPS panel, thickness: 50mm | |
3-Folded Entrance Door With Safety Glass Window | 1 set, size: 3100x2700 mm(B x H),size is bigger than traditional spray booth | ||
-Operator’s Door With Safety Glass Window | Big opening:700x2000mm (B x H),hand-made, tempering glass observation window | ||
Light System | Ceiling Lighting | 8Units, each4×36W, Total 1152W , adopt Germany OSRAM Lamp | |
Side Lighting | Optional | ||
Brightness | ≥1000 LUX | ||
Filtration System | Pre-filters | Grade G2 plate type fiber glass filter | |
Ceiling Filters | EU5 grade high efficient filter | ||
Bottom filter & exhaust filter | Fibreglass paint-stop filter | ||
Ventilation System | Inlet fan (Direct drive motor) | Adopt big impeller turbo fan 7.5KW ,380V,50HZ,CE | |
Outlet fan(Direct drive motor) | Adopt big impeller turbo fan 5.5KW ,380V,50HZ,CE | ||
Fan for water-based paints | On top of cabin installs 2 sets of 1.5kw centrifugal fans, increase system air supply capacity to dry quicker | ||
Painting nozzles | Install two rows of nozzles on position of ceiling lighting box | ||
Painting and baking exchange system | Solenoid valve+ pressure adjustment control cylinder driven damper exchange | ||
Total fan Capacity | 32,000m³/h | ||
Air Flow Speed in cabin | 0. 3m/s in empty booth , 0.30-0.45m/s in loaded booth | ||
Heating System | Heating Exchanger | Adopt high efficient heat-resistant stainless steel as cycling heat exchanger | |
Heating Exchange Capacity | 160KW(180,000Kcal/H) | ||
Burner Model | Adopt Italy RIELLO diesel burner G20(180,000kcal/h) | ||
Heating time | 4-6minutes (from20 to 60º under baking status, max baking temperature is 80° | ||
Control Board | Control system | Standard control system | |
Function | Painting, warm painting, baking, lighting, emergency stop switch, failure indication, over-temperature alarm indication | ||
Total power | 17.5KW | ||
Packaging & Shipping
Package and Shipping
Package: Professional export package-use the iron bracket package
Loading situations: a 20GP container
Our Services
Our Services
A. All of the machines in our factory can be customized. If you have any other requirements of the machine, please feel free to contact me. We can design it for you.
B: Payment terms: T/T. 30% in advance after order confirmed, 70% in balance before
shipment.
C: Delivery time: To effect shipment within 7 days after the receipt of deposit.
D:Warranty time: 1 year. During the warranty time, any defective caused by product’s quality, CHNHC has responsibility to offer free spare parts to customers freely and bear the
delivery cost for DHL or TNT Carrier.
Company Information
Company Information
HC Coating Equipment Manufacturing Co., Ltd. is an auto maintenance equipment company. Today it is a global player in the automotive aftermarket providing a full range of equipment and service solutions for workshops. The core products in our company are spray painting and baking booth, portable spray booth, bus/truck spray paint booth, preparation station, mixing room, brake lathe, car bench and so on. All our products are shipped to Europe, East Europe, North & South America, Africa, Australia and Asia as well as different provinces in China.
Exhibition
FAQ
FAQ
Q: Are you a factory or a trading company?
A: We are a factory and all machines are produced at our own factory.
Q:Can I order special color which I like?
A: Yes, we can also produce machines with special color according to client's request.
Q: Can I order metal drying chamber in any special size?
A: Yes,you can.
The size is customized.
Q: I don't know how to assemble your industrial paint dry booth.
A: The complex installation is already finished before delivery, what you need to
do is finishing the simple procedures according to the installation instructions.
Q: When the product can be delivered?
A: Commonly the lead time will be within 7 working days after receiving 30% deposit by T/T.
Q:Where is your factory located? How can I visit there?
A:Our factory is located in Huadu District, Guangzhou City, Guangdong Province, China, about 25 minutes by car from Baiyun international Airport. We welcome customers from all over the world!
Q: What is "Trade Assurance"?
A: Trade Assurance is a new service provided by Alibaba, which can provides buyers with a number of trade safeguards, protect buyers' payments, and to ensure suppliers fufill their obligations regarding order delivery time and product quality.
Thanks for your visit.
If you need more information, please click "Send" now.
If you have any other questions, please feel free to contact us.
