Большой крутящий момент челюсти паука соединение HRC150 HRC180 для вала

Большой крутящий момент челюсти паука соединение HRC150 HRC180 для вала

Категория: >>>
Поставщик: Tianjin NaBoRui Mechanical Equipment Sales Co. Ltd.

Цена:*

Количество:

В избранное

Описание и отзывы

Характеристики

Professional supply kinds of motor coupling

As a professional coupling manufacturer and trader with many years expriences,

we could offer many kinds of couplings.They are good quality and more competitive price in this field.

HRC type couplings can be supplied .

Features of HRC spider couplings :

1).Installation is quick and easy without special tools .

2).Maintenance is virtually eliminated without lubrication required.

3).The electro metri element allows HRC to be suitable for use in most conditions.

4). Can undertake high torque ,Have the good buffer,Long service life

Catalog of HRC spider coupling

please choose the suitable model from below .(please contsct us if any question )

HRC coupling type as below

Type F&H						BORED TO SIZE				A	B	E	F	G	L1	L2	L3	J*
SIZE	BUSH	BORE		C	D	BORE		C	D
SIZE	BUSH	MAX	MIN	C	D	MAX	MIN	C	D
70	1008	25	9	20	23.5	32	10	20	23.5	69	60	31	25	18	65	66.5	68	29
90	1108	28	9	19.5	23.5	42	10	26	30.5	85	70	32	30.5	22.5	69.5	76	82.5	29
110	1610	42	14	18.5	26.5	55	10	37	45.5	112	100	45	45	29	82	101	119	38
130	1610	42	14	18	26.5	60	20	39	47.5	130	105	50	50	36	89	118	146	38
150	2012	50	14	23.5	33.5	65	28	46	56	150	115	62	62	40	107	134	160	42
180	2517	60	16	34.5	46.5	80	28	58	70	180	125	77	77	49	142	166	189	48
230	3020	75	25	39.5	52.5	100	48	77	90	225	155	99	99	59.5	165	202	240	55
280	3525	100	35	51	66.5	115	60	90	105.5	275	206	119	119	74.5	208	247	286	67

We also accept OEM and ODM,we can produce coupling as per your requirest size.

We also can help customer design and produce non-standard coupling.

If you need,please feel free to contact with us!

real photos show of HRC spider coupling

package show

factory show

our serive & why choose us

1.High quality product----Our tenet is “quality first”.Good material,precise

manufacturing processes and strict quality control can create excellent

quality.

2.Competitive price----We have our own factory,scientific producing,

direct-selling.So we can save the cost and supply low price.

3.Professional----- Our professional engineer can answer technical

questions,help you solve technical problems and help you choose the

most suitable product according to your requirment.

4.Delivery fast -----We are near port,and we have professional forwarder.

Goods can be sent out within 1 to 5 working days based on order quantity.

5.Best service-----Answering e-mails or solving questions timely.

Delivery and update information on time.

Trust, good quality and service are the basic of long term business.

We are sure any of your inquiry will get our prompt and reply !

Please feel free to contact with us !

Satisfy the needs of customers
Fast reaction
High quality and guarantee,
Using environmental protection material
Our products are complete in specifications
Our products are well-known for its fine quality
Quality is job 1
Customer always first

please contact us by the below

what is the our diameter ,length and inner diameter you need dear ?

catalog can be provided ,please ask for from me by beow way ,thanks .

have questions? we're here to help !!!

thanks for your visting !
