G80 сварка на анкерных крючках и крюке от снаряжения грузоподъемной компании

G80 Weld On Anchor Hooks and Weld on hook from rigging and lifting company

• Size:2-15MM
•  Material: Forged super alloy steel-Quenched Tempered.
• Finish: Power Coating
• Safety Factor: 4:1
• Certified heat treatment
• Individually Proof Test: 2.5times working Load Limit.
• Fatigue Test: 1.5 times Working Load Limit for 20000 cycles.
• Breakage test:  magnaflux crack detection.
• Load Pins: all load pins are 100%individually inspected and tested.
• Nonstandard products can be made according to drawing or samples.
• Rated: 100% at 90 degree angle.

• Specifictaion of G80 Weld On Anchor Hooks and Weld on hook from rigging and lifting company



  Item No.	Size	WLL/T	B.L/T	Technique parameter(mm)				N.W
  				B	C	E	L	(KG)
  YD-072-02	2	2T	10T	92	67	30	114	0.83
  YD-072-03	3	3T	15T	106	73.5	33.2	129	1.2
  YD-072-05	5	5T	25T	133	94	39	171	2.46
  YD-072-08	8	8T	40T	136.5	94	35	177	3.26
  YD-072-10	10	10T	50T	169.5	134.5	50.54	233	5.17
  YD-072-15	15	15T	75T	184	155	54	255	8






• Our Main Products:
•
• Product Manufacture Flow 1
• Product Manufacture Flow 12
•

G80 Weld On Anchor Hooks and Weld on hook from rigging and lifting company

•

  • 100% factory price, because we are direct producer of swivel lifting points,Slings,Shackles,Links,Hooks,Other Rigging    accessories and so on. .
  • Market, technical support and after-sale service within 24 hours.
  • You can order your own configuration.
  • All lifting points are tested  2.5times working Load Limit, 1.5 times Working Load Limit for 20000 cycles for fatigue test and so on.
  • OEM is accepted

Lots in Stock!!!Grade80 Alloy Steel Quenched Tempered Lifting Point

Tianjin Yiyun Rigging co.,ltd, is located in the beautiful Binhai newly developed area-Tianjin Shuanggang industry zoo, is a professional company which owns one stop service from research, design, production ,sale to service.

We started our business earlier at the year of 1997. We are a qualified supplier and we have obtained ISO9001:2000 and CE Quality System Certificate for Swivel Hoist Ring. Our main products include Swivel Hoist Ring, Universal Rings, Side Pull Lifting Points, Weld-on Lifting Point, Angular Contact Bearing Swivels Ring , lifting belts& fittings, up to 10 varieties of series, more than 300 kinds of specifications. Location, harmonious human environment and outstanding industrial advantages have made our company become the ideal place for foreign investment. Up till now, our products are sold to South Korea, the United Kingdom, the United States, Germany, Russia, Vietnam, Philippine, Taiwan and other countries and regions. With our effort, a good reputation has been erecting among the majority of users at home and abroad.

OUrs Advantages:

• Certifications: ISO 9001,CE,CSS&Patents.
• Factory History: A decade more manufactures experience.
• Factory Location: Shuanggang Industry Zoo, Tianjin, China
• Management Certification: ISO 9001,CE,CSS&Patents.

          Lots in Stock!!!Grade80 Alloy Steel Quenched Tempered Lifting Point
