cheap price 80hp 4WD farm tractor made in China

Product Description

Brief introduction for farm tractor:

1. The power by luoyang dongfanghong diesel engine, straight cold water, four-stroke engine, torque reserve;
2. Use 4 x (3 + 1) transmission (12 forward, four reverse), convenient operation, high work efficiency;
3. Double speed power output, speed is 540/1000 or 540/720, two sets of hydraulic output interface, can form a complete set of various agricultural machinery, adapt to many condition of operation;
4. Adopting full hydraulic steering, double-acting clutch, flexible operation of portable.



IMG_3737.jpgIMG_2352.jpgIMG_3698.jpgIMG_3716.jpg IMG_3734.jpg IMG_3720.jpg



Advatage of farm tractor:



& Adjustable supporting slider, a protection of the ground

& Flexible design, avoid snow blocking of outlet

& Blow the snow to the green belt or roadside, or throw the snow onto truck

& Ideal implements for clearing traffic lanes, sidewalks, yards etc



Technical parameters for farm tractor:



Tractor Model

300

350

304

354

Drive Type

4×2

4X2

4X4

4X4

Overall Dimension  L×W×H(mm)

3535×1485×1895

3590×1485×1940

3590×1485×1895

3590×1485×1940

Wheel base(mm)

1705

1760

Front wheel tread(mm)

1100-1400

1200

Rear wheel tread(mm)

1100-1400

1100-1400

Min. ground clearance(mm)

338

380

235

280

Min.  steering radius

Unilateral brake(m)

2.8

2.8

Not unilateral brake(m)

3.2

3.4

Min. operating weight (KG)

1410

1480

1620

1640

Gearbox  gears number

8F+4R

8F+4R

Speed

Forward(Km/h)

2.07-27.08

2.25-29.53

2.07-27.08

2.25-29.53

Reverse(Km/h)

3.07-9.35

3.34-10.20

3.07-9.35

3.34-10.20

Engine

Model

YD485T-C075

YND490T-C053

YD485T-C075

YND490T-C053

Rated power (Kw)

22.1

25.7

22.1

25.7

Rated speed (r/min)

2200

2200

2200

2200

Tires spec.

Front tires

5.50-16

5.50-16

6.50-16

7.50-16

Rear tires

11.2-24

11.2-28

11.2-24

11.2-28

Steering Type

Full hydraulic  front wheels steering

Max. lifting force( KN )

5

5.8

5

5.8

PTO

Type

Rear-mounted, Non independent type

Speed (r/min)

540/720 or 540/1000

Power(Kw)

≥18.78

≥21.85

≥18.78

≥21.85

Control type of ploughing depth

Force  control & Position control

Max. traction force (KN)

5.6

5.8

6.7

6.9

Front / rear Ballast (KG)

80/80

80/100

80/80

80/100



  IMG_3729.jpg IMG_3724.jpg
